As a manufacturer with over a decade of experience in precision woven and knitted mesh products, Anping Xinye Metal Wire Mesh Products Co., Ltd introduces our Warp Knitted Nylon Spandex Conductive Fabric 0.3mm Small Diamond Grid Antistatic Yarn. This high-performance fabric combines the flexibility of stretchable textiles with reliable static dissipation, making it ideal for applications where both comfort and safety are required. Engineered with a unique small diamond grid structure, the fabric offers uniform conductivity while maintaining a soft, breathable hand feel.
The core of this fabric is its warp knitted construction using nylon and spandex filaments interwoven with conductive yarns. The result is a lightweight, elastic material that conforms to curved surfaces without losing its antistatic properties. At just 0.3 mm thickness, it can be integrated into garments, linings, and protective covers without adding bulk. The small diamond grid pattern not only enhances tensile strength but also provides a consistent conductive path across the entire surface.
Key Features & Technical Specifications
- Ultra-Thin Profile: 0.3 mm thickness ensures flexibility and ease of sewing.
- Stretch & Recovery: Spandex content provides excellent elasticity (up to 30% elongation) and shape retention.
- Uniform Conductivity: Small diamond grid distributes conductive yarn evenly, achieving surface resistivity typically in the range of 10^3 – 10^5 Ω/sq (depending on yarn count).
- Breathable Structure: Open warp knit design allows air circulation, reducing heat buildup in wearable applications.
- Durable Antistatic Performance: Conductive yarn is integrated into the fabric, not a topical coating, so it withstands multiple wash cycles.
- Color Options: Standard black or gray; custom colors available upon request.
- Customizable Widths: Available in standard rolls of 100 cm, 150 cm, or custom widths.
| Parameter | Value |
|---|---|
| Material Composition | Nylon 70% + Spandex 20% + Conductive Yarn 10% |
| Thickness | 0.3 mm ± 0.05 mm |
| Weight | Approx. 120 g/m² |
| Surface Resistivity | 10³ – 10⁵ Ω/sq |
| Elongation (Warp & Weft) | 20% – 30% |
| Tensile Strength | ≥ 200 N (warp direction) |
| Wash Durability | Retains conductivity after 50+ washes (tested per AATCC 135) |
Customer Benefits
- Enhanced Safety: Prevents electrostatic discharge (ESD) in sensitive environments like electronics manufacturing, cleanrooms, and laboratories.
- Comfortable Wear: The soft, stretchy fabric conforms to body movements, making it suitable for antistatic uniforms and protective apparel.
- Versatile Integration: Can be laminated, sewn, or bonded to other fabrics for composite shielding solutions.
- Cost-Effective: Compared to traditional metal mesh or coated fabrics, our knitted structure offers lower weight and higher flexibility at a competitive price.
- Eco-Friendly Option: Conductive yarn is blended without heavy metal coatings; fabric is washable and reusable, reducing waste.
Anping Xinye Metal Wire Mesh Products Co., Ltd. has been a trusted supplier of precision mesh products since our establishment. Leveraging our expertise in yarn handling and weaving techniques, we have expanded into functional textiles that meet modern industrial demands. Our factory in Hengshui, Hebei, covers 8,000 square meters and is equipped with advanced knitting machines and quality control instruments. We strictly adhere to internal testing standards to ensure consistent product performance. With a monthly production capacity of 500,000 square meters across all product lines, we can fulfill both small sample orders and large-volume contracts. Our team of 20+ engineers and technicians supports customization projects, such as adjusting grid size, conductivity level, or adding flame retardant treatment.
We invite you to experience the quality and reliability of our warp knitted conductive fabric. Whether you need a sample roll for prototyping or a full container for production, we are ready to assist. Contact us today to discuss your specific requirements, and let our technical team recommend the optimal solution for your antistatic needs.
Frequently Asked Questions
-
Q: Can this fabric be washed without losing its antistatic properties?
A: Yes. The conductive yarn is integrated into the knit structure, not a surface coating. It retains its conductivity after 50+ standard wash cycles (tested per AATCC 135). For best results, we recommend gentle washing and air drying. -
Q: Is the fabric suitable for direct skin contact?
A: Yes. The nylon and spandex fibers are soft and non-irritating. The conductive yarn is also skin-friendly, making it appropriate for antistatic undergarments, gloves, and linings. -
Q: What is the typical surface resistivity value?
A: The surface resistivity ranges from 10³ to 10⁵ Ω/sq, depending on the conductive yarn density. We can adjust the yarn count to target a specific resistivity range per your application. -
Q: Can I get a custom grid pattern or thickness?
A: Customization is available upon request. Our engineers can work with you to modify the diamond grid size, thickness (e.g., 0.2 mm or 0.5 mm), or even change the knit structure (e.g., plain, twill). Minimum order quantities apply for custom specifications. -
Q: Does the fabric provide electromagnetic interference (EMI) shielding?
A: Yes, due to its conductive nature, this fabric offers moderate EMI shielding effectiveness (typically 20–40 dB in the 30 MHz to 1 GHz range). For higher shielding requirements, we can recommend a multilayer construction or combine with a metal mesh. -
Q: What width and roll length are available?
A: Standard width is 100 cm (39 inches) and 150 cm (59 inches). Roll length is typically 50 meters, but we can cut to custom lengths. Please inquire for non-standard sizes. -
Q: Is this fabric compatible with standard sewing machines?
A: Yes. The fabric is flexible and can be sewn using a standard needle (e.g., size 70/10) with polyester thread. No special equipment is required. -
Q: How do I place a sample order?
A: You can request a free sample (A4 size) through our contact form or email. We will provide a sample within 5–7 working days. For large orders, please specify quantity and delivery timeline.
