Help CenterDouble Twisted Steel Wire Mesh for Rockfall Drapery Systems in Slope Stabilization
Product Spotlights
Related Products
-
3x1x0.8m Gabion Box With 2m Integrated Tail Double Twisted Mesh Zinc Al10% PVC CoatedNegotiableMOQ: 50 Cubic Centimeters -
Strong Double Twisted Wire Mesh Maintaining Integrity Under Stress and Pressure LoadsNegotiableMOQ: 50 Cubic Centimeters
-
Galvanized Double Twisted Woven Gabion Mesh for Stream Bank Protection and Erosion ControlNegotiableMOQ: 50 Cubic Centimeters
-
Double Twisted Steel Woven Hexagonal Mesh for River Control Rock FillingNegotiableMOQ: 50 Cubic Centimeters
-
PVC Coated Galvanized Double Strands Twisted Hexagonal Mesh for FencingNegotiableMOQ: 50 Cubic Centimeters
As a leading manufacturer from Anping, Hebei, China, Anping Xinye Metal Wire Mesh Products Co., Ltd specializes in the production of high-quality double twisted steel wire mesh designed for rockfall drapery systems in slope stabilization. Our product combines robust structural integrity with flexible installation, ensuring long-term performance in challenging geological environments. Engineered with precise double-twist weaving technology, this mesh offers exceptional resistance to tensile forces and environmental corrosion, making it an ideal choice for protecting infrastructure, roads, and residential areas from rockfall hazards.
Our double twisted steel wire mesh is manufactured from premium galvanized steel wire, with optional PVC coating for enhanced durability in aggressive environments. The unique hexagonal mesh structure provides uniform load distribution, effectively absorbing and dissipating impact energy from falling rocks. With over 20 years of experience in wire mesh production, we ensure each roll meets strict quality control standards, delivering reliable performance in slope stabilization projects worldwide.
Key Features and Technical Specifications
- Double Twisted Weave: The hexagonal mesh is formed by twisting two adjacent wires together, creating a flexible yet strong structure that can conform to uneven terrain without losing integrity.
- High Tensile Strength: Wire diameters range from 2.0mm to 4.0mm, with tensile strength exceeding 500 N/mm², ensuring the mesh can withstand heavy rockfall impacts.
- Corrosion Resistance: Hot-dip galvanized coating (≥250 g/m²) provides excellent protection against rust and oxidation, extending service life to 30+ years in moderate climates. PVC coating is available for harsher environments.
- Customizable Dimensions: Mesh openings from 60mm × 80mm to 100mm × 120mm, roll widths from 1m to 3m, and roll lengths up to 50m — all customizable to meet project-specific requirements.
- Easy Installation: Lightweight and flexible, the mesh can be unrolled and fixed with anchors or cables, reducing labor time and costs. No special tools required.
- Environmentally Friendly: The mesh allows vegetation to grow through its openings, promoting natural slope stabilization and ecological restoration.
| Parameter | Value |
|---|---|
| Material | Galvanized steel wire (Q195/Q235) or PVC coated |
| Mesh Opening | 60×80, 80×100, 100×120 mm (custom) |
| Wire Diameter | 2.0 – 4.0 mm |
| Roll Width | 1 – 3 m |
| Roll Length | 10 – 50 m |
| Tensile Strength | ≥ 500 N/mm² |
| Coating | Hot-dip galvanized (≥250 g/m²), PVC optional |
Applications and Benefits
Our double twisted steel wire mesh is widely used in rockfall drapery systems to protect slopes along highways, railways, mines, and residential areas. The mesh drapes over the slope face, containing loose rocks and debris while allowing natural drainage. Key benefits include:
- Enhanced Safety: Prevents rockfalls from reaching people and property, reducing accident risks.
- Cost-Effective: Lower installation and maintenance costs compared to rigid barriers or concrete walls.
- Longevity: Galvanized coating ensures decades of service with minimal upkeep.
- Flexibility: Adapts to irregular slope contours and can be combined with other stabilization methods like anchors or shotcrete.
- Eco-Friendly: Supports vegetation growth, blending with natural landscape.
Why Choose Anping Xinye Metal Wire Mesh Products Co., Ltd?
Located in the wire mesh hub of Hengshui, Hebei, our company has been dedicated to manufacturing high-quality wire mesh products for over two decades. With a strong focus on innovation and customer satisfaction, we have supplied millions of square meters of double twisted mesh to projects across Asia, Europe, Africa, and the Americas. Our production capacity exceeds 500,000 square meters per month, ensuring timely delivery for large-scale infrastructure projects. All products undergo rigorous testing for tensile strength, coating thickness, and mesh uniformity. We offer flexible packaging options (rolls, bundles, or pallets) and can provide samples for evaluation. Trust Anping Xinye for reliable, durable, and cost-effective slope stabilization solutions.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lifespan of double twisted steel wire mesh in a rockfall drapery system?
A: With proper hot-dip galvanizing (≥250 g/m²), the mesh can last 30+ years in moderate climates. For aggressive environments (coastal, acidic), we recommend PVC coating for extended life. -
Q: Can the mesh be customized to specific dimensions?
A: Yes, we offer custom mesh openings, wire diameters, roll widths, and lengths. Please provide your project requirements for a tailored solution. -
Q: How is the mesh installed on a slope?
A: The mesh is unrolled over the slope, anchored at the top with cables or bolts, and tensioned to ensure close contact with the ground. Overlap at joints is recommended. Detailed installation instructions are available. -
Q: Is the mesh suitable for vegetated slopes?
A: Absolutely. The open mesh structure allows vegetation to grow through, and the mesh can be used in combination with hydroseeding or erosion control blankets. -
Q: What certifications do your products have?
A: Our products comply with international standards such as ASTM A975 and EN 10223. Specific certifications can be provided upon request depending on the destination country. -
Q: What is the minimum order quantity (MOQ)?
A: MOQ for standard sizes is 1000 square meters. For custom specifications, larger quantities may apply. We can discuss based on your project needs. -
Q: How do you ensure quality control?
A: We conduct in-process and final inspections including tensile testing, coating thickness measurement, and mesh opening verification. Each batch comes with a test report. -
Q: Can I get a sample before placing a bulk order?
A: Yes, we provide free samples (customer pays shipping) for evaluation. Contact our sales team to request a sample of your preferred specification.
Contact us today for a quotation or technical consultation. Anping Xinye Metal Wire Mesh Products Co., Ltd. – Your trusted partner in slope stabilization.
