Help CenterHeat Seal Lacquer Coated Pharmaceutical Aluminum Foil, 25 Micron, 8021 Alloy
Product Spotlights
Related Products
-
High Tensile Strength Pharmaceutical Aluminum Foil, 8011-H18, 25 MicronNegotiableMOQ: 1 Ton -
1 Year Warranty Pharmaceutical Aluminum Foil, 25 Micron, With Mill Test ReportNegotiableMOQ: 1 Ton
-
Tropical Climate Pharmaceutical Aluminum Foil for Moisture Sensitive MedicineNegotiableMOQ: 1 Ton
-
Matt Finish Pharmaceutical Aluminum Foil, 8021 Alloy, 0.025mm for BlisterNegotiableMOQ: 1 Ton
-
Custom Width 200mm-600mm Pharmaceutical Aluminum Foil, 8011, 20 MicronNegotiableMOQ: 1 Ton
Welcome to Hemaokang Steel (Shandong) Co., Ltd. As a trusted manufacturer established in 2025 with annual export value exceeding US$50 million, we are proud to present our Heat Seal Lacquer Coated Pharmaceutical Aluminum Foil made from premium 8021 alloy at 25 micron thickness. This foil is specifically engineered for the pharmaceutical industry, offering superior barrier properties and reliable heat seal performance to ensure drug safety and integrity. Our product is manufactured under strict quality control, supported by ISO9001 certification, and has been exported to over 15 regions worldwide including North America, Europe, and Southeast Asia.
Our pharmaceutical aluminum foil is designed for blister packaging, where it serves as a protective layer that seals medicine tablets or capsules. The heat seal lacquer coating provides excellent adhesion to PVC/PVDC films, ensuring a tamper-evident and moisture-proof seal. With a thickness of exactly 25 microns, it balances flexibility and strength, making it ideal for automated packaging lines. Below we detail the key features, technical specifications, and benefits of this product.
Key Features & Advantages
- Enhanced Barrier Protection: The 8021 aluminum alloy offers outstanding resistance to moisture, oxygen, and light, preserving the stability of pharmaceutical products.
- Consistent Heat Seal Performance: The precisely applied lacquer coating ensures uniform sealing temperature and peel strength, reducing packaging defects.
- Flexible & Durable: At 25 microns, the foil is thin yet strong, easily conforming to blister cavities without tearing.
- Food-Grade Safety: All materials comply with pharmaceutical packaging standards, free from harmful substances.
- Customizable Dimensions: Available in various widths and roll lengths to fit your specific packaging machines.
- Eco-Friendly Production: Our manufacturing process minimizes waste and energy consumption, aligning with green initiatives.
Technical Specifications
| Parameter | Value |
|---|---|
| Alloy | 8021 |
| Thickness | 25 Micron (±5%) |
| Coating | Heat Seal Lacquer (single or double side, optional) |
| Width | 200mm – 1200mm (customizable) |
| Temper | O (soft) or H18/H24 available upon request |
| Tensile Strength | ≥ 80 MPa (typical) |
| Elongation | ≥ 1% (for O temper) |
| Heat Seal Temperature | 120°C – 180°C (depending on base film) |
| Pin-Hole Resistance | Excellent, ≤ 5 pinholes/m² |
Customer Benefits
- Cost Efficiency: Consistent quality reduces waste and rework, lowering overall packaging costs.
- Enhanced Drug Shelf Life: Superior barrier properties increase the stability of sensitive medications.
- Easy Integration: Compatible with most blister packaging machines, minimizing downtime during changeover.
- Reliable Supply: Our company has a production capacity of over 500 tons per month, ensuring timely delivery.
- Technical Support: Our experienced team provides guidance on coating selection and sealing parameters.
Why Choose Hemaokang Steel (Shandong) Co., Ltd.? With 51-100 employees and an annual export value of US$50-100 million, we have established a strong reputation in the global market. Our factory is located in Liaocheng, Shandong, a major aluminum production hub in China, giving us access to high-quality raw materials and advanced manufacturing technology. We hold ISO9001 certification and conduct rigorous tests on every batch, including pinhole detection, coating thickness uniformity, and peel strength measurement. Our main markets span across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. We are committed to providing the best heat seal aluminum foil for your pharmaceutical needs. Contact us today for a quote or sample, and experience the difference in quality and service.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lead time for this product?
A: Standard lead time is 15-20 days after order confirmation, depending on the quantity and customization requirements. -
Q: Can you provide samples for testing?
A: Yes, we offer free samples (excluding shipping cost) for quality evaluation. Please contact our sales team to arrange. -
Q: Is this foil suitable for high-speed blister packaging machines?
A: Absolutely. The 25 micron thickness and consistent lubrication ensure smooth feeding and sealing on most automatic machines. -
Q: What is the shelf life of the coated foil?
A: When stored in a dry, cool environment (below 40°C, humidity -
Q: Do you offer custom widths or lengths?
A: Yes, we can produce any width from 200mm to 1200mm and custom roll lengths (e.g., 1000m, 2000m) per your specifications. -
Q: What certifications do you have for pharmaceutical packaging?
A: Our factory is ISO9001 certified, and the foil complies with relevant pharmaceutical packaging standards. Additional certifications can be reviewed upon request. -
Q: How do you ensure the coating is uniform?
A: We use advanced coating machines with online thickness monitoring and conduct random sampling tests for each batch. -
Q: Can this foil be used for cold-form blister packaging?
A: Our 8021 alloy foil is primarily designed for heat-seal lidding. For cold-form applications, we recommend our other product lines; please consult our technical team.
