Help CenterPVC Coated Woven Wire Mesh 0.8mm Wire Diameter 6mm x 6mm Opening Plain Weave 1m Width 30m Length
Product Spotlights
Related Products
-
304 Stainless Steel Woven Wire Mesh 0.5mm Wire Diameter 2mm x 2mm Opening Plain Weave 1m WidthNegotiableMOQ: 50 Cubic Centimeters -
Woven Wire Mesh for Aggregate Sieving 304 Stainless Steel 2mm x 2mm Opening 0.5mm Wire Diameter Industrial GradeNegotiableMOQ: 50 Cubic Centimeters
-
316 Stainless Steel Woven Wire Mesh 1.0mm Wire Diameter 1/2 Inch x 1/2 Inch Opening Twill Weave 30m RollNegotiableMOQ: 50 Cubic Centimeters
-
Twill Weave Woven Wire Mesh 1.5mm Wire Diameter 10mm x 10mm Opening Galvanized 1.2m Width 30m LengthNegotiableMOQ: 50 Cubic Centimeters
-
Plain Weave Woven Wire Mesh 0.3mm Wire Diameter 0.5mm x 0.5mm Opening 304 Stainless Steel 1.0m WidthNegotiableMOQ: 50 Cubic Centimeters
Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is a trusted manufacturer specializing in high-quality wire mesh solutions. Our PVC Coated Woven Wire Mesh with 0.8mm wire diameter, 6mm x 6mm opening, plain weave, 1m width, and 30m length is designed to offer superior durability, corrosion resistance, and versatility for a wide range of applications. Whether you need fencing for agriculture, protection for gardens, or screening for industrial use, this mesh provides reliable performance at an economical cost.
This product features a robust PVC coating applied over galvanized steel wire, ensuring long-lasting protection against rust, UV rays, and weather extremes. The 6mm x 6mm square opening is ideal for small animal enclosures, debris fencing, and light sieving. With a 0.8mm wire diameter, the mesh maintains a good balance of strength and flexibility, making it easy to cut and install. Each roll is 1 meter wide and 30 meters long, providing ample coverage for medium-sized projects.
Key Features & Technical Specifications
- Material: Galvanized mild steel wire with PVC coating (peel-resistant).
- Wire Diameter: 0.8 mm (±0.05 mm tolerance).
- Opening Size: 6 mm x 6 mm (center to center).
- Weave Style: Plain weave – stable and uniform mesh.
- Width: 1 m (can be slit to custom widths upon request).
- Length: 30 m per roll (other lengths available).
- PVC Coating Color: Green, black, gray, or custom colors (minimum order quantity applies).
- Operating Temperature: -20°C to 60°C (for PVC coating).
| Parameter | Value |
|---|---|
| Mesh Count (per inch) | Approximately 4.2 x 4.2 |
| Open Area | Approx. 78% |
| Weight per Roll | Approx. 10–12 kg (depending on coating thickness) |
| Tensile Strength (wire) | 350–500 N/mm² (core wire) |
| PVC Coating Thickness | 0.2–0.4 mm (optional range) |
Advantages & Benefits for Customers
Our PVC coated woven mesh offers a compelling combination of affordability, ease of handling, and long service life. The PVC layer protects the steel core from moisture and chemicals, making it suitable for outdoor use without frequent maintenance. Unlike bare galvanized mesh, the PVC coating reduces glare and provides a more aesthetic finish.
- Corrosion Resistance: PVC coating prevents rust, even in humid or coastal environments.
- Flexibility: The 0.8mm wire diameter allows easy cutting and shaping for custom applications.
- Safe Edges: Smooth PVC coating reduces risk of injury compared to bare wire.
- Versatile Use: Ideal for chicken coops, rabbit hutches, garden fencing, vine trellises, and industrial filtering.
- UV Stability: The PVC formulation includes UV stabilizers for prolonged outdoor exposure.
- Economical: Lower cost than stainless steel or fully welded mesh for similar applications.
Trust & Reliability from Anping Xinye
As a leading manufacturer in Anping, Hebei – the wire mesh capital of China – Anping Xinye Metal Wire Mesh Products Co., Ltd has been supplying quality mesh products to global markets for years. We maintain strict quality control on every roll, ensuring consistent wire diameter, even coating, and accurate opening size. Our production capacity allows us to fulfill large orders while maintaining competitive pricing. We offer customizable options such as different widths, lengths, colors, and even PVC hardness. For detailed specifications, please contact our sales team – we are ready to provide samples and technical support.
Why choose us? Located in the industrial hub of Hengshui, we have direct access to raw materials, skilled labor, and efficient logistics. Our experienced team can guide you to the exact mesh specification for your project. We welcome inquiries for bulk orders, OEM packing, and drop-shipping arrangements. Contact us today to get a quote or request a free sample roll.
Frequently Asked Questions (FAQ)
-
Q: Can this mesh be used for saltwater environments?
A: While the PVC coating offers good resistance, prolonged exposure to saltwater may eventually degrade the coating. For marine applications, we recommend using a thicker PVC coating or our stainless steel mesh. -
Q: What is the temperature resistance of the PVC coating?
A: The PVC coating is suitable for temperatures from -20°C to 60°C. Avoid prolonged exposure to extreme heat above 80°C. -
Q: Can I order different widths or lengths?
A: Yes, we can customize the width from 0.5m to 2m and length up to 50m per roll, subject to minimum order quantities. -
Q: How is the mesh packaged for shipping?
A: Each roll is wrapped in protective plastic film and then in woven bags or cartons to prevent damage during transport. -
Q: Is the PVC coating food-safe?
A: The standard PVC coating is not certified for direct food contact. For food-grade applications, please inquire about our special coating options. -
Q: Can I get a sample before placing a bulk order?
A: Yes, we offer free samples (up to 1 square meter) for customer evaluation, with shipping cost covered by the buyer. -
Q: What is the typical lead time for a 30m roll?
A: For standard colors and sizes, lead time is 7–15 days after order confirmation. Custom colors may take longer. -
Q: How do I cut and install this mesh?
A: Use wire cutters or heavy-duty scissors. The mesh can be attached to wooden posts with staples or to metal frames with wire ties.
