Help CenterPrecision Drawn Anodized Aluminum Tube 5052 Alloy 10mm ID 12mm OD 0.5mm Wall Smooth Surface
Product Spotlights
Related Products
-
Lightweight Anodized Aluminum Tube for Drone Frame 7075-T6 Seamless 20mm OD 1.5mm WallNegotiableMOQ: 1 Ton -
6063 Alloy Anodized Aluminum Tube Precision Extruded 15mm-17mm Diameter Threaded Holes Custom LengthNegotiableMOQ: 1 Ton
-
Anodized Aluminum Tube 6063 Alloy 1 Year Warranty Mill Test Report Provided Custom Sizes AvailableNegotiableMOQ: 1 Ton
-
7075 T6 Seamless Anodized Aluminum Tube 6mm Wall Thickness High Tensile Strength for Structural UseNegotiableMOQ: 1 Ton
-
Anodized Aluminum Tube for Decorative Handrails 6063 Alloy 15mm Diameter 3m Length Corrosion ResistantNegotiableMOQ: 1 Ton
Welcome to Hemaokang Steel (Shandong) Co., Ltd. – your trusted partner for high-quality aluminum solutions. Our Precision Drawn Anodized Aluminum Tube 5052 Alloy (10mm ID, 12mm OD, 0.5mm wall) is engineered to meet the most demanding industrial applications. With a newly established facility in 2025 and an annual export value exceeding US$50 million, we are committed to delivering precision and reliability. Every tube undergoes rigorous quality control, backed by our ISO9001 certification, ensuring consistent performance across global markets including North America, Europe, and Southeast Asia.
Key Features & Technical Specifications:
- Alloy 5052: Excellent corrosion resistance, high fatigue strength, and good weldability – ideal for marine, automotive, and aerospace components.
- Precision Drawn Process: Ensures tight dimensional tolerances and a smooth, uniform surface finish, reducing the need for secondary machining.
- Anodized Surface: Provides a hard, protective oxide layer that enhances wear resistance, improves aesthetics, and allows for optional color dyeing (customizable upon request).
- Dimensions: 10mm Inner Diameter, 12mm Outer Diameter, 0.5mm Wall Thickness – available in any cut length or coil form.
- Smooth Surface: Free of scratches, pits, or burrs, ensuring fluid flow efficiency and easy assembly.
| Parameter | Value |
| Alloy | 5052 (Al-Mg) |
| Temper | H32 / H34 (available) |
| Inner Diameter | 10.00 mm ±0.05 mm |
| Outer Diameter | 12.00 mm ±0.05 mm |
| Wall Thickness | 0.50 mm ±0.03 mm |
| Surface | Anodized, smooth, uniform |
| Length | Custom (1m – 6m standard, up to 12m on request) |
| Tensile Strength | ≥ 210 MPa (H32) |
Benefits to Your Business:
- Reduced Production Costs: Our precision drawn tubes eliminate extra processing steps – you get ready-to-use components with superior surface finish.
- Enhanced Product Lifespan: The anodized layer resists corrosion and wear, extending the service life of your final product in harsh environments.
- Design Flexibility: Available in various lengths and can be cut, bent, or welded easily. Custom anodizing colors (e.g., black, clear) are available upon request.
- Consistent Quality: Every batch is tested for dimensional accuracy and surface integrity. Our ISO9001 management system ensures traceability.
- Global Logistics: With an annual export value of US$50-100 million, we have established shipping networks to deliver to over 15 regions worldwide, including North America, South America, Europe, and Asia.
Why Choose Hemaokang Steel? Since our establishment in 2025, we have rapidly grown into a reliable supplier with 51-100 skilled employees. Our strict quality control and customer-centric approach have earned us a reputation in the global market. We hold ISO9001 certification, which guarantees that our manufacturing processes meet international standards. Our main markets span across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. We are dedicated to providing competitive pricing, fast delivery, and technical support. Whether you need a small sample or bulk orders, we are ready to serve you.
Frequently Asked Questions (FAQ):
- Q: What is the minimum order quantity (MOQ)? A: Our MOQ is 100 kg for standard sizes, but we can accommodate smaller trial orders for new customers.
- Q: Can you provide custom lengths or cut-to-size tubes? A: Yes, we offer custom cutting services. Please specify your required length when placing an order.
- Q: Is the anodized layer food-safe or suitable for medical applications? A: The 5052 alloy with anodized finish is generally considered safe for food contact and medical devices, but we recommend consulting with your local regulatory body for specific compliance.
- Q: How do you ensure the smooth surface without scratches? A: Our precision drawing process uses high-quality dies and lubricants, followed by careful handling and packaging. Each tube is individually wrapped to prevent damage during transit.
- Q: What is the typical lead time? A: For standard sizes, lead time is 7-15 working days. Custom orders may take 15-25 working days, depending on quantity.
- Q: Do you offer samples before bulk purchase? A: Yes, we provide free samples of up to 1 meter length (shipping cost covered by customer). Contact our sales team to arrange.
- Q: Can you provide a certificate of analysis (COA) or material test report? A: Absolutely. We provide a COA with each shipment, including chemical composition and mechanical properties, as part of our ISO9001 quality system.
- Q: What payment methods do you accept? A: We accept T/T, L/C, and other common international payment terms. Negotiable based on order value.
Conclusion: With our strong production capacity, ISO9001 certification, and a team of 51-100 professionals, Hemaokang Steel is your reliable partner for precision drawn anodized aluminum tubes. Our 5052 alloy tubes combine excellent mechanical properties with a smooth, anodized surface that adds value to your products. We serve a global customer base with annual exports exceeding US$50 million, and we are confident in our ability to meet your requirements. Contact us today for a quotation or to discuss your specific needs. Let us help you achieve success with high-quality aluminum tubing.
