MVR Mother Liquor Evaporator 316L Stainless Steel IP65 Waterproof Control Panel for Harsh Environment
Product Spotlights
316L stainless steel enclosure with IP65 waterproof rating for harsh environments. Customizable PLC control for MVR mother liquor evaporators. High corrosion resistance, wide temperature tolerance, and global certifications. Modular design reduces downtime. Backed by ISO9001 factory with 10+ years of export experience.
US$ 2100 - 986000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, 316L Stainless Steel
Application:
Other, MVR Mother Liquor Evaporator
Protection Rating:
IP65
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
60 days
Related Products
-
Automatic Distillation Equipment 380V Three-Phase With 10-Layer Packed Column and Mill Test ReportUS$ 37900 - 8879000MOQ: 1 Combo -
High-Efficiency Distillation Unit 1000L Batch Volume With Vacuum Pump and Automated Reflux RatioUS$ 37900 - 8879000MOQ: 1 Combo
-
Industrial Distillation Column 500L/h Capacity With Temperature Controller and ISO Standard CompliantUS$ 37900 - 8879000MOQ: 1 Combo
-
Single-Stage Distillation System 5kW Heating Power 316L Stainless Steel With CIP Cleaning PortUS$ 37900 - 8879000MOQ: 1 Combo
-
Industrial Distillation Equipment for Chemical Waste Treatment 200L/h Capacity With 304 SS ShellUS$ 37900 - 8879000MOQ: 1 Combo
Material
Other, 316L Stainless Steel
Application
Other, MVR Mother Liquor Evaporator
Protection Rating
IP65
Control Type
PLC-based (customizable)
Power Supply
380V/50Hz (optional)
Operating Temperature
-20°C to +60°C (customizable)
Dimensions
Customizable per request
Weight
Customizable per request
Color
Silver / Gray (standard)
As a leading manufacturer since 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. specializes in advanced environmental equipment. Our MVR Mother Liquor Evaporator 316L Stainless Steel IP65 Waterproof Control Panel is engineered to deliver reliable, precise control in the most demanding industrial environments. Built with corrosion-resistant 316L stainless steel and a fully sealed IP65 enclosure, this control panel ensures uninterrupted operation even in high humidity, chemical exposure, or dusty conditions – a critical advantage for MVR evaporator systems handling mother liquor.
This control panel is the brain of your MVR evaporator, integrating advanced PLC logic, monitoring sensors, and user-friendly interfaces. It is designed to optimize energy recovery, maintain stable operation, and extend equipment lifespan. Whether you are processing wastewater, concentrating chemicals, or recovering valuable by-products, our panel provides the durability and precision you need.
Key Features & Benefits
- Heavy-Duty 316L Stainless Steel Enclosure: Resists pitting, crevice corrosion, and stress corrosion cracking from chloride-rich mother liquor environments. Ideal for chemical, petrochemical, and pharmaceutical industries.
- IP65 Waterproof & Dustproof Protection: Fully sealed against water jets, rain, and dust ingress. Suitable for outdoor installation or wash-down areas.
- Advanced PLC Control: Supports programmable logic for automated MVR operation, including temperature, pressure, flow, and level control. Real-time monitoring reduces manual intervention.
- High-Temperature & Harsh Environment Tolerance: Operating range from -20°C to +60°C, with optional heating/cooling add-ons for extreme climates.
- Modular & Customizable Design: Available in various sizes, power ratings (e.g., 380V/50Hz, 220V/60Hz), and IO configurations. Custom panel layouts, terminal blocks, and cable glands upon request.
- Comprehensive Safety Features: Emergency stop, overload protection, short-circuit protection, and ground fault detection. Optional redundant power supplies for critical processes.
- Easy Maintenance & Serviceability: Hinged door with tool-less access, labeled wiring, and removable sub-panels. Quick troubleshooting reduces downtime.
- Global Compliance Ready: Designed to meet international standards including CE, UL, and IEC (certifications available upon request). Our factory is ISO9001 and ISO14001 certified.
Technical Specifications (Typical)
| Parameter | Value |
|---|---|
| Enclosure Material | 316L Stainless Steel (1.4404) |
| Ingress Protection | IP65 (NEMA 4X equivalent) |
| Rated Voltage | AC 380V 3-phase (50/60Hz) or as specified |
| Control Power Supply | 24V DC (built-in transformer) |
| Operating Temperature | -20°C to +60°C |
| Relative Humidity | ≤ 95% (non-condensing) |
| PLC Communication | Modbus RTU/TCP, Profibus, Ethernet (optional) |
| Dimensions (W×H×D) | Customizable (e.g., 600×800×250 mm) |
| Weight | Approx. 35–80 kg (depending on configuration) |
| Certifications | ISO9001, ISO14001, OHSAS18001; CE/UL available upon request |
Why Choose Our Control Panel?
Our MVR evaporator control panel is not just a component; it's an integrated solution designed for long-term reliability. Key customer benefits include:
- Reduced Downtime: Robust construction and high-quality components (Schneider, Siemens, or equivalent) minimize failures. On-site diagnostic support available.
- Energy Efficiency: Precise control of compressor speed, temperature, and pressure reduces energy consumption by up to 15% compared to conventional panels.
- Simplified Operation: Intuitive touchscreen HMI with multi-language support, trend graphs, and alarm logs. Remote monitoring via SCADA optional.
- Seamless Integration: Pre-configured for Conqinphi MVR evaporators, but easily adaptable to other brands. We provide wiring diagrams, terminal assignments, and commissioning support.
Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a 10,000–30,000 m² factory with over 200 skilled employees. Our annual export value exceeds US$10 million, supplying markets across North America, Europe, Asia, and Africa. With certifications including ISO9001, ISO14001, and OHSAS18001, we adhere to strict quality and environmental management systems. Each control panel undergoes rigorous testing – including insulation resistance, dielectric strength, and IP65 water ingress tests – before shipment.
We offer a standard 12-month warranty, with extended options available. Our after-sales team provides remote troubleshooting, spare parts, and on-site service in major markets. Contact us today for a custom quotation or technical consultation. Let our durable MVR evaporator control panel safeguard your production and maximize your ROI.
Frequently Asked Questions
-
Q: Can this control panel be used with other MVR evaporator brands?
A: Yes, the panel is designed with universal compatibility. We can adjust the PLC program, I/O mapping, and communication protocols to match your existing evaporator. Please provide the technical specifications of your equipment. -
Q: What is the typical lead time for a custom panel?
A: For standard configurations, lead time is 15–20 working days. Custom panels requiring special instrumentation or non-standard dimensions may take 25–30 working days. Rush orders are possible with prior arrangement. -
Q: Is the panel suitable for outdoor installation in coastal areas?
A: Absolutely. The 316L stainless steel enclosure provides excellent resistance to saltwater corrosion. Combined with IP65 protection, it is ideal for coastal or offshore environments. -
Q: Do you provide the HMI touchscreen interface?
A: Yes, the standard panel includes a 7-inch or 10-inch color touchscreen HMI (optional upgrades). We can also integrate with your existing SCADA system via Modbus or Ethernet. -
Q: What certifications does the panel have?
A: Our factory is ISO9001, ISO14001, and OHSAS18001 certified. The panels can be manufactured to meet CE, UL, or IEC standards upon request. Please specify your required certification when ordering. -
Q: Can you provide a wiring diagram and technical documentation?
A: Yes, we provide a complete set of documents including electrical schematics, panel layout, terminal assignment, and user manual in English. Additional languages available on request. -
Q: What is the warranty period?
A: Standard warranty is 12 months from the date of shipment. We offer extended warranty up to 36 months for an additional cost. Coverage includes manufacturing defects; wear parts are excluded. -
Q: How do I place an order or request a quote?
A: Please contact our sales team with your evaporator specifications (power, voltage, required I/O points, environmental conditions). We will provide a detailed quotation and engineering proposal within 2–3 business days.
