Help CenterIndustrial MVR Evaporator for Lithium Salt, 380V, IP55 Enclosure, 1000kg/h Evaporation
Product Spotlights
Related Products
-
Compact MVR Lithium Salt Evaporator, 220V, 3kW, 100L/h for Laboratory UseUS$ 2180 - 877900MOQ: 1 Combo -
MVR Lithium Salt Evaporator With 1 Year Warranty, Mill Test Report, 304 Stainless Steel, 500kg/hUS$ 2180 - 877900MOQ: 1 Combo
-
MVR Lithium Salt Evaporator, 304 Stainless Steel, PLC Touch Screen, 0.5-2 T/h EvaporationUS$ 2180 - 877900MOQ: 1 Combo
-
MVR Evaporator for Lithium Salt Extraction From Brine, 220V, 1000L/h Capacity, Standard CompliantUS$ 2180 - 877900MOQ: 1 Combo
-
MVR Lithium Salt Evaporator for Battery Material Production, 304 Stainless Steel, PLC Control, 500L/hUS$ 2180 - 877900MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory spanning 10,000–30,000 square meters, is a leading manufacturer specializing in industrial evaporation systems. Our Industrial MVR Evaporator for Lithium Salt is engineered to deliver high-efficiency concentration and crystallization for lithium salt production, combining advanced mechanical vapor recompression technology with robust construction. With a rated evaporation capacity of 1000 kg/h, a 380V power supply, and an IP55 enclosure, this unit is designed for reliable operation in demanding environments, offering significant energy savings compared to traditional evaporators.
The MVR (Mechanical Vapor Recompression) evaporator reuses the latent heat of vaporized steam, drastically reducing energy consumption by up to 60–70% compared to multi-effect evaporation systems. This makes it an ideal solution for lithium salt processing, where operational costs are critical. The system is built with high-grade stainless steel to resist corrosion from alkaline and acidic lithium salt solutions, ensuring long service life and minimal maintenance.
Key Technical Specifications
| Parameter | Value |
| Evaporation Capacity | 1000 kg/h |
| Power Supply | 380V / 50Hz / 3-Phase |
| Enclosure Protection | IP55 (dust and water jet resistant) |
| Operating Temperature | 60–100°C (adjustable) |
| Compressor Type | Centrifugal / Roots (optional) |
| Material of Construction | SS316L / SS304 (customizable) |
| Control System | PLC + HMI touch screen |
| Dimensions (L×W×H) | Customized per order |
Product Features & Benefits
- Energy Efficiency: The MVR technology recycles vapor latent heat, reducing energy consumption by up to 70% compared to conventional evaporators, lowering your operational costs.
- High Capacity: With a 1000 kg/h evaporation rate, it meets the demands of medium-to-large scale lithium salt production lines.
- Robust Enclosure: IP55 rating protects internal components from dust and water splashes, ensuring reliable performance in harsh industrial environments.
- Corrosion Resistance: Constructed with high-grade stainless steel (SS316L or SS304), the system withstands aggressive lithium salt solutions, extending equipment lifespan.
- Automatic Operation: PLC-based control with touch screen interface allows easy monitoring and adjustment of parameters, reducing manual intervention and human error.
- Compact Design: Skid-mounted structure minimizes footprint and simplifies installation, saving valuable factory space.
- Low Maintenance: Fewer moving parts and robust compressor design reduce downtime and maintenance costs.
- Customizable Options: Available with different compressor types, material grades, and auxiliary equipment (e.g., pre-heaters, separators) to suit specific process requirements.
Our MVR evaporator is particularly suitable for concentrating lithium chloride, lithium hydroxide, lithium carbonate, and other lithium salt solutions. The system can be integrated with existing crystallization or drying units to form a complete production line. We also offer pilot-scale testing and on-site commissioning support to ensure seamless integration.
Trust & Reliability: As a company with an annual export value of US$10–50 million and a workforce of 201–300 skilled employees, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has supplied equipment to over 30 countries across North America, Europe, Asia, and Oceania. Our factory is certified under ISO9001, ISO14000, OHSAS18001, and other management systems, reflecting our commitment to quality and safety. With a dedicated R&D team and a 24/7 after-sales service network, we ensure your production goals are met efficiently.
Choose our Industrial MVR Evaporator for Lithium Salt to achieve sustainable, cost-effective evaporation. Contact us today for a tailored quotation or to schedule a technical consultation.
Frequently Asked Questions (FAQ)
-
Q: What is the typical energy saving compared to multi-effect evaporators?
A: Our MVR evaporator can reduce energy consumption by 60–70% because it reuses vapor latent heat, requiring only a small amount of electricity for the compressor. -
Q: Can this evaporator handle lithium salt solutions with high viscosity or scaling tendency?
A: Yes, the design includes forced circulation options to prevent scaling and handle viscous solutions. Material selection (SS316L) also minimizes corrosion and scaling. -
Q: What is the required floor space for the 1000 kg/h unit?
A: The exact footprint depends on the configuration (e.g., with or without pre-heater, separator). Typically, the skid dimensions are around 8m × 3m × 4m, but we can customize to fit your layout. -
Q: Is the IP55 enclosure suitable for outdoor installation?
A: Yes, IP55 provides protection against dust ingress and water jets from any direction, making it suitable for sheltered outdoor use. For extreme weather, additional weatherproofing can be added. -
Q: How often does the compressor require maintenance?
A: The compressor is designed for long-life operation. Routine inspections every 6 months and oil changes every 2,000 operating hours are recommended. Detailed maintenance schedule is provided in the manual. -
Q: Can you customize the evaporator to handle a different capacity or voltage?
A: Absolutely. We offer customization for evaporation capacity (from 200 kg/h to 10,000 kg/h), voltage (380V, 440V, 480V, etc.), and frequency (50Hz/60Hz). Please provide your requirements for a tailored solution. -
Q: What after-sales support do you provide?
A: We offer remote technical support, on-site commissioning, training, and a 12-month warranty. Spare parts are available from our warehouse in Qingdao. Our global service network ensures quick response. -
Q: Does your company have experience in the lithium battery industry?
A: Yes, we have supplied MVR evaporators for lithium salt producers in China and abroad, supporting the growing lithium battery supply chain. Our team understands the specific process requirements.
