Welcome to Hemaokang Steel (Shandong) Co., Ltd. As a professional manufacturer and exporter of high-quality steel products, we are proud to present our S355JR H Beam Steel EN 10025 Standard 150x150 Welded H-Shaped Steel Beam. This product is engineered to meet the rigorous demands of modern construction and industrial applications, combining superior strength with excellent weldability and formability. Our H-beam is produced in strict accordance with the EN 10025 standard, ensuring consistent mechanical properties and dimensional accuracy. With our company's strong export capability (annual export value US$50-100 million) and ISO 9001 certified production processes, you can rely on us for a reliable supply of structural steel beams that enhance the safety and durability of your projects.
The S355JR grade is a hot-rolled structural steel with a minimum yield strength of 355 MPa, making it ideal for load-bearing structures such as building frames, bridges, columns, and beams. The welded H-shaped profile optimizes the steel distribution, providing high bending resistance while minimizing weight. Our 150x150 welded H-beam offers a balanced section for medium-span applications, and it can be customized in length, surface treatment, and end connections to suit your specific project requirements.
Key Features & Technical Specifications
- Grade & Standard: S355JR per EN 10025-2, ensuring consistent chemical composition and mechanical properties.
- Section Profile: Welded H-shaped beam with precise dimensions: 150 mm height × 150 mm flange width.
- Web Thickness: Standard 7 mm (optional 6-10 mm available upon request).
- Flange Thickness: Standard 10 mm (optional 8-12 mm available upon request).
- Length: 6 m, 9 m, 12 m, or custom lengths up to 18 m.
- Surface Treatment: Black (as-rolled), painted (primer or custom color), hot-dip galvanized, or anti-corrosion coating.
- End Finish: Plain, beveled, or drilled for bolted connections (customizable).
- Quality Control: 100% dimensional inspection, ultrasonic testing (optional), and mechanical property testing per ISO 9001.
| Parameter | Value |
|---|---|
| Yield Strength (min) | 355 MPa |
| Tensile Strength | 470-630 MPa |
| Elongation (min) | 22% |
| Impact Energy (0°C) | 27 J (longitudinal) |
| Weight per Meter (approx.) | 31.5 kg/m (for 150x150x7x10) |
| Flange to Web Angle | 90° ± 0.5° |
Advantages & Benefits for Your Business
- High Load-Bearing Capacity: The S355JR grade provides superior strength, allowing longer spans and reduced steel usage, saving material costs.
- Excellent Weldability: Low carbon equivalent (Ceq max 0.45) ensures easy welding without preheating for most applications, speeding up fabrication.
- Precision & Consistency: Our welded H-beams are manufactured with advanced automated welding lines, ensuring straightness, uniform flange width, and consistent web thickness.
- Cost-Effective Customization: We offer flexible length cutting, surface treatment, and drilling services, reducing secondary processing at your site.
- Reliable Supply Chain: With 51-100 experienced employees and an annual export value of US$50-100 million, we guarantee on-time delivery even for large orders.
- Global Market Acceptance: Our products are exported to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and other regions, meeting international quality standards.
Trust & Support from Hemaokang Steel
At Hemaokang Steel (Shandong) Co., Ltd., we take pride in our ISO 9001 certified quality management system. Our production facility in Liaocheng, Shandong, is equipped with modern welding lines, cutting machines, and testing equipment. Every batch of S355JR H-beam is subjected to rigorous inspection, including chemical composition analysis, tensile testing, and dimensional verification. We have served clients in over 15 countries and regions, with a strong track record of zero major quality complaints. Our dedicated sales team provides prompt technical support, documentation (mill certificates, test reports), and shipping solutions. Whether you need standard sections or custom profiles, we are committed to being your long-term partner for structural steel. Contact us today for a competitive quote and experience the Hemaokang difference.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between S355JR and S355J2?
A: S355JR has a minimum impact energy requirement of 27 J at room temperature (20°C), while S355J2 requires 27 J at -20°C. If your project is in a cold environment, we recommend S355J2 or discuss other options with us. -
Q: Can you provide a mill test certificate (MTC) with the shipment?
A: Yes, we issue a 3.1 MTC per EN 10204 for every order, showing chemical composition and mechanical properties. Additional Third-party inspection (e.g., SGS, BV) is available upon request. -
Q: What is the typical lead time for 150x150 welded H-beams?
A: For standard lengths (6m, 12m) and as-rolled surface, lead time is 15-20 working days after deposit. Custom lengths or surface treatments may require 25-30 days. We can also arrange express delivery for urgent small orders. -
Q: How do you ensure the weld quality of the H-beam?
A: Our welding process is performed by certified welders using automated submerged arc welding (SAW). We conduct visual inspection, ultrasonic testing (UT) on a sampling basis, and dimensional checks on every piece. The weld seam is smooth and free of defects. -
Q: What is the maximum length you can produce?
A: Our standard maximum length is 18 meters. For longer lengths, we can provide splicing or you can weld multiple beams on-site. Please consult our technical team for special requirements. -
Q: Do you offer galvanized or painted H-beams?
A: Yes, we offer hot-dip galvanizing (HDG) per ASTM A123 or EN 1461, as well as primer painting (red oxide, epoxy) or custom RAL colors. Surface treatment adds extra corrosion protection and extends service life. -
Q: Can I order a small quantity for a sample or trial order?
A: Absolutely. We welcome sample orders of 1-5 pieces for testing and certification. The price will include the cost of material and shipping. Once you are satisfied, we can proceed with full container orders. -
Q: What is the packaging method for export?
A: Beams are bundled with steel straps, with wooden blocks or plastic spacers between layers to prevent damage. For container loading, we can stack and secure them properly. For break-bulk or flat rack, we use waterproof wrapping and lashing. We also provide custom packaging upon request.
