Help CenterSintered Filter Element Screen, 316L, 5 Micron, 1000L/min Flow Rate, for Chemical Processing
Product Spotlights
Related Products
-
Pleated Filter Element Screen With 0.3mm Thickness, 50mm Length, 1/2" NPT ConnectionNegotiableMOQ: 1 Piece -
316L Stainless Steel Filter Element Screen, 20 Micron, 150 PSI Rated for Industrial UseNegotiableMOQ: 1 Piece
-
Filter Element Screen for Pharmaceutical Manufacturing, 304 Stainless Steel, 0.5μm AbsoluteNegotiableMOQ: 1 Piece
-
Stainless Steel Filter Element Screen for Wastewater Treatment, 500mm, 100 Mesh, Corrosion ResistantNegotiableMOQ: 1 Piece
-
316L Filter Element Screen 200 Mesh 0.5mm Opening 10 Bar Pressure RatedNegotiableMOQ: 1 Piece
As a leading manufacturer from Anping County Boli Hardware Wiremesh Products Factory, established in 1998 with an annual export value of US$5-10 million, we are proud to present our Sintered Filter Element Screen, 316L, 5 Micron, 1000L/min Flow Rate, specially designed for chemical processing applications. This high-performance filter element combines corrosion resistance, high flow capacity, and precise filtration, ensuring your production processes run smoothly and efficiently. With years of expertise in wire mesh and filtration products, we deliver reliable solutions trusted by clients across North America, Europe, Southeast Asia, and more.
Our sintered filter element is engineered from multiple layers of 316L stainless steel wire mesh, sintered under high temperature and pressure to form a rigid, porous structure. This unique manufacturing process provides exceptional mechanical strength, thermal stability, and uniform pore distribution. The 5 micron filtration rating effectively removes fine particles while maintaining a high flow rate of 1000 L/min, making it ideal for demanding chemical processing environments where both purity and throughput are critical.
Key Features & Benefits
- Superior Corrosion Resistance: Made from 316L stainless steel, resistant to chlorides, acids, and alkalis, ensuring long service life in harsh chemical media.
- High Filtration Precision: 5 micron absolute rating provides consistent particle removal, protecting downstream equipment and product quality.
- High Flow Capacity: Up to 1000 L/min per element reduces the number of filters needed, lowering system costs and footprint.
- Reusable & Cleanable: The sintered structure allows backwashing or ultrasonic cleaning, extending service life and reducing replacement frequency.
- Thermal & Mechanical Stability: Withstands temperatures up to 600°C (optional) and pressures up to 30 bar, suitable for extreme process conditions.
- Customizable Dimensions: Available in various diameters, lengths, and end cap configurations to fit existing housings.
Technical Specifications
| Material | 316L Stainless Steel |
| Filtration Rating | 5 Micron (absolute) |
| Maximum Flow Rate | 1000 L/min (for standard element) |
| Operating Temperature | Up to 600°C (optional) |
| Maximum Pressure | Up to 30 bar (customizable) |
| Filtration Area | Customizable per design |
| Cleaning Method | Backwash, ultrasonic, or chemical |
| End Cap Options | Flat, dome, or threaded (custom) |
Our sintered filter elements are widely used in chemical processing, petrochemical, pharmaceutical, water treatment, and food & beverage industries. The 5 micron precision ensures that fine catalyst particles, scale, or precipitates are captured without sacrificing flow. The 316L material offers excellent resistance to pitting and crevice corrosion, even in high-chloride environments. Additionally, the rigid sintered structure prevents media migration and bypass, guaranteeing consistent filtration performance over time.
Compared to traditional woven wire mesh filters, our sintered elements provide higher dirt-holding capacity and lower pressure drop for the same flow rate. This means lower energy consumption and longer intervals between cleanings. Customers can also benefit from our customization services: we can adjust the element length, diameter, end connections, and even combine multiple layers for graded filtration.
Trust & Reliability
With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has built a strong reputation in the global filtration market. Our annual export value of US$5-10 million is a testament to the trust placed in us by clients from North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. We ship from major Chinese ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery. Our in-house quality control system guarantees that every sintered filter element meets strict dimensional and performance standards. We invite you to request a sample or send your specific requirements for a customized solution. Contact us today to optimize your chemical processing filtration.
Frequently Asked Questions
-
Q: Can this filter element withstand high-concentration acids?
A: Yes, 316L stainless steel offers excellent resistance to many acids, including sulfuric acid (up to 20% concentration at room temperature), phosphoric acid, and organic acids. However, for highly corrosive media like hydrochloric acid, we recommend consulting our technical team for compatibility. -
Q: How often does the filter need to be cleaned?
A: The cleaning frequency depends on the solids load in your process. Typically, when the differential pressure reaches 0.5-0.7 bar, backwashing or ultrasonic cleaning is recommended. Our sintered elements can be cleaned multiple times without losing filtration efficiency. -
Q: Is the 1000 L/min flow rate based on water or a specific fluid?
A: The 1000 L/min flow rate is measured with clean water at 20°C and a differential pressure of 0.1 bar. Actual flow may vary depending on fluid viscosity, temperature, and particle load. We can provide performance curves for your specific fluid. -
Q: Can I get custom lengths or diameters?
A: Absolutely. We offer full customization on dimensions, end caps, and gasket materials. Please provide your housing dimensions and operating conditions to receive a tailored quote. -
Q: What is the maximum operating temperature?
A: Standard elements can handle up to 450°C. For higher temperatures up to 600°C, we can use a special sintering process. Please specify your temperature requirements. -
Q: Do you provide samples for testing?
A: Yes, we can provide sample elements for evaluation. Please contact our sales team with your application details to arrange sample shipment. -
Q: How do I ensure the filter element fits my existing housing?
A: We recommend sending us your housing drawings or dimensions. We can match the outer diameter, length, and end connection type (e.g., DOE, 222, 226, or flat gasket). -
Q: What is the typical lead time for bulk orders?
A: Standard lead time is 15-25 working days depending on quantity and customization. For urgent orders, expedited production is available upon request.
