Help CenterWedge Wire Screen Element Factory Direct With Free Technical Support and Sample Testing
Product Spotlights
Related Products
-
Wedge Wire Screen Element, 304 Stainless Steel, 0.2mm Slot, 1 Year Warranty, Free Technical SupportNegotiableMOQ: 1 Piece -
Precision Wedge Wire Screen Element, 1.0mm Slot, 316L Stainless Steel, 120mm Length, for Oil & GasNegotiableMOQ: 1 Piece
-
Wedge Wire Screen Element for Sand and Gravel Filtration, 316L SS, 0.8mm Slot, Anti-Clogging DesignNegotiableMOQ: 1 Piece
-
Wedge Wire Screen Element With 316L Stainless Steel, 1.5mm Slot, 50mm OD, Mill Test Report IncludedNegotiableMOQ: 1 Piece
-
Custom Wedge Wire Screen Element, 304 SS, 0.2mm Slot, 100mm Length, for Industrial FiltrationNegotiableMOQ: 1 Piece
Welcome to Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer since 1998, specializing in high-quality wedge wire screens. With an annual export value of US$5 Million - US$10 Million and serving markets across North America, South America, Europe, Asia, Africa, and Oceania, we offer factory-direct pricing on wedge wire screen elements. Our commitment to excellence includes free technical support and complimentary sample testing, ensuring you get the perfect filtration solution for your application. Whether you need a single element or bulk orders, our experienced team is ready to assist.
Wedge wire screen elements are precision-engineered components used in liquid-solid separation, water treatment, oil & gas filtration, and many industrial processes. Our elements are manufactured using advanced welding technology, ensuring consistent slot sizes, high strength, and long service life. The V-shaped profile design minimizes clogging and allows for efficient backwashing, reducing maintenance costs.
Key Features & Technical Specifications
- V-Shaped Wire Profile – Provides self-cleaning effect, reduces particle entrapment, and ensures uniform filtration.
- Wide Slot Range – From 0.05mm to 20mm (customizable), suitable for coarse to fine screening.
- High Mechanical Strength – Welded construction withstands high pressure and backwash cycles.
- Corrosion & Heat Resistance – Available in 304/316L stainless steel, duplex, or hastelloy for harsh environments.
- Customizable Dimensions – Length, diameter, end connections (flange, thread, welding) tailored to your needs.
- Free Technical Support – Our engineers help you select the optimal slot size, material, and design.
- Free Sample Testing – Send us your fluid or solid sample; we test the performance before mass production.
| Parameter | Specification | Remarks |
|---|---|---|
| Material | SS304, SS316L, 904L, Duplex, Hastelloy | Customizable upon request |
| Slot Size | 0.05 – 20 mm | Tolerance ±0.02mm |
| Wire Diameter | 0.5 – 5 mm | Depends on slot and strength |
| Max Length | Up to 6000 mm (single piece) | Longer length can be spliced |
| Max Outer Diameter | Up to 2000 mm | For cylindrical elements |
| End Connections | Flange, Thread, O-ring, Welding | Customizable |
Benefits for Your Business: By choosing our wedge wire screen elements, you gain access to decades of manufacturing expertise. Our factory-direct model eliminates middlemen, offering you competitive pricing without compromising quality. The free technical support ensures that your specific requirements are met – from slot size selection to material compatibility. Sample testing allows you to verify performance in your actual process, reducing risk before full-scale production.
Our products are widely used in water treatment plants (intake screens, filter nozzles), oil & gas industry (well screens, sand control), food processing (juice extraction, sugar refining), mining (dewatering, sizing), and chemical processing (catalyst recovery). With a robust production capacity and strict quality control, we deliver consistent, reliable components that stand the test of time.
Trust & Reliability – Why Choose Us?
At Anping County Boli Hardware Wiremesh Products Factory, we have been serving global clients for over 25 years. Our factory is located in Hengshui, Hebei, China – the heart of China's wire mesh industry. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring fast and reliable logistics. Our annual export value of US$5-10 million reflects the trust our customers place in us. We offer free technical support and free sample testing to help you make an informed decision. Whether you need a custom design or a standard element, we are ready to assist. Contact us today for a quote or to discuss your project!
Frequently Asked Questions (FAQ)
-
Q: What is the typical lead time for custom wedge wire screen elements?
A: For standard sizes, we can ship within 10-15 working days. Custom designs usually take 20-30 days, depending on complexity. We offer expedited options for urgent orders. -
Q: Can I get a sample before placing a large order?
A: Yes, we provide free sample testing. You can send us your fluid or solid sample, and we will test the performance of our wedge wire screen. Samples are available at a nominal cost (refundable with bulk order). -
Q: How do I choose the correct slot size for my application?
A: Our technical support team can help you based on your particle size distribution, flow rate, and desired separation efficiency. We also provide free testing to confirm the optimal slot. -
Q: What materials are available? Can I use it in high-temperature environments?
A: We offer stainless steel 304, 316L, 904L, duplex, and hastelloy. For high-temperature applications up to 800°C, we recommend specific grades. Please consult our engineers. -
Q: Do you provide end connections like flanges or threads?
A: Yes, we can customize end connections: flanges (ANSI, DIN, JIS), male/female threads, O-ring grooves, or plain ends for welding. Specify your requirements. -
Q: How do you ensure quality consistency?
A: We have a strict quality control system including slot size measurement, pressure test, and material certification. Each batch is inspected before shipment. -
Q: What is the minimum order quantity (MOQ)?
A: For standard products, MOQ is 10 pieces. For custom designs, it depends on the complexity. We are flexible and welcome small trial orders. -
Q: What payment terms do you accept?
A: We accept T/T, L/C, Western Union, and PayPal for small orders. For large contracts, terms are negotiable.
Ready to get started? Contact our sales team for a personalized quotation and free technical advice. With our factory-direct pricing, free support, and sample testing, you can be confident in the performance of your wedge wire screen elements. We look forward to building a long-term partnership with you!
