As a leading manufacturer from Henan San Kuang Machinery Technology Co., Ltd. (established in 2014, located in Luoyang, Henan, China), we specialize in producing high-quality, customized transmission gear shafts that meet the rigorous demands of various industries. Our factory spans 10,000–30,000 square meters and is equipped with advanced CNC machines and heat treatment facilities, ensuring every gear shaft delivers exceptional durability and precision. We offer free samples for testing and provide unlimited technical support throughout your project, from design to mass production.
Our transmission gear shafts are engineered to transfer torque efficiently in automotive gearboxes, industrial reducers, and agricultural equipment. With over 10 years of export experience to markets including North America, Europe, Southeast Asia, and Africa, we understand the importance of consistent quality and on-time delivery. Whether you need a standard spline shaft or a complex custom profile, our team of 51–100 skilled workers and engineers can deliver solutions tailored to your specifications.
Key Features of Our Customized Transmission Gear Shafts:
- High Strength & Wear Resistance: Made from alloy steels (20CrMnTi, 40Cr, 42CrMo) with carburizing or nitriding treatment, achieving surface hardness up to HRC 60.
- Precision Machining: CNC hobbing and grinding ensure tooth profile accuracy within DIN 6-8 grade, reducing noise and vibration in operation.
- Fully Customizable: We accept custom dimensions, tooth count, helix angle, bore diameter, keyway, and special coatings upon request.
- Rigorous Quality Control: 100% dimensional inspection, magnetic particle testing, and hardness testing are performed before shipment.
- Free Sample Program: Evaluate our quality with a free sample (shipping cost collect). Technical support is provided during your testing phase.
- Flexible MOQ: Low minimum order quantity available for trial orders, with scalable production for large volumes.
Technical Specifications (Typical Parameters):
| Parameter | Available Range |
|---|---|
| Shaft Diameter | 20 mm – 200 mm |
| Overall Length | 50 mm – 1500 mm |
| Module (for gears) | 1 – 10 |
| Tooth Hardness | HRC 50 – 65 |
| Surface Roughness | Ra 0.8 – 1.6 μm |
| Material Options | 20CrMnTi, 40Cr, 42CrMo, 45# steel, stainless steel |
Benefits for Your Business:
- Reduce Downtime: Our shafts are engineered to withstand high loads and harsh conditions, extending equipment life.
- Cost Efficiency: Competitive pricing without compromising quality – our annual export value of US$2.5–5 million proves our ability to deliver value.
- One-Stop Service: From CAD drawing review to final packaging, we handle all steps. Technical support is available via email, phone, or video call.
- Fast Lead Time: Sample production in 7–15 days; mass production lead time depends on quantity, typically 20–35 days.
Company Strengths & Trustworthiness:
With over 51–100 employees, a factory area of 10,000–30,000 m², and multiple certifications including ISO9001, ISO14000, OHSAS18001, TS16949, and HACCP (among others), Henan San Kuang Machinery Technology Co., Ltd. is a reliable partner for global buyers. We ship through major ports: Shanghai, Lianyungang, Qingdao, and Tianjin, ensuring efficient logistics. Our main markets span all continents, and we have a dedicated sales team supporting after-sales service. We invite you to test our free sample and experience the difference that precision engineering makes.
Contact us today to discuss your custom transmission gear shaft requirements. We are ready to provide technical drawings, quotation, and a free sample for your evaluation.
Frequently Asked Questions (FAQ)
-
What is the typical lead time for a customized gear shaft sample?
Sample production usually takes 7–15 working days after drawing approval. For urgent needs, we can expedite with a small surcharge. -
Do you offer free samples? How do I get one?
Yes, we offer free samples for testing. You just need to cover the shipping cost. Please contact us with your required specifications, and we will arrange the sample. -
What materials are available for the gear shaft?
Common materials include 20CrMnTi, 40Cr, 42CrMo, and 45# steel. We also offer stainless steel or other alloys on request. The best material depends on your application and load requirements. -
Can you manufacture gear shafts with special tooth profiles or spline designs?
Absolutely. We can produce involute splines, straight splines, helical gears, double helical gears, and custom profiles. Provide your drawing or technical specifications. -
What is the minimum order quantity (MOQ) for mass production?
Our MOQ is flexible. For standard sizes, we can accept as low as 50 pieces for trial. For large volume orders, we can adjust pricing accordingly. -
How do you ensure the quality of the gear shafts?
We have a comprehensive QC system: incoming material inspection, in-process dimensional checks, final hardness and surface testing, and report provided with each shipment. We also follow ISO9001 and TS16949 standards. -
Do you provide technical support for design optimization?
Yes, our engineering team can help you optimize the shaft design for better performance, cost reduction, or easier manufacturing. We provide free technical consultation. -
What is the shipping method and port?
We ship from Shanghai, Lianyungang, Qingdao, or Tianjin ports. We can arrange sea freight, air freight, or express courier based on your preference.
