Help CenterIndustrial Evaporator for Sodium Chloride for Food Grade Brine Concentration
Product Spotlights
Related Products
-
Automatic Forced Circulation Evaporator for Sodium Chloride, 1000L/h CapacityUS$ 5480 - 859000MOQ: 1 Combo -
Evaporator for Sodium Chloride Used in Pharmaceutical Industry, CIP CompatibleUS$ 5480 - 859000MOQ: 1 Combo
-
304 Stainless Steel MVR Evaporator for Sodium Chloride, 220V 50Hz PLC ControlUS$ 5480 - 859000MOQ: 1 Combo
-
Evaporator for Sodium Chloride With 1-Year Warranty and Mill Test Report IncludedUS$ 5480 - 859000MOQ: 1 Combo
-
Steam Heating Evaporator for Sodium Chloride, 500kg/h, Double Effect DesignUS$ 5480 - 859000MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – your trusted partner in industrial evaporation solutions. As a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and an annual export value exceeding US$10 million, we specialize in designing and producing high-performance Industrial Evaporators for Sodium Chloride tailored for food-grade brine concentration. Our evaporator systems are engineered to deliver exceptional efficiency, purity, and reliability, ensuring your brine concentration process meets the highest standards of food safety and operational excellence.
Our team of over 200 skilled professionals combines decades of expertise in environmental technology and process engineering. The Industrial Evaporator for Sodium Chloride (Food Grade) is a result of rigorous R&D and field-tested performance, designed to handle challenging brine streams while maintaining product quality. Whether you are concentrating brine for table salt production, industrial salt recovery, or food processing applications, our evaporator offers a robust and energy-efficient solution.
Below, we detail the key features, technical specifications, and benefits that make this evaporator the ideal choice for your brine concentration needs.
Key Features & Technical Specifications
- High-Efficiency Evaporation: Utilizes forced circulation or falling film design (optional) to maximize heat transfer and minimize energy consumption. Achieves concentration levels up to 25%–35% NaCl (depending on feed conditions).
- Food-Grade Materials: Constructed from Stainless Steel 316L (or 304 upon request) to ensure corrosion resistance and meet hygiene standards for food-grade applications. All product contact surfaces are polished to Ra ≤ 0.8 μm.
- Automatic Control System: Equipped with a PLC-based controller and touch-screen interface, allowing precise monitoring of temperature, pressure, flow rate, and concentration. Real-time data logging and remote access available.
- Energy Recovery Option: Optional mechanical vapor recompression (MVR) or thermal vapor recompression (TVR) can reduce steam consumption by up to 50%–70%, lowering operational costs significantly.
- Compact & Modular Design: Skid-mounted for easy installation and integration into existing production lines. Footprint optimized for limited floor space.
- Anti-Scaling & Fouling: Special design features such as recirculation loops and periodic cleaning cycles prevent salt crystallization on heat transfer surfaces, ensuring long-term stable operation.
- Compliance with International Standards: Manufactured under ISO9001, HACCP, QS9000, and other quality management systems, ensuring consistent product quality and safety.
| Parameter | Specification |
| Evaporation Capacity (kg/h) | 500 – 10,000 (customizable) |
| Feed Brine Concentration (NaCl %) | 5% – 15% |
| Final Concentration (NaCl %) | Up to 30% (saturation limit adjustable) |
| Operating Temperature (°C) | 60 – 120 |
| Steam Consumption (kg steam/kg water evaporated) | 0.4 – 0.8 (with MVR/TVR) |
| Power Supply | 380V/50Hz or customized |
| Control System | PLC + HMI touch screen |
| Material of Construction | Stainless Steel 316L / 304 |
| Certification | ISO9001, HACCP, QS9000, etc. |
Advantages & Customer Benefits
- Superior Product Purity: The gentle evaporation process and high-quality stainless steel construction ensure that your final concentrated brine remains free from contaminants, meeting strict food-grade standards.
- Reduced Energy Costs: With optional MVR/TVR technology, our evaporator dramatically lowers steam consumption, translating into significant savings on utility bills. Typical payback period is under 18 months.
- Minimal Downtime: Anti-scaling design and automated cleaning cycles (CIP) reduce maintenance frequency. The system also features self-diagnostic capabilities to alert operators before issues arise.
- Scalable & Flexible: Whether you need a small pilot unit or a large industrial system, we offer modular designs that can be expanded or modified as your production grows.
- Environmentally Friendly: By concentrating brine rather than discarding it, you reduce waste volume and can recover valuable salt for reuse, supporting circular economy goals.
- Global Support & Spare Parts: As an established exporter (annual export value US$10–50 million), we provide quick delivery of spare parts and on-site technical support worldwide. Our main markets include North America, Europe, Southeast Asia, and more.
Trust in Qingdao Conqinphi Environmental Technology Group Co., Ltd. With over 200 employees, a 10,000–30,000 m² factory, and multiple certifications including HACCP, TL900, QS9000, SA8000, ISO9001, ISO14000, and others, we are committed to delivering superior quality and reliability. Our products have been shipped to major markets across the globe, and we have a proven track record of customer satisfaction. We invite you to partner with us for your brine concentration needs. Contact our team today for a customized solution that will boost your production efficiency and product quality.
Ready to optimize your food-grade brine concentration process? Request a quote or technical consultation now. Our engineers will work closely with you to design an evaporator that meets your exact specifications, backed by our comprehensive warranty and after-sales service.
Frequently Asked Questions
-
Q: What is the typical lifespan of your Industrial Evaporator for Sodium Chloride?
A: With proper maintenance and routine cleaning, the evaporator can operate reliably for 15–20 years. Our stainless steel construction and anti-scaling features help extend service life. -
Q: Can you handle brine with impurities or other salts?
A: Yes, our evaporator is designed for brine containing sodium chloride, but it can also handle other dissolved salts. Please provide a detailed water analysis, and we will customize the system accordingly. -
Q: What is the minimum order quantity (MOQ)?
A: For standard models, MOQ is 1 set. Customized systems may have a higher MOQ depending on complexity. We are flexible to meet your project needs. -
Q: Do you offer installation and commissioning services?
A: Yes, we provide on-site installation supervision and commissioning support. Our technical team can travel to your site or offer remote guidance via video call. -
Q: What certifications does your evaporator have?
A: Our manufacturing facility is certified under ISO9001, HACCP, QS9000, SA8000, and others. The evaporator can be designed to meet CE, ASME, or other international standards upon request. -
Q: How long is the delivery time?
A: Typically 30–60 days after order confirmation, depending on the specification and complexity of the system. Urgent orders can be expedited. -
Q: Does the evaporator require special foundation or utilities?
A: The skid-mounted design requires only a flat, level concrete floor. Utility connections include steam/heat source, cooling water, electrical power, and brine feed/outlet. We provide detailed installation drawings. -
Q: Can you provide after-sales spare parts and technical support?
A: Yes, we maintain a stock of common spare parts and can ship them worldwide. Our after-sales team is available 24/7 for troubleshooting and support.
