Product Overview
As a leading manufacturer based in Hengshui, Hebei, China, Anping County Boli Hardware Wiremesh Products Factory has been dedicated to the production of high-quality wire mesh since 1998. Our 316L Stainless Steel Crimp Wire Mesh with 0.5mm wire diameter and 2mm mesh opening is engineered for demanding industrial applications where corrosion resistance, dimensional stability, and long service life are critical. With annual export value reaching US$5-10 million and shipments to global markets including North America, Europe, and Southeast Asia, we offer a product that combines precision manufacturing with competitive pricing.
Key Features & Technical Specifications
- Superior Corrosion Resistance: 316L stainless steel contains molybdenum, providing enhanced resistance to chlorides, acids, and harsh chemical environments – ideal for marine, chemical processing, and food-grade applications.
- Precise Mesh Opening: 2mm (±0.05mm) square opening ensures consistent particle retention and flow control. The crimp weave locks wires in place, preventing shifting under load.
- 0.5mm Wire Diameter: Balanced strength and flexibility. Thin enough for fine filtration yet robust for mechanical support in screens and guards.
- Industrial Grade Quality: Manufactured from prime 316L stainless steel wire, cold-drawn to exact tolerances. Each roll is inspected for surface defects, corrosion spots, and weave uniformity.
- Customizable Dimensions: Standard width: 1m (other widths available on request). Standard length: 30m per roll. Custom lengths, slit widths, and edge treatments (buckled, welded, or knuckled) are offered.
| Specification | Value | Tolerance |
| Material | 316L Stainless Steel | - |
| Wire Diameter | 0.5 mm | ±0.01 mm |
| Mesh Opening (Aperture) | 2 mm | ±0.05 mm |
| Open Area | ~64% | - |
| Weave Type | Intermediate Crimp | - |
| Standard Width | 1 m | ±5 mm |
| Standard Length | 30 m | ±0.3 m |
| Tensile Strength (approx.) | 490–690 MPa | - |
Advantages & Customer Benefits
- Long Service Life: 316L’s low carbon content minimizes carbide precipitation during welding, maintaining corrosion resistance in welded joints – fewer replacements, lower total cost of ownership.
- Consistent Flow & Filtration: The precise 2mm opening and rigid crimp structure ensure uniform particle size separation, reducing downtime caused by blinding or tearing.
- Versatile Applications: Suitable for chemical filtering, oil & gas separation, mining screens, architectural facades, animal enclosures, and safety guards. The mesh can be cut, bent, or welded without losing integrity.
- Easy Cleaning & Hygiene: Smooth surface and non-porous material allow easy washing, making it ideal for food processing, pharmaceutical, and cleanroom environments.
- Global Shipping Options: We ship from Tianjin, Qingdao, Shanghai, and Foshan ports. Flexible packaging: rolls wrapped in kraft paper, water-proof film, or wooden crates for export.
Quality Assurance & Trust
For over 25 years, Anping County Boli Hardware Wiremesh Products Factory has served customers across North America, South America, Europe, Asia, Africa, and Oceania. Our annual export value of US$5-10 million reflects the trust placed in our products. We implement strict incoming raw material inspection, in-process weave monitoring, and final roll inspection. Each roll is labeled with batch number, weight, and dimensions for full traceability. Our experienced team can provide technical support for selecting the correct mesh specification for your project. We welcome OEM/ODM enquiries and offer small trial orders for qualification.
Frequently Asked Questions
-
Q: Is this mesh suitable for seawater exposure?
A: Yes, 316L stainless steel offers excellent resistance to chloride-induced corrosion, making it suitable for marine environments. However, for long-term immersion, periodic cleaning is recommended. -
Q: Can the mesh be cut to smaller sizes?
A: Absolutely. The mesh can be cut with standard shear, nibbler, or plasma cutter. We can also supply pre-cut panels or strips upon request. -
Q: What is the maximum temperature this mesh can withstand?
A: 316L can be used continuously up to 800°C in oxidizing environments, but mechanical properties decrease above 500°C. For high-temperature applications, please consult our technical team. -
Q: How is the mesh packaged for export?
A: Standard packaging: rolls wrapped in plastic film and kraft paper, then secured with straps. For fragile or large orders, we use plywood crates or pallets. Custom packaging is available. -
Q: What is the lead time for standard rolls?
A: For standard width (1m) and length (30m), lead time is typically 7–15 working days after order confirmation. For custom sizes, please allow 15–25 working days. -
Q: Do you provide samples before bulk order?
A: Yes, we offer free samples (within reasonable size) with freight collect. Once you confirm the quality, we proceed with mass production. -
Q: Can you supply this mesh with a different wire diameter?
A: We can customize wire diameter and mesh opening within our production capability. Please contact us with your specific requirements.
Why Choose Anping Boli
With a factory established in 1998 and a dedicated export team, we have the experience to deliver consistent quality. Our 316L stainless steel crimp wire mesh is manufactured using advanced weaving looms and strict quality control. We are a reliable partner for distributors, OEMs, and end-users worldwide. Contact us today for a quotation or to discuss your project – we speak your language and understand your industrial needs.
