Welcome to Anping Xinye Metal Wire Mesh Products Co., Ltd, a trusted manufacturer based in Hengshui, Hebei, China specializing in high-security fencing solutions. Our Galvanized PVC Stainless Steel Concertina Razor Blade Barbed Wire series (BTO-22, BTO-60, CBT-65) is engineered to deliver superior deterrence and durability for critical perimeter protection. Whether you need corrosion resistance, weatherproof coating, or extreme strength, our concertina razor wire meets rigorous international standards while remaining cost-effective.
This product combines the sharpness of razor-sharp blades with the flexibility of concertina coils, creating an intimidating barrier that is difficult to breach. The available materials—galvanized steel, PVC-coated steel, and stainless steel—allow you to select the optimal balance of corrosion resistance and mechanical strength for your specific environment. Below we detail the key features, specifications, and benefits that make this concertina wire a preferred choice for military bases, prisons, industrial plants, and border control.
Key Features & Advantages
- Three core configurations: BTO-22 (small coil, 22mm blade spacing), BTO-60 (medium coil, 60mm spacing), and CBT-65 (single coil, 65mm blade spacing) – each designed for different security levels.
-
Material options:
- Galvanized steel – excellent rust resistance, cost-effective for long-term outdoor use.
- PVC coated – additional weatherproofing, available in multiple colors (green, blue, gray) for camouflage or aesthetic blending.
- Stainless steel – maximum corrosion resistance for coastal or chemical environments, with high tensile strength.
- Razor-sharp blades: Each blade is precisely stamped and heat-treated to ensure consistent sharpness, creating a painful deterrent that prevents climbing or cutting.
- Concertina coil design: The coiled structure allows easy expansion and installation; the coil can be stretched to cover large perimeters quickly.
- Customizable specifications: Blade thickness (0.5mm–0.7mm), core wire diameter (3.0mm–5.0mm), and coil diameter (450mm–900mm) can be tailored to your project requirements.
- Modular and portable: Rolls are compact for transport and can be quickly deployed on fences, walls, or standalone posts.
Technical Specifications
| Parameter | BTO-22 | BTO-60 | CBT-65 |
|---|---|---|---|
| Blade Spacing (mm) | 22 | 60 | 65 |
| Coil Diameter (mm) | 450–600 | 500–700 | 600–900 |
| Blade Thickness (mm) | 0.5 ± 0.05 | 0.6 ± 0.05 | 0.7 ± 0.05 |
| Core Wire Diameter (mm) | 3.0–4.0 | 3.5–4.5 | 4.0–5.0 |
| Standard Roll Length (m) | 10 / 20 / 50 | 10 / 20 / 50 | 10 / 20 / 50 |
The BTO-22 is the most common type for high-security perimeters, offering dense blade coverage. BTO-60 provides a balance between security and cost, while CBT-65 is a single-coil design often used for temporary barriers. Each type can be supplied with galvanized, PVC, or stainless steel finish.
Benefits for Your Security Project
- Rapid installation: Concertina coils can be mounted on existing fences, walls, or standalone posts using simple brackets. No special tools required.
- Long service life: Galvanized and PVC coatings provide 10–15 years of outdoor protection. Stainless steel options last even longer in harsh environments.
- Customizable packaging: Rolls are available in various lengths and can be bundled with fixing clips, ties, or warning signs upon request.
- Multi-scenario use: Suitable for military facilities, correctional institutions, government buildings, industrial sites, residential complexes, and agricultural boundaries.
- Low maintenance: Once installed, the wire requires minimal upkeep. The razor edges remain sharp even after years of exposure.
Why Choose Anping Xinye?
As a leading manufacturer with years of experience in wire mesh products, we ensure strict quality control from raw material selection to final packaging. Our factory in Hengshui, Hebei, produces thousands of meters of concertina razor wire per month, serving clients across Asia, Africa, the Middle East, and South America. We offer competitive factory-direct pricing, flexible MOQ (starting from 100 rolls), and reliable delivery times. Our team can assist with custom specifications, samples, and technical drawings.
Ready to secure your perimeter? Contact us today for a quote or to request a sample. We are committed to providing high-quality concertina barbed wire that meets your exact security needs. Let Anping Xinye be your partner in protection.
Frequently Asked Questions
-
What is the difference between BTO-22, BTO-60, and CBT-65?
BTO-22 has the smallest blade spacing (22mm) for maximum density, ideal for high-security areas. BTO-60 has wider spacing for medium security, and CBT-65 is a single-coil design often used for temporary barriers or where cost is a priority. -
Can I get a sample before placing a bulk order?
Yes, we provide samples (typically 1 meter of wire) for a small fee plus shipping. The sample fee is refundable upon bulk order. -
What is the shipping weight and packaging?
Each roll weighs approximately 5–15 kg depending on material and coil diameter. Rolls are packed in woven bags or pallets for sea/air freight. -
How long does the PVC coating last?
Under normal outdoor conditions, the PVC coating provides UV resistance and prevents rust for 10–15 years. Stainless steel options have an even longer lifespan. -
Does this product comply with international security standards?
Our concertina razor wire is manufactured per general industry standards. While we do not hold specific certifications, our products are widely used in prisons, military bases, and border fencing. We can provide test reports for mechanical properties upon request. -
Can I order custom colors for the PVC coating?
Yes, we offer standard colors (green, blue, gray, black) and can match custom RAL colors for large orders (minimum 5000 meters). -
What is the minimum order quantity (MOQ)?
Our standard MOQ is 100 rolls, but we can accommodate smaller quantities for trial orders. Please contact our sales team for details. -
Is installation hardware included?
Fixing clips, brackets, and ties are available as optional accessories. They are not included in the standard wire price but can be added to your order.
