Anping Xinye Metal Wire Mesh Products Co., Ltd, located in Hengshui, Hebei, China, specializes in manufacturing high-quality woven wire mesh for industrial applications. Our Plain Weave Woven Wire Mesh with 0.8mm wire diameter and 4x4mm mesh opening is designed to meet ASTM standards, ensuring reliable performance in demanding screening and filtration environments. This product combines precision weaving with durable materials to deliver consistent particle separation and long service life.
The mesh is produced using advanced looms and strict quality control processes, resulting in uniform openings and strong tensile strength. Whether you need it for mineral processing, chemical filtration, or construction aggregate screening, this mesh offers excellent dimensional stability and resistance to wear. Our factory can customize the mesh size, wire gauge, and material to match your specific requirements, while maintaining full ASTM compliance.
Key Features & Technical Specifications
- Precise Mesh Opening: 4mm x 4mm square openings ensure accurate particle size classification.
- 0.8mm Wire Diameter: Provides optimal balance between strength and open area for efficient flow.
- Plain Weave Construction: Each wire passes alternately over and under the perpendicular wires, creating a tight, stable structure.
- ASTM Standard Compliance: Manufactured according to ASTM E11 / AASHTO M-92 specifications for woven wire test sieves and industrial screens.
- Multiple Material Options: Available in stainless steel (304, 316), galvanized steel, or low-carbon steel to suit different environments.
- Customizable Surface Treatment: Mill finish, hot-dip galvanized, or PVC coating for corrosion resistance.
- High Tensile Strength: Withstands heavy loads and repeated impact in vibrating screens.
- Uniform Open Area: Consistent wire spacing ensures reliable screening results batch after batch.
| Parameter | Value |
| Mesh Count | Approx. 4.8 mesh per inch (based on 0.8mm wire) |
| Open Area | Approx. 64% (calculated for 4mm opening using 0.8mm wire) |
| Wire Tolerance | ±0.02mm |
| Mesh Opening Tolerance | ±0.1mm (compliant with ASTM E11) |
| Standard Roll Width | 1m, 1.2m, 1.5m (customizable) |
| Standard Roll Length | 30m, 50m (custom lengths available) |
Benefits for Industrial Screening
- Accurate Separation: The 4x4mm opening is ideal for classifying materials in the 4mm range, such as gravel, sand, coal, or recycled aggregates.
- Reduced Blinding: Plain weave with adequate wire diameter minimizes particle wedging and clogging.
- Long Service Life: Durable materials resist abrasion and corrosion, reducing replacement frequency.
- Cost-Effective: Competitive pricing without compromising on quality, thanks to our efficient manufacturing in Hebei.
- Easy Installation: Flexible mesh can be cut and tensioned on standard screening equipment.
Anping Xinye Metal Wire Mesh Products Co., Ltd has been a trusted supplier in the wire mesh industry, serving clients in mining, construction, chemical, and food processing sectors. Our factory in Hengshui, Hebei, is equipped with modern weaving machines and a dedicated quality control team. We have exported large quantities of woven wire mesh to markets across North America, Europe, and Southeast Asia, consistently meeting ASTM standards. Our commitment to on-time delivery and customer support ensures that your industrial screening operations run smoothly.
We invite you to request a quote or sample to test the mesh in your application. Our technical team can assist with selecting the correct material and surface treatment for your specific environment. Contact us today to discuss your project requirements and experience the reliability of Anping Xinye woven wire mesh.
Frequently Asked Questions
-
What materials are available for this mesh?
We offer stainless steel (304, 316), galvanized steel, and low-carbon steel. For corrosive environments, we recommend stainless steel or PVC-coated mesh. -
Is the mesh cut to size or sold in rolls?
We supply standard rolls (1m x 30m, 1.2m x 50m) and can also cut to custom sizes or provide pre-cut panels upon request. -
What is the exact tolerance for the mesh opening?
Our mesh opening tolerance is ±0.1mm, fully compliant with ASTM E11 requirements for industrial sieves. -
Can this mesh be used for high-temperature applications?
Stainless steel 316 mesh can withstand temperatures up to 800°C under oxidizing conditions. For lower temperature environments, galvanized or low-carbon steel is suitable. -
Do you provide samples before bulk order?
Yes, we can provide A4-sized samples free of charge, with the buyer paying shipping. Contact our sales team for sample requests. -
How long does production take for a standard roll?
For standard specifications, production takes 7–10 working days. Custom orders may require 15–20 working days depending on quantity. -
What packaging do you use for export?
We use strong wooden pallets or steel-framed crates, with waterproof wrapping to protect the mesh during ocean freight. -
Is this mesh suitable for fine screening of powders?
For 4mm opening, it is best for coarse to medium particle sizes. For finer powders, we recommend smaller mesh openings (e.g., 0.5mm or 1mm).
