Hemaokang Steel (Shandong) Co., Ltd. is a professional manufacturer and exporter of high-quality carbon steel plates, established in 2025 with an annual export value of US$50–100 million. Our ASTM A36 / S235JR carbon steel plates are specifically designed for pressure vessel and boiler manufacturing, offering reliable mechanical properties and excellent weldability. With ISO9001 certification and a dedicated team of 51–100 employees, we ensure every plate meets international standards, backed by a 1-year warranty for your peace of mind.
Product Overview
Our carbon steel plate conforms to ASTM A36 and S235JR specifications, widely used in pressure vessels, boilers, storage tanks, and structural components. The material offers a balanced combination of strength, ductility, and toughness, making it suitable for forming, welding, and machining operations. Available in a wide range of thicknesses (2mm–200mm), widths (1000mm–3000mm), and lengths (2000mm–12000mm), we can also customize dimensions upon request to meet your specific project requirements.
| Parameter | ASTM A36 | S235JR |
|---|---|---|
| Yield Strength (min) | 250 MPa | 235 MPa |
| Tensile Strength | 400–550 MPa | 360–510 MPa |
| Elongation | ≥20% | ≥24% |
| Thickness Range | 2–200 mm | 2–200 mm |
| Standard | ASTM A36 | EN 10025-2 |
| Application | Pressure vessel, boiler, structural | Pressure vessel, boiler, general engineering |
Key Features and Benefits
- Superior Weldability: Low carbon content ensures excellent weldability without preheating for most thicknesses, reducing fabrication time and cost.
- High Toughness and Ductility: Suitable for cold forming, bending, and flanging operations, ideal for complex pressure vessel shapes.
- Consistent Mechanical Properties: Strict quality control from raw material to finished plate guarantees uniform strength and hardness across the entire batch.
- Corrosion Resistance Options: Surface treatments such as black oxide, galvanizing, or painting are available to enhance durability in harsh environments.
- Custom Sizing: We offer cutting, drilling, and edge preparation services according to your drawings, minimizing waste and secondary processing.
- 1-Year Warranty: All plates are covered against manufacturing defects, giving you confidence in long-term performance.
Quality Assurance
Our production facility is ISO9001:2015 certified, and each plate undergoes rigorous testing including chemical analysis, mechanical testing, and ultrasonic inspection (optional). The plates are packaged with steel straps, waterproof paper, or wooden pallets to prevent damage during transit. We have shipped to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, serving clients in boiler manufacturing, petrochemical, and construction industries.
Why Choose Hemaokang Steel?
- Established in 2025 with rapid growth, we already export US$50–100 million annually.
- Dedicated team of 51–100 experienced professionals ensures quick response and reliable service.
- ISO9001 certification guarantees consistent quality management.
- Strategic location in Liaocheng, Shandong, provides convenient access to major ports.
- Flexible payment terms and competitive pricing for bulk orders.
Trusted by Global Markets
Our plates are used in pressure vessels, boilers, heat exchangers, and storage tanks across diverse industries. With a 1-year warranty and after-sales technical support, we are committed to your satisfaction. Contact us today for a quotation or sample testing – experience the Hemaokang difference.
Frequently Asked Questions (FAQ)
-
What is the difference between ASTM A36 and S235JR?
ASTM A36 is an American standard with minimum yield strength 250 MPa, while S235JR is a European standard (EN 10025-2) with minimum yield 235 MPa. Both are suitable for pressure vessel and boiler manufacturing, but A36 is more common in North America, and S235JR in Europe. Our plates can be supplied in either specification. -
Can these plates be used for high-temperature boiler applications?
Both grades are designed for general structural and pressure vessel use at ambient to moderate temperatures. For high-temperature service (above 400°C), we recommend consulting our technical team for alternative materials like heat-resistant alloy steels. -
What thickness tolerances do you offer?
We follow ASTM A36/A6M and EN 10029 tolerances. Typical thickness tolerance ranges from ±0.25mm for thin plates to ±1.5mm for thicker plates. Exact tolerances depend on thickness and width; please provide your requirements for a detailed quote. -
Do you offer third-party inspection and certification?
Yes, we can arrange third-party inspection by SGS, BV, or other accredited agencies at an additional cost. Mill test certificates (MTC) are provided free of charge with each shipment. -
What is the minimum order quantity (MOQ)?
Our MOQ is 5 tons for standard sizes. For custom dimensions or special surface treatments, MOQ may be higher. Contact our sales team for flexible options. -
How is the plate packaged for export?
Plates are bundled with steel straps, wrapped in waterproof paper, and packed on wooden pallets or steel frames. For sea freight, we also use anti-rust oil and VCI paper to prevent corrosion during transit. -
What is the lead time for production?
For standard sizes in stock, we can ship within 7–15 days. For custom orders, lead time is typically 20–30 days depending on quantity and specifications. -
Does the 1-year warranty cover all defects?
The warranty covers manufacturing defects such as lamination, inclusions, or chemical composition deviations. It does not cover damage caused by improper handling, storage, or use beyond the recommended parameters.
