Help CenterGalvanized Barbed Wire 2.5mm Diameter 80mm Spacing 500m Coil High Tensile Strength ISO Standard Compliant
Product Spotlights
Related Products
-
304 Stainless Steel Barbed Wire 1.8mm Diameter 4-Point 50m Coil Rust Proof Security FenceNegotiableMOQ: 50 Cubic Centimeters -
Electro Galvanized Barbed Wire 2.2mm Diameter 75mm Spacing 400m Roll ASTM Standard CompliantNegotiableMOQ: 50 Cubic Centimeters
-
Double Twist Barbed Wire 2.8mm Galvanized, 4-inch Barb Spacing, 500m Coil, 0.5mm Zinc CoatingNegotiableMOQ: 50 Cubic Centimeters
-
Heavy Duty Barbed Wire for Farm Perimeter Security 2.5mm Galvanized 500m RollNegotiableMOQ: 50 Cubic Centimeters
-
Barbed Wire 3.0mm Thick 4-Inch Spacing 1000m Coil Double Twist Welded Mesh FencingNegotiableMOQ: 50 Cubic Centimeters
Anping Xinye Metal Wire Mesh Products Co., Ltd is proud to present our premium Galvanized Barbed Wire with a diameter of 2.5mm, 80mm barb spacing, and 500 meters per coil. Manufactured in our facility in Hengshui, Hebei, China, this high tensile strength barbed wire is designed to provide reliable perimeter security and fencing solutions for demanding environments. Each coil is produced under strict ISO standard compliance, ensuring consistent quality and durability. Whether you need to secure a construction site, farm, or military installation, our barbed wire offers the perfect balance of strength, corrosion resistance, and cost-effectiveness.
Key Features & Technical Specifications
- Wire Diameter: 2.5mm ± 0.05mm – offers excellent rigidity and resistance to cutting.
- Barb Spacing: 80mm (standard) – optional 100mm, 120mm available upon request.
- Coil Length: 500 meters per roll – reduces splicing and installation time.
- Tensile Strength: High tensile (≥450 N/mm²) – withstands heavy loads and harsh weather.
- Galvanization: Hot-dip galvanized (zinc coating ≥ 60 g/m²) – superior corrosion resistance for outdoor use.
- Barb Type: 2-point or 4-point barbed – customizable for different security levels.
- Standard Compliance: Manufactured in accordance with ISO 9001 quality management system (ISO standard compliant).
- Packaging: Each coil is wrapped in waterproof paper and polypropylene woven bag for safe transport.
Technical Parameters Table
| Parameter | Value |
|---|---|
| Wire Diameter | 2.5 mm |
| Barb Spacing | 80 mm |
| Coil Length | 500 m |
| Tensile Strength | ≥ 450 N/mm² |
| Zinc Coating | ≥ 60 g/m² |
| Barb Type | 2-point / 4-point (customizable) |
| Standard | ISO Compliant |
Product Advantages & Customer Benefits
Our galvanized barbed wire offers several tangible benefits for buyers:
- Long Service Life: The heavy zinc coating resists rust and corrosion, making it suitable for coastal and humid environments.
- Easy Installation: 500m continuous coil minimizes joints and reduces labor costs. The wire is flexible yet strong, allowing quick tensioning.
- High Security: Sharp barbs at 80mm spacing create a formidable barrier against intruders and animals.
- Consistent Quality: ISO-compliant production ensures uniform diameter, spacing, and galvanization across every meter.
- Cost-Effective: Bulk coil packaging reduces per-meter cost and transportation expenses.
Company Trust & Quality Assurance
Based in Anping, Hebei – the renowned 'Wire Mesh Capital of China' – Anping Xinye Metal Wire Mesh Products Co., Ltd has been a trusted manufacturer and exporter of wire mesh products for over a decade. Our factory operates with advanced drawing and galvanizing lines, and we implement strict quality control at every stage: from raw material selection to final packaging. With an annual output exceeding 5000 tons, we serve clients in more than 30 countries including the USA, Australia, Middle East, and Africa. Our commitment to ISO standard compliance and competitive pricing has earned us long-term partnerships with contractors, government agencies, and distributors worldwide.
We invite you to experience the reliability of our galvanized barbed wire. Contact us today for a quotation or free sample. Our team is ready to support your project with tailored solutions and fast delivery.
Frequently Asked Questions
Q1: What does the ISO standard compliance mean for this barbed wire?
A1: Our barbed wire is manufactured under a quality management system that meets ISO requirements. This ensures consistent product dimensions, uniform galvanization, and reliable tensile strength. However, we do not have specific ISO product certification – the compliance refers to our production process control.
Q2: Can I get different barb spacing like 100mm or 120mm?
A2: Yes, we offer customizable barb spacing. The standard 80mm spacing is in stock, but 100mm and 120mm spacing are available upon request with a minimum order quantity.
Q3: Is the wire suitable for saltwater or coastal areas?
A3: The hot-dip galvanized coating provides good corrosion resistance for most outdoor environments. For extremely corrosive coastal or industrial areas, we recommend a heavier zinc coating (≥80 g/m²) or PVC-coated barbed wire, which we can supply as a custom option.
Q4: What is the weight of one 500m coil?
A4: Approximate weight for 2.5mm diameter wire with 80mm spacing is around 22–25 kg per coil, depending on the barb type. Exact weight can be provided on the packing list.
Q5: How is the barbed wire packed for export?
A5: Each coil is wrapped in waterproof kraft paper, secured with polypropylene woven bag, and then palletized or bundled with steel straps. For sea freight, we also use fumigation-free wooden pallets upon request.
Q6: Can I order a sample before bulk purchase?
A6: Yes, we offer free samples (1–2 meters) for evaluation. The customer only pays for shipping. Contact our sales team to arrange a sample.
Q7: What is the minimum order quantity (MOQ)?
A7: For standard specification (2.5mm, 80mm spacing, 500m), the MOQ is 50 coils. For customized specifications, MOQ may be higher. Please inquire for details.
Q8: Is the wire available in other diameters like 2.0mm or 3.0mm?
A8: Yes, we produce barbed wire with diameters ranging from 1.8mm to 3.5mm. Please specify your requirement when placing an order.
