Help Center304 Stainless Steel Plate | 2B Finish 1219x2438mm | Cold Rolled Sheet
Product Spotlights
18.0–20.0% Cr / 8.0–10.5% Ni composition for corrosion resistance
Cold-rolled + annealed + pickled 2B finish, semi-reflective smooth surface
Tensile strength ≥515 MPa / Yield ≥205 MPa / Elongation ≥40%
Hardness ≤201 HBW / ≤92 HRB
Standard 1219×2438mm (4′×8′), thickness 0.3–3.0mm available
Thickness tolerance per ASTM A480: ±0.05 to ±0.15mm
Mill edge or slit edge optional
Wide application: food processing, chemical equipment
Related Products
-
ASTM 304 Stainless Steel Sheet 2B Finish 2mm 1219x2438mm Mill Edge for Kitchen EquipmentUS$ 1.85 - 4.15MOQ: 100 Kilograms -
SUS304 Cold Rolled Stainless Sheet 1.5mm 1500x3000mm BA Surface Laser Cutting UseUS$ 1.85 - 4.15MOQ: 100 Kilograms
-
DIN 1.4301 Stainless Steel Plate 3mm 4x8ft No.4 Brushed Finish for Elevator PanelsUS$ 1.85 - 4.15MOQ: 100 Kilograms
-
EN X5CrNi18-10 Stainless Sheet 0.8mm 1000x2000mm 2B Surface Decorative ApplicationUS$ 1.85 - 4.15MOQ: 100 Kilograms
-
GB 06Cr19Ni10 Stainless Steel Plate 6mm 1500x6000mm Pickled Surface Tank FabricationUS$ 1.85 - 4.15MOQ: 100 Kilograms
AISI 304 Stainless Steel Plate 2B Finish Cold Rolled Sheet – ASTM A240
Product Introduction
The 304 Stainless Steel Plate with 2B finish is a cold-rolled austenitic stainless steel sheet manufactured in compliance with ASTM A240 / ASME SA-240 standards--. Grade 304, also known as 18/8 stainless steel, contains 18.0–20.0% chromium and 8.0–10.5% nickel, offering an optimal balance of corrosion resistance, formability, and weldability-. This product is supplied in the standard 1219×2438mm (4′×8′) sheet size with 2B finish—the most widely used stainless steel surface finish, achieved through cold rolling, annealing, pickling, and a final light cold-roll pass on polished rolls. Thickness ranges from 0.3mm to 3.0mm, with precision tolerances per ASTM A480.
Core Selling Points
1. Corrosion Resistance & Material Integrity
The 18.0–20.0% chromium content forms a protective passive oxide layer on the surface, while the 8.0–10.5% nickel content enhances overall corrosion resistance. This composition enables the material to withstand exposure to mildly acidic and alkaline environments, making it suitable for chemical, food processing, and marine-adjacent applications-. Carbon content is controlled at ≤0.08%, with 304L variants available with even lower carbon (≤0.03%) for welded applications requiring enhanced intergranular corrosion resistance.
2. Mechanical Performance & Formability
The material delivers tensile strength ≥515 MPa (typical range 515–720 MPa), yield strength (0.2% offset) ≥205 MPa, and elongation at break ≥40%. Hardness is maintained at ≤201 HBW or ≤92 HRB. The balanced austenitic structure enables severe deep drawing without intermediate annealing, a characteristic that has made Grade 304 dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware, and saucepans. The material is readily brake or roll formed into a variety of components for industrial, architectural, and transportation applications.
3. 2B Surface Finish – Functional & Cost-Effective
The 2B finish is the most economical stainless steel surface finish, offering a smooth, semi-reflective, matte-like appearance with minimal surface roughness. It has been chemically pickled, which enhances corrosion resistance, and the smooth surface facilitates cleaning and resists fingerprinting in commercial environments. The finish is more readily polished than No. 1 or No. 2D finishes if further surface refinement is required.
4. Dimensional Precision & Customization
Thickness tolerances per ASTM A480: 0.3–0.5mm: ±0.05mm; 0.5–1.0mm: ±0.07mm; 1.0–2.0mm: ±0.10mm; 2.0–3.0mm: ±0.15mm. Width tolerance: ±1.5mm for standard widths up to 1500mm; length tolerance: ±2.0mm for standard lengths up to 6000mm-28. Flatness: ≤3mm/m for sheets ≤1.5mm thickness. Custom sizes available upon request.
Applications & Industry Solutions
Food Processing Equipment – Used in brewing and winemaking equipment, kitchen benches, sinks, appliances, and food-grade workbenches. Meets food-grade standards, odorless and rust-free, suitable for direct food contact.
Chemical & Pharmaceutical Processing – Chemical containers, process vessels, tanks, and pharmaceutical processing equipment. The 2B finish provides a smooth, non-porous surface that resists chemical attack and facilitates sanitation.
Architectural & Construction – Architectural paneling, downpipes, gutters, and interior cladding. While not recommended for applications requiring exact finish uniformity, 2B is suitable for architectural installations where the finish will not be closely examined for uniformity.
Industrial Fabrication – Threaded fasteners, springs, automotive components, heat exchangers, and general industrial equipment. The material's weldability is outstanding—post-weld annealing is not required when welding thin sections.
HVAC & Refrigeration – Used in heat exchanger components and HVAC system fabrication due to its thermal conductivity (16.2 W/m·K) and thermal expansion characteristics.
Technical Specifications
| Parameter | Specification | Remarks |
|---|---|---|
| Material Grade | AISI 304 / UNS S30400 / EN 1.4301 / SUS 304 | Austenitic stainless steel-- |
| Standard | ASTM A240 / ASME SA-240 / ASTM A480 | Also meets AISI, JIS, EN, DIN, GB-11- |
| Surface Finish | 2B | Cold-rolled, annealed, pickled, light cold-roll pass-29 |
| Thickness | 0.3mm – 3.0mm | Custom thickness available-3 |
| Standard Size | 1219 × 2438mm (4′ × 8′) | Custom sizes: 1000×2000, 1500×3000, 2000×4000mm-3-11 |
| Width Range | 500 – 2000mm | Custom |
| Length Range | 1000 – 6000mm | Custom |
| Thickness Tolerance | Per ASTM A480: ±0.05 to ±0.15mm | Depends on thickness range |
| Width/Length Tolerance | Width ±1.5mm / Length ±2.0mm | For standard sizes up to 1500mm/6000mm |
| Flatness | ≤3mm/m | For sheets ≤1.5mm thickness |
| Edge Condition | Mill edge or slit edge | Optional |
| Chemical Composition | C ≤0.08%, Si ≤1.0%, Mn ≤2.0%, P ≤0.045%, S ≤0.03%, Cr 18.0–20.0%, Ni 8.0–10.5% | Per ASTM A240 |
| Tensile Strength | ≥515 MPa (typical 515–720 MPa) | / |
| Yield Strength (0.2%) | ≥205 MPa | / |
| Elongation | ≥40% | / |
| Hardness | ≤201 HBW / ≤92 HRB | / |
| Density | 7.93 g/cm³ (typical 8.0 g/cm³) | / |
| Melting Point | 1398 – 1454°C | / |
| Thermal Conductivity | 16.2 – 21.5 W/m·K (100–500°C) | / |
| Modulus of Elasticity | 193 KN/mm² | / |
Quality Control & Certification
In-Process Quality Control:
Chemical composition verified by spectrometer analysis per ASTM E1086
Mechanical properties tested via tensile testing per ASTM E8 / E8M
Hardness testing per ASTM E18 (Rockwell) and E10 (Brinell)
Dimensional inspection per ASTM A480/A480M
Surface finish inspection per ASTM A480 (2B finish standard)
Flatness and edge condition inspection
Available Certifications:
Mill Test Certificate (MTC) per EN 10204 3.1 / 3.2-11
SGS inspection available upon request-11
BV inspection available upon request-
Third-party inspection accepted
Supply Chain Transparency:
Material sourced from major mills including TISCO, BAOSTEEL, LISCO, JISCO, and ZPSS-11-39. Full traceability from melt to final shipment maintained through heat number tracking.
Packaging & Delivery
Packaging:
Interlayer paper between sheets to prevent surface scratches-
Waterproof kraft paper wrapping for moisture protection-11-
Fumigated wooden pallets or steel pallets for structural support-
Steel strip bundling for secure transport-11
Standard seaworthy export packaging--
Container Loading:
20ft GP container: 5.8m (L) × 2.13m (W) × 2.18m (H), approx. 24–26 CBM, 23 MTS capacity-39
Container loading photos provided and container sealed in customer presence-3
Delivery Timeline:
5–10 working days for standard orders-39-
10–15 days for large quantity orders-
Shipment tracking provided throughout the logistics process-3
Order Information:
MOQ: 1 ton (negotiable)--39
Payment Terms: L/C, T/T, D/P, Western Union-39-
Price Terms: FOB, CIF, CNF
Wuxi Yansheng Technology Co., Ltd. – Company Profile
Wuxi Yansheng Technology Co., Ltd. is a comprehensive technology enterprise specializing in high-quality metal raw material supply and precision processing services. Located in Wuxi City, a major steel distribution center in China, the company leverages the mature industrial chain advantages of the Yangtze River Delta region to provide professional material solutions to global customers.
As a technology-driven enterprise, Yansheng Tech maintains strategic cooperation with several well-known steel mills (such as TISCO, Baosteel, JISCO, Dongfang Special Steel, etc.) and is an authorized distributor of these mills. Our main products include stainless steel (304/316/BA/EP pipe), carbon steel, silicon steel, copper, aluminum and other materials in the form of sheets, pipes, coils, as well as custom-processed parts.
Core Business Highlights:
Material Supply: We maintain sufficient stock inventory, offering 304/316 stainless steel sheets, pipes, coils, API 5L casing, electrical steel, and more. We also accept orders for special steel grades and non-standard specifications.
Precision Processing: Equipped with imported mirror polishing machines, water jet cutting machines, high-precision slitting/leveling lines, large CNC milling machines, boring machines, and more. We provide customized services including BA/EP pipe finishing, medium plate polishing, matte finishing, embossing, plasma cutting, etc.
Main Applications: Our products are widely used in industries such as solar energy, pressure vessels, boilers, electric heating equipment, petrochemicals, environmental protection machinery, pharmaceutical and food processing, and new energy vehicles.
Our processing center is located in Xishan District, Wuxi City, covering nearly 10,000 square meters, with an experienced technical and service team. We adhere to the business philosophy of "Technology First, Quality Oriented, Service Supreme" , providing 24/7 warehousing and logistics support as well as comprehensive after-sales service. Yansheng Tech is committed to being your trusted long-term partner.
Frequently Asked Questions (FAQ)
Q1. What products do you mainly supply?
We mainly supply stainless steel (304/316/BA/EP pipes), carbon steel, silicon steel, copper, aluminum, and other materials in sheets, pipes, and coils. Customized processing services are also available.
Q2. Do you have stock available?
Yes, we maintain sufficient stock for most standard specifications. For non-standard sizes, we can accept orders with reasonable lead time.
Q3. Can you provide MTC (Mill Test Certificate)?
Yes, we provide MTC for every shipment. Third-party inspection (SGS, TÜV, BV, etc.) is also available upon request.
Q4. Do you support video inspection before shipment?
Yes, we fully support video inspection. You can also arrange an agent or third party to visit our factory for on-site inspection before shipment.
Q5. What are your main export markets?
We export to Southeast Asia, the Middle East, Europe, Africa, and South America. We have rich experience in international trade and export documentation.
Q6. What payment terms do you accept?
We accept T/T (wire transfer), L/C at sight (irrevocable), and sometimes a combination of T/T deposit + L/C balance. Payment terms are negotiable based on order size and customer history.
Q7. Can you provide samples?
Yes, samples are available for most standard products. For custom sizes, we may need to produce small batch samples. Sample cost and shipping are usually borne by the customer, but can be discussed.
Q8. What is your typical lead time?
For stock items: 7–10 days after order confirmation. For custom production: 20–30 days, depending on the specification and quantity.
Q9. What quality certifications do you have?
We provide MTC with every shipment. Our partner mills are ISO9001 certified. We can also assist with third-party inspections (SGS, TÜV, BV) upon request.
Q10. How can I get a quotation?
Please send us your material grade, specification (size, thickness, length), quantity, and preferred trade term (FOB, CIF, DAP, etc.). We will reply with a detailed quotation within 24 hours.
