Metal Exterior Wall Sandwich Panel 0.6mm Thickness Rockwool Core Fireproof for Industrial Building
Product Spotlights
0.6mm thick galvanized steel facings bonded with high-density rockwool core deliver Class A fire resistance, superior thermal insulation (0.035 W/m·K), and soundproofing up to 45 dB. Lightweight, easy to install with tongue-and-groove joints, customizable colors and sizes. ISO9001 certified manufacturer with US$50M+ annual exports, serving global industrial projects. Energy-saving, durable, and safe.
Negotiable
MOQ: 100 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Face Material:
Galvanized Steel / Color Coated Steel
Core Material:
Rockwool
Panel Thickness:
0.6mm (face sheet) / total customizable
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
7 days
Related Products
-
Aluminum Zinc Coated Steel Metal Exterior Wall Sandwich Panel 75mm Thickness for Thermal Insulation R-Value 30NegotiableMOQ: 100 Square Meters -
Metal Exterior Wall Sandwich Panel 3m Length 0.5mm Thickness With PU Core for High Insulation PerformanceNegotiableMOQ: 100 Square Meters
-
Free Sample and Technical Support Metal Exterior Wall Sandwich Panel With Standard Compliant MaterialNegotiableMOQ: 100 Square Meters
-
Metal Exterior Wall Sandwich Panel for Cold Storage Warehouse Insulation With 0.6mm Steel SheetNegotiableMOQ: 100 Square Meters
-
0.5mm Galvanized Steel Metal Exterior Wall Sandwich Panel With 50-100mm PU Foam for Fire Resistance Class ANegotiableMOQ: 100 Square Meters
Face Material
Galvanized Steel / Color Coated Steel
Core Material
Rockwool
Panel Thickness
0.6mm (face sheet) / total customizable
Width
1000mm (customizable)
Length
Customizable (up to 12m)
Fire Resistance
Class A (non-combustible)
Application
Industrial Building Exterior Wall
Surface Treatment
Embossed / Smooth / PVDF Coating (optional)
Color
Multiple RAL colors available
Hemaokang Steel (Shandong) Co., Ltd., established in 2025 and headquartered in Liaocheng, Shandong, China, is a professional manufacturer of high-quality steel building materials. With an annual export value of US$50 million – US$100 million and a dedicated team of 51–100 employees, we are committed to delivering reliable, fire-resistant wall panels for industrial projects worldwide. Our Metal Exterior Wall Sandwich Panel with 0.6mm thickness and rockwool core combines superior thermal insulation, structural strength, and exceptional fire protection, making it the ideal choice for modern industrial buildings, warehouses, and factories.
Key Features & Technical Specifications
- Fireproof Core: High-density rockwool (≥120 kg/m³) provides excellent fire resistance, achieving Class A non-combustible rating. It can withstand temperatures up to 1000°C, preventing fire spread and ensuring building safety.
- Durable Metal Facings: Both outer and inner sheets are made from 0.6mm thick galvanized or color-coated steel, offering high corrosion resistance, impact strength, and long service life (up to 25 years under normal conditions).
- Thermal Insulation: Rockwool core has a low thermal conductivity of 0.035–0.040 W/m·K, significantly reducing heat transfer. This helps maintain stable indoor temperatures, lowering HVAC energy consumption by up to 30%.
- Soundproofing: The dense fiber structure of rockwool absorbs sound, providing excellent acoustic insulation (sound reduction index up to 45 dB) – ideal for noisy industrial environments.
- Easy Installation: Panels feature a tongue-and-groove joint design, allowing quick assembly with minimal labor. Each panel covers a width of 1000mm, and lengths can be customized up to 12 meters, reducing seams and improving air tightness.
- Weather Resistance: The metal surface is treated with anti-corrosion coatings (e.g., PVDF, HDP) to withstand UV radiation, rain, snow, and temperature extremes. Suitable for use in various climates.
Technical Parameters (Typical Values)
| Parameter | Value |
| Face Sheet Thickness | 0.6mm (standard, customizable 0.4–0.8mm) |
| Core Thickness | 50mm, 75mm, 100mm, 120mm, 150mm (customizable) |
| Panel Width | 1000mm (effective width 950mm) |
| Panel Length | Up to 12,000mm (custom) |
| Rockwool Density | 120–150 kg/m³ |
| Fire Resistance Class | Class A (EN 13501-1, ASTM E84) |
| Thermal Conductivity | 0.035–0.040 W/m·K |
| Sound Reduction Index | ≥30 dB (depending on core thickness) |
| Weight (approximate) | ~12–15 kg/m² (for 100mm core) |
Why Choose Our Metal Exterior Wall Sandwich Panel?
- Enhanced Safety: The rockwool core is non-combustible and does not produce toxic smoke, ensuring compliance with international fire safety standards.
- Energy Efficiency: Superior thermal insulation reduces heating and cooling costs, providing a quick return on investment (ROI within 2–3 years).
- Structural Integrity: The metal facings bonded to the rigid core create a strong, lightweight panel capable of withstanding wind loads, snow loads, and impacts.
- Aesthetic Versatility: Available in a wide range of colors and surface finishes (embossed, smooth, stone-coated) to match architectural designs.
- Customizable Options: We offer custom lengths, core thicknesses, and cutouts for windows/doors to meet project-specific requirements.
Trust & Reliability
With an annual export value exceeding US$50 million, Hemaokang Steel has served customers across North America, South America, Europe, Asia, Africa, and Oceania. Our production facility is ISO9001 certified, ensuring consistent quality control from raw material sourcing to final inspection. Every panel undergoes rigorous testing for fire resistance, bond strength, and dimensional accuracy before shipment. We are dedicated to providing fast delivery, competitive pricing, and professional after-sales support.
Contact us today to request a quote or sample. Let our team help you select the right panel for your industrial building project. Experience the combination of safety, durability, and energy savings with Hemaokang Steel’s rockwool core sandwich panels.
Frequently Asked Questions (FAQ)
-
Q: What is the fire resistance rating of this panel?
A: Our rockwool core panel achieves Class A non-combustible rating (EN 13501-1, ASTM E84). The fire resistance time (e.g., 60, 90, 120 minutes) depends on core thickness. For example, 100mm core can provide up to 2 hours fire resistance. -
Q: Can the panel be used for both walls and roofs?
A: Yes, this panel is designed primarily for exterior walls, but it can also be used for roofs (with additional structural support if needed). We recommend using specific roof panels for better water drainage. -
Q: What is the standard panel width and length?
A: Standard width is 1000mm (effective width 950mm). Length is customizable up to 12 meters. Shorter lengths are available for easier handling. -
Q: Is the panel waterproof?
A: The metal facings are waterproof, and the tongue-and-groove joint, when properly sealed with silicone or rubber gaskets, provides excellent water resistance. However, for severe weather, additional sealant is recommended. -
Q: How long does it take to install?
A: Installation is quick due to the lightweight design and interlocking joints. A typical industrial building wall can be enclosed in 1–2 weeks, depending on size and complexity. -
Q: Do you offer custom colors or surface finishes?
A: Yes, we support a wide range of RAL colors and finishes including smooth, embossed, and PVDF-coated options. Minimum order quantity may apply for custom colors. -
Q: What is the expected lifespan of the panel?
A: Under normal conditions, the panel can last 20–25 years, with the metal facings requiring minimal maintenance. The rockwool core does not degrade over time. -
Q: Do you provide samples before bulk order?
A: Yes, we can provide samples (A4 size or small panel) upon request. Shipping cost is at buyer's expense, but we can arrange for express delivery.
