As a professional manufacturer from Hemaokang Steel (Shandong) Co., Ltd., we are proud to offer our high-quality 5083 Aluminum Pipe in 6-meter lengths with a 60mm outer diameter and 5mm wall thickness. This marine-grade extruded pipe is specifically engineered to withstand the harshest saltwater environments, providing exceptional corrosion resistance and structural integrity for shipbuilding, offshore platforms, and marine applications. Our commitment to precision and durability ensures that every pipe meets rigorous quality standards, backed by our ISO9001 certified production processes.
The 5083 aluminum alloy is renowned for its superior strength-to-weight ratio and excellent weldability, making it the preferred choice for demanding marine projects. Each pipe is extruded to tight tolerances, ensuring consistent dimensions and reliable performance. Whether you are constructing a yacht, a commercial vessel, or an offshore structure, our 5083 aluminum pipe delivers the robust characteristics you need.
Key Features & Technical Specifications
- Alloy Grade: 5083 (Marine Grade) – High resistance to seawater corrosion.
- Length: 6 meters (19.7 feet) – ideal for large-scale fabrication, minimizing joints.
- Outer Diameter: 60 mm (2.36 inches) – standard size compatible with many fittings.
- Wall Thickness: 5 mm (0.197 inches) – provides excellent strength and rigidity.
- Manufacturing Process: Extruded – ensures uniform grain structure and precise dimensions.
- Surface Finish: Mill Finish – clean surface ready for welding or coating.
- Certification: ISO9001 – quality management system ensures consistent product quality.
- Applicable Standards: ASTM B221 / EN 755 (available upon request).
| Parameter | Value |
|---|---|
| Tensile Strength (MPa) | 290 – 340 |
| Yield Strength (MPa) | 145 – 200 |
| Elongation (%) | 12 – 18 |
| Density (g/cm³) | 2.66 |
| Corrosion Resistance | Excellent in marine environments |
| Weldability | Excellent (TIG, MIG, laser) |
Advantages & Customer Benefits
Choosing our 5083 aluminum pipe means investing in a product that offers:
- Long Service Life: The alloy’s natural oxide layer protects against pitting and stress corrosion cracking, even in splash zones.
- Weight Reduction: Approximately 35% lighter than steel, reducing structural load and fuel consumption in marine vessels.
- Easy Fabrication: Can be cut, drilled, bent, and welded with standard techniques, saving time and labor costs.
- Dimensional Consistency: Extrusion process ensures tight tolerances (±0.5mm on OD, ±0.2mm on wall), simplifying assembly.
- Eco-Friendly: 100% recyclable, supporting sustainability goals in the maritime industry.
Trust & Reliability
Hemaokang Steel (Shandong) Co., Ltd. has been serving global clients since 2025 with an annual export value of US$50-100 million. Our team of 51-100 experienced professionals ensures that every shipment meets the highest standards. We export to markets across North America, South America, Europe, Asia, Africa, and Oceania, building long-term partnerships through quality and service. Our ISO9001 certification reflects our dedication to continuous improvement and customer satisfaction.
We offer customized packaging, cutting to specific lengths, and additional surface treatments (e.g., anodizing) upon request. Contact us today to discuss your requirements or request a quote. Let our 5083 aluminum pipe be the foundation of your next marine project.
Frequently Asked Questions
Q1: Is the 5083 aluminum pipe suitable for use in saltwater?
A: Yes, 5083 is specifically designed for marine environments. It offers excellent resistance to seawater corrosion, including stress corrosion cracking, and is widely used in shipbuilding and offshore structures.
Q2: What are the mechanical properties of this pipe?
A: Typical tensile strength ranges from 290 to 340 MPa, yield strength from 145 to 200 MPa, and elongation between 12% and 18%. Exact values can be provided upon request with a mill test certificate.
Q3: Can I get the pipe cut to a custom length?
A: Absolutely. We offer cutting services to any length you need, subject to minimum order quantities. Please specify your requirements when placing an order.
Q4: What welding methods are recommended for this alloy?
A: 5083 aluminum has excellent weldability. TIG (GTAW) and MIG (GMAW) processes are commonly used. We recommend using ER5356 filler wire for optimal strength and corrosion resistance.
Q5: Does the pipe come with a mill finish? Can it be anodized?
A: The standard delivery is mill finish. Anodizing is available as an optional service to enhance corrosion resistance and appearance. Please contact us for details.
Q6: What certifications are provided with the product?
A: Each shipment can be accompanied by an ISO9001 certificate, mill test report, and, if required, third-party inspection reports. We can also provide material traceability documentation.
Q7: What is the tolerance on outer diameter and wall thickness?
A: Our extrusion process maintains tight tolerances: OD ±0.5mm, wall thickness ±0.2mm, and length +10mm/-0mm. Tighter tolerances are available upon request.
Q8: How is the pipe packaged for export?
A: Pipes are bundled with steel straps, wrapped in waterproof paper or plastic, and placed in wooden crates or pallets for sea freight. Custom packaging options are available.
