Help CenterEmbossed Screen Plate 5mm Thick 10x10mm Square Hole 4ft x 8ft Carbon Steel
Product Spotlights
Related Products
-
Embossed Screen 316L 0.5mm Wire 1.5mm Opening 220V Vibrating Motor Industrial SifterNegotiableMOQ: 50 Cubic Centimeters -
304 Stainless Steel Embossed Screen 1.2mm Hole for Food Processing Standard CompliantNegotiableMOQ: 50 Cubic Centimeters
-
200 Mesh Embossed Screen 3mm Aperture 1.2m x 2.4m Carbon Steel Sheet for SievingNegotiableMOQ: 50 Cubic Centimeters
-
304 Embossed Screen 0.8mm Wire Diameter 2mm Gap 500mm Roll Width 30m LengthNegotiableMOQ: 50 Cubic Centimeters
-
Embossed Screen 1.5mm Thick 8x8 Mesh 600x1200mm Panel for Industrial FiltrationNegotiableMOQ: 50 Cubic Centimeters
At Anping Xinye Metal Wire Mesh Products Co., Ltd, located in the heart of Hengshui, Hebei—China's renowned wire mesh manufacturing hub—we take pride in delivering high-quality industrial screening solutions. Our Embossed Screen Plate 5mm Thick 10x10mm Square Hole 4ft x 8ft Carbon Steel is engineered to provide exceptional durability, precise filtration, and long service life in demanding environments. Each plate undergoes rigorous quality control to ensure consistent hole size, flatness, and embossed pattern integrity, making it a reliable choice for industries ranging from mining to chemical processing.
Key Features & Technical Specifications
- Material: Premium carbon steel (Q235 or equivalent) with excellent strength and wear resistance.
- Thickness: 5mm – offers robust rigidity while maintaining manageable weight for handling and installation.
- Hole Pattern: Accurate 10mm x 10mm square holes, punched and deburred for smooth edges and precise sizing.
- Sheet Size: Standard 4ft x 8ft (1220mm x 2440mm), customizable upon request.
- Surface Finish: Embossed pattern (raised diamond or similar) enhances stiffness and reduces glare, improving visibility in screening applications.
- Open Area: Approximately 40-45% (depending on exact pattern configuration), balancing strength and flow capacity.
Product Advantages
- Superior Durability: The 5mm carbon steel base withstands heavy impacts, abrasion, and repeated loading, ideal for primary screening stages.
- Accurate Classification: 10x10mm square holes provide consistent particle sizing, reducing oversize contamination.
- Enhanced Stiffness: Embossed surface increases plate rigidity without adding extra thickness, minimizing deflection under load.
- Easy Installation: Standard dimensions fit most equipment frames; optional pre-drilled mounting holes available.
- Cost-Effective: Lower material cost compared to stainless steel, while offering excellent performance for many dry and wet screening tasks.
| Parameter | Value |
|---|---|
| Tensile Strength (MPa) | ≥ 370 |
| Yield Strength (MPa) | ≥ 235 |
| Hardness (HRB) | 60-80 |
| Weight per Sheet (approx.) | 47 kg |
Applications
- Mining & Quarrying – Vibrating screens for aggregate, coal, ore classification.
- Chemical & Fertilizer – Sifting powders, granules, and pellets.
- Recycling – Sorting waste materials, e.g., plastics, glass, metals.
- Construction – Aggregate sizing for concrete and asphalt.
- Agriculture – Grain cleaning, seed processing.
Customer Trust & Quality Assurance
Anping Xinye Metal Wire Mesh Products Co., Ltd has been a trusted manufacturer in the wire mesh industry for over 15 years, supplying to clients across more than 30 countries. Our factory spans 10,000 square meters and is equipped with advanced CNC punching machines, embossing presses, and straightening equipment. Every batch of screen plates is inspected for hole size tolerance (±0.5mm), flatness, and surface finish. We have shipped over 50,000 tons of perforated metal products, earning recognition for consistent quality and on-time delivery.
We understand that your screening process demands reliability. That's why we offer customizable options including different embossed patterns, edge preparation (plain, beveled, or hook), and protective coatings (paint, galvanized) upon request. Our experienced technical team can assist with selection and provide samples for your testing.
Contact us today to discuss your requirements or request a quotation. Benefit from competitive pricing, short lead times, and a dedicated support team that ensures your satisfaction from order to delivery.
Frequently Asked Questions
-
Q: What is the exact open area percentage of this screen plate?
A: The open area is approximately 40-45% for the standard 10x10mm square hole on a 5mm thick plate. Actual percentage may vary slightly depending on the embossed pattern dimensions. -
Q: Can I get a custom size other than 4ft x 8ft?
A: Yes, we offer custom cutting to your required dimensions. Minimum order quantity may apply. Please provide your exact size requirements. -
Q: Is the plate hot-dip galvanized for corrosion resistance?
A: The standard product is in plain carbon steel (black surface). Galvanized or painted finishes are available as optional treatments. Contact us for lead time and pricing. -
Q: How do I install this screen plate in my vibrating screen machine?
A: The plate can be bolted or clamped directly onto the screen frame. We can also supply pre-drilled holes or edge hooks if needed. Please specify when ordering. -
Q: What is the tolerance on hole size?
A: Our production tolerance is ±0.5mm for the square hole dimension. This ensures accurate screening performance. -
Q: Can you provide a sample before bulk order?
A: Yes, we can provide a small sample piece (e.g., 300mm x 300mm) for evaluation. Please contact our sales team to arrange. -
Q: What is the minimum order quantity?
A: Typically, the MOQ is 10 sheets for standard sizes. For custom sizes, it may be higher. Please inquire for your specific needs. -
Q: How long does shipping take?
A: For standard orders, production takes about 7-10 working days, and shipping time depends on your location and chosen freight method. We can provide estimated delivery dates upon request.
