Product Overview
This skid-mounted high concentration sodium hypochlorite generator is developed for large commercial scenarios such as super-large swimming pools, comprehensive shopping malls, campus water supply and municipal public sanitation disinfection. The equipment produces 10%-13% high-concentration hypochlorite solution by electrolyzing edible refined salt, raw materials are easy to purchase and safe to store, avoiding the safety hazards of transporting bottled chlorine powder and low-concentration bleach. The integrated skid design is convenient for container transportation and rapid installation in underground equipment rooms of shopping malls and sports venues. It can automatically adjust production volume according to swimming pool water circulation flow and residual chlorine value, realize unattended daily disinfection of water bodies, and can also regularly produce high-concentration disinfectant for public area ground, pipeline and garbage station sanitization.
Technical Principle
Adopt compact single-chamber ion membrane electrolysis technology optimized for commercial low-space layout. Edible refined salt is mixed with tap water to form saturated brine, filtered through fine filter to remove tiny impurities to protect electrode coating. The brine evenly enters the compact sealed electrolytic cell with built-in ion membrane. After electrification, chlorine and alkali are separated on both sides of the membrane, and fully absorbed in the built-in mini absorption tower to form high-concentration sodium hypochlorite. The system matches swimming pool circulating water residual chlorine probe, when residual chlorine is lower than the set standard, the electrolysis power automatically increases to improve liquid output; when the index exceeds the limit, the electrolysis unit reduces load or standby. Light hydrogen produced by electrolysis is quickly extracted by small negative pressure fan to prevent gas accumulation in the closed underground equipment room.
Main Features
Compact integrated skid design, small floor area, suitable for underground equipment room and narrow special disinfection room of commercial buildings.
Use edible refined salt as raw material, low procurement threshold, no dangerous chemical management approval troubles of liquid chlorine and chlorine dioxide raw materials.
Touch screen one-click automatic operation, built-in swimming pool special disinfection parameter preset program, operators can start equipment without professional chemical knowledge.
Low noise circulating pump and exhaust fan, will not interfere with the daily operation of shopping malls, stadiums and other public places.
Dual-purpose design: can continuously supply disinfection liquid for water circulation, and regularly produce high-concentration stock solution for ground and space sanitation spraying.
Core Advantages
High concentration finished liquid reduces the frequency of salt replenishment and liquid tank cleaning, reduce daily maintenance workload of property management personnel.
Safe raw material and on-site production mode, no need to apply for hazardous chemical storage certificate, simplify commercial venue safety filing procedures.
Low noise and fully sealed odor-free design, will not produce irritating chlorine smell to affect customer experience in public areas.
Built-in multiple safety protection of liquid level, current, temperature and hydrogen concentration, automatically stop operation once abnormal conditions occur, suitable for unattended property equipment room.
-
Flexible capacity model selection, cover medium-sized community swimming pools to stadium-level super-large swimming venues, one machine meets multiple disinfection demands of the whole commercial complex.
Core Components
Compact ion membrane electrolytic cell, titanium coating electrode, small automatic salt dissolver, precision brine filter, integrated gas-liquid absorption tank, silent hydrogen exhaust fan, small FRP hypochlorite storage tank, swimming pool residual chlorine transmitter, low-noise corrosion-resistant dosing pump, touch screen PLC control cabinet, integrated skid base frame.
Application Fields
Large indoor and outdoor swimming stadiums, commercial shopping mall supporting swimming pools, university campus tap water and swimming pool disinfection, hotel resort water circulation system, municipal garbage transfer station sanitation disinfection, large hospital domestic water disinfection, community centralized living water supply projects.
Boasting 25 years of professional industry experience in production and supply, BLUEWAV factory delivers premium,cost-effective chemical products with reliable quality. Equipped with fully automatic production systems and scientific modular production line design, we achieve stable output, high efficiency and low energy consumption while strictly complying with industrial standards. Different from ordinary manufacturers, BLUEWAV provides flexible customized services tailored to diverse customer needs on product specifications, packaging and solutions. With direct factory pricing and optimized production processes, we help clients cut procurement costs and obtain high-quality, stable chemical supplies with comprehensive professional support.
