  • Panel brand

  • BOE

  • Panel model

  • DV185WHM-NM1

  • Panel size

  • 18.5 inches

  • Panel type

  • a-Si TFT-LCD, LCD module

  • Resolution

  • 1366(RGB)×768, WXGA, 84PPI

  • Pixel layout

  • RGB vertical stripes

  • Display area

  • 409.8(W)×230.4(H) mm

  • Overall dimensions

  • 430.4(W)×254.6(H)×11.4(D) mm

  • Viewable area

  • 413.4(W)×234.0(H) mm

  • Surface treatment

  • Matte (Haze 25%), Hard coating (3H)

  • Display brightness

  • 250 cd/m² (Typ.)

  • Contrast ratio

  • 1000:1 (Typ.) (Transmission)

  • Recommended viewing angle

  • Full viewing angle

  • Response time

  • 14 (Typ.)(G to G) ms

  • Viewing angle

  • 89/89/89/89 (Typ.)(CR≥10)

  • Display mode

  • ADS, normally black display, transmissive

  • Supported colors

  • 16.7M , 99% sRGB

  • Light source type

  • WLED  [6S4P] , 30K hours, no driver

  • Weight

  • 1.30Kgs (Typ.)

  • Application products


  • Frame frequency

  • 60Hz

  • Touch technology

  • No touch

  • Interface type

  • 30 pins   LVDS (1 ch, 8-bit) , terminal

  • Voltage supply

  • 5.0V (Typ.)

  • Application environment

  • Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C
