| Product Name | Ceramic Structured Packing |
| Material | Industrial Ceramic |
| Packing Type | Structured Packing |
| Available Model | 125Y / 250Y / 350Y / 450Y |
| Application | Tower Replacement / Retrofit |
| Tower Type | Existing Packed Tower |
| Process | Gas-Liquid Mass Transfer |
| Service | Corrosive Chemical Service |
| Performance | Corrosion Resistance / Thermal Stability |
| Customization | Tower Diameter / Segment Size |
| Project Type | Revamp / Retrofit / Replacement |
| Industry | Chemical / Acid Processing / Gas Treatment |
Ceramic Structured Packing for Existing Tower Replacement
DAIER Separation supplies ceramic structured packing for existing packed tower revamps, retrofit projects and replacement of old structured packing beds.
For replacement projects, the new packing should be checked against tower diameter, bed height, support structure, process medium and operating conditions rather than replacing the old packing by model number alone.
Different ceramic structured packing models can be supplied according to the required balance between hydraulic capacity, pressure drop and mass-transfer efficiency.
Typical Applications
Existing acid absorption towers
Chemical process tower revamps
Corrosive gas treatment columns
Sulfuric acid tower maintenance
Ceramic structured packing replacement
Packed tower retrofit projects
Maintenance shutdown projects
Replacement RFQ Information
Please provide:
Existing packing model
Tower internal diameter
Existing packing bed height
Manway size
Support structure details
Process medium and concentration
Operating temperature
Gas and liquid load if available
Current operating issue, if any
Drawings or photos if available
Pingxiang Daier Separation Tech Co., Ltd.
DAIER Separation
Specs and test data available upon request.
