Trusted manufacturer since 1998 – Anping County Boli Hardware Wiremesh Products Factory proudly presents our premium SS304/316/316L Wire Mesh, engineered for versatile applications including projector screens, insect nets, and security screens for windows. With over 20 years of export experience and annual export value exceeding US$5 million, we deliver high-quality stainless steel mesh that combines durability, precision, and corrosion resistance. Whether you need a fine mesh for clear projection images or a robust screen for home protection, our product is designed to meet diverse industrial and residential needs.
Our wire mesh is manufactured from top-grade stainless steel (304, 316, 316L) to ensure exceptional performance in various environments. The 316L grade offers enhanced resistance to chlorides and harsh chemicals, making it ideal for coastal areas or marine applications. Available in a wide range of mesh sizes, wire diameters, and roll dimensions, this product can be customized to your exact specifications. Each roll undergoes strict quality control to guarantee uniform weave and consistent aperture.
Key Features & Technical Specifications
- Corrosion Resistance: SS316/316L offers superior resistance to rust, pitting, and chemical attack, ensuring long service life even in humid or saline environments.
- High Tensile Strength: The wire mesh can withstand heavy loads and impacts, making it suitable for security screens and industrial barriers.
- Uniform Aperture: Precision weaving provides consistent mesh openings, critical for projector screen brightness and clarity.
- Flexible Applications: Use as window insect net, balcony security screen, projector screen material, or filtration mesh.
- Customizable: Mesh size, wire diameter, width, length, and weave type can be tailored to your project requirements.
- Easy Installation: Lightweight and flexible, can be cut and framed with standard tools.
| Parameter | Available Options |
|---|---|
| Material Grade | SS304, SS316, SS316L |
| Mesh Count (per inch) | 10, 12, 14, 16, 18, 20, 30, 40, 50, 60, 80, 100 |
| Wire Diameter | 0.12 mm – 2.0 mm |
| Roll Width | 0.5 m – 2.0 m (custom) |
| Roll Length | 10 m – 50 m (custom) |
| Weave Type | Plain weave, Twill weave, Dutch weave |
| Surface Finish | Mill finish, Bright, Electropolished |
| Applications | Projector screen, insect net, window security, filtration |
Why choose our SS304/316/316L wire mesh? The material difference directly impacts performance. SS304 is economical for general indoor use; SS316 offers better corrosion resistance for outdoor or humid conditions; SS316L, with lower carbon content, provides superior weldability and resistance to intergranular corrosion. For projector screens, a fine mesh (e.g., 60–100 mesh) ensures high-definition image clarity. For insect nets, 16–20 mesh effectively blocks mosquitoes while allowing airflow. For security screens, a thicker wire diameter (0.5–1.0 mm) with 10–14 mesh provides robust protection against break-ins.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between SS304, SS316, and SS316L wire mesh?
A: SS304 is the basic grade with good corrosion resistance. SS316 adds molybdenum for improved resistance to chlorides and acids. SS316L has lower carbon content, reducing the risk of carbide precipitation during welding, making it ideal for applications requiring high temperature or corrosive environments. -
Q: Can I order custom mesh sizes and dimensions?
A: Yes, we offer full customization. Mesh count, wire diameter, roll width, and length can be tailored to your specific requirements. Minimum order quantity may apply. -
Q: Is this wire mesh suitable for outdoor use?
A: Absolutely. SS316 and SS316L grades are highly resistant to weathering and UV, making them perfect for outdoor window screens, insect nets, and security barriers. SS304 is also suitable but may show slight discoloration in harsh coastal environments. -
Q: How do I install the wire mesh for a window security screen?
A: You can cut the mesh to size using heavy-duty shears. Fix it to a window frame using staples, screws, or a frame kit. For a professional look, we recommend using a tensioning system. Detailed installation instructions are available upon request. -
Q: What is the typical lead time for an order?
A: Standard lead time is 15–25 days after order confirmation, depending on quantity and customization. For urgent orders, express production can be arranged. -
Q: Do you provide samples for quality testing?
A: Yes, we offer free samples (shipping cost paid by buyer). You can request a small piece of mesh to evaluate the quality before placing a bulk order. -
Q: What is your packaging method to prevent damage during shipping?
A: The wire mesh is wound on sturdy cores, wrapped with plastic film, and packed in cartons or wooden pallets. For large orders, we use steel strapping to secure the rolls. We ensure the goods arrive in perfect condition. -
Q: Can this mesh be used for projector screens in home theaters?
A: Yes, fine mesh (e.g., 80–100 mesh) with black coating or natural silver finish is commonly used for acoustic transparent projector screens. Our mesh provides excellent image clarity and minimal moiré effect. Please contact us for specific recommendations.
Trust the experts at Anping Boli – With a factory established in 1998, we have supplied stainless steel wire mesh to clients across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our annual export value of US$5–10 million is a testament to our consistent quality and global reliability. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery anywhere in the world.
Every roll of our wire mesh is inspected for weave uniformity, tensile strength, and dimensional accuracy. We are committed to providing products that meet your exact specifications – whether you need 304 mesh for general use or 316L for demanding environments. Contact us today to request a quote or free sample, and experience the durability and precision that has made us a trusted partner for over two decades.
