Help CenterEmbossed Screen for Chemical Filtration 304 Stainless Steel 0.5mm Hole Size Acid Resistant
Product Spotlights
Related Products
-
Automated Embossed Screen Production Line 220V PLC Control 10m/min Speed for Metal MeshNegotiableMOQ: 50 Cubic Centimeters -
Embossed Screen 1.5mm Plate 5mm Hole Dia 60% Open Area for Heavy Duty Mining ScreeningNegotiableMOQ: 50 Cubic Centimeters
-
Decorative Embossed Screen Panel 1.2m x 2.4m 0.6mm 304 Stainless Steel for Building FacadeNegotiableMOQ: 50 Cubic Centimeters
-
Embossed Screen 12 Months Warranty Free Sample Available Mill Test Report SuppliedNegotiableMOQ: 50 Cubic Centimeters
-
Embossed Screen With 2mm Hole Diameter 40% Open Area Laser Cut Stainless Steel MeshNegotiableMOQ: 50 Cubic Centimeters
Anping Xinye Metal Wire Mesh Products Co., Ltd, based in the industrial hub of Hengshui, Hebei, China, is proud to present our Embossed Screen for Chemical Filtration crafted from premium 304 Stainless Steel with a precise 0.5mm hole size. This product is specifically designed to withstand harsh acidic environments, ensuring reliable performance in demanding chemical filtration processes. Our embossed screen combines structural integrity with excellent flow characteristics, making it an ideal choice for separating solids from liquids in corrosive media. With years of expertise in metal mesh manufacturing, we deliver screens that meet rigorous quality standards while offering cost-effective solutions for your filtration needs.
Key Features & Technical Specifications
- Material: High-grade 304 Stainless Steel – excellent corrosion resistance against acids, alkalis, and organic solvents.
- Hole Size: 0.5mm (500 microns) – ensures effective filtration of fine particles while maintaining high throughput.
- Surface Treatment: Embossed pattern – increases surface area for improved filtration efficiency and reduces clogging tendency.
- Acid Resistance: Specifically engineered for chemical environments, including sulfuric acid, hydrochloric acid, and nitric acid solutions at moderate concentrations and temperatures.
- Durability: Robust construction withstands repeated cleaning and high-pressure backwashing cycles.
- Customization Options: Available in various sheet sizes, thicknesses (0.5mm to 2.0mm), and edge finishes (plain, hooked, or welded).
- Easy Installation: Can be cut, bent, or welded to fit existing filtration equipment.
| Parameter | Value |
|---|---|
| Material Grade | 304 Stainless Steel (1.4301) |
| Hole Diameter | 0.5 mm ± 0.05 mm |
| Open Area | Approximately 30-40% (depending on embossed pattern) |
| Sheet Size | Standard 1m x 2m; custom sizes available |
| Thickness | 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm |
| Working Temperature | -20°C to 400°C (depending on environment) |
| Acid Resistance | Excellent against dilute sulfuric acid, phosphoric acid, organic acids |
Advantages for Your Filtration Process
- Enhanced Filtration Efficiency: The embossed surface creates turbulence that helps separate solids more effectively than flat screens.
- Reduced Maintenance: Smooth, non-stick surface minimizes particle adhesion, extending cleaning intervals.
- Chemical Compatibility: 304 stainless steel provides reliable performance in most acidic and alkaline environments, reducing replacement costs.
- Versatile Applications: Suitable for chemical processing, pharmaceutical filtration, water treatment, food and beverage industry, and petrochemical refining.
- Long Service Life: High mechanical strength and corrosion resistance ensure years of continuous operation.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we have been supplying high-quality filtration solutions to global clients since our establishment. Our factory in Hengshui, Hebei, utilizes advanced stamping and embossing machinery to produce screens with consistent hole sizes and uniform patterns. We have shipped thousands of square meters of embossed screens to customers in Europe, North America, Southeast Asia, and the Middle East. Our quality control includes dimensional inspection, corrosion testing, and visual checks to ensure every screen meets your specifications. With a dedicated team of engineers, we can also customize the hole pattern, sheet dimensions, and edge finishing to suit your exact requirements. We invite you to contact us for a quote or technical consultation – our responsive customer service ensures prompt support and fast delivery. Choose Anping Xinye for reliable chemical filtration screens that deliver performance and value.
Frequently Asked Questions (FAQ)
1. What is the maximum temperature this screen can withstand?
The working temperature range depends on the environment. In air, 304 stainless steel can handle up to 400°C; in acidic solutions, the maximum temperature is lower (typically up to 60°C for concentrated acids). Please consult our engineers for specific conditions.
2. Can the embossed screen be used for reverse osmosis pre-filtration?
Yes, it is suitable as a pre-filter to remove larger particles before RO membranes. The 0.5mm hole size effectively captures particles >500 microns.
3. Is the screen resistant to hydrochloric acid?
304 stainless steel has limited resistance to hydrochloric acid, especially at high concentrations and temperatures. For strong HCl environments, we recommend our 316L or Hastelloy screens. For dilute HCl (<1%) at room temperature, 304 may be acceptable.
4. What surface finishes are available?
Standard finish is embossed (raised pattern). We also offer plain (flat) perforated screens, or combinations with woven wire mesh upon request.
5. How do I clean the screen?
You can clean the screen with water jets, ultrasonic cleaning, or chemical cleaning agents compatible with 304 stainless steel. The embossed pattern helps prevent clogging, making cleaning easier.
6. Can I get a sample before bulk order?
Yes, we provide small sample sheets (e.g., 200mm x 200mm) for testing. Please contact us to arrange a sample with your preferred hole size and thickness.
7. What is the lead time for standard orders?
For standard sizes, lead time is typically 7-10 working days. Custom orders may require 15-20 working days, depending on complexity.
8. Do you provide certificates of material or test reports?
Yes, we can issue a material test certificate (MTC) for 304 stainless steel upon request. Additional testing reports (e.g., corrosion resistance) are available at extra cost.
