Help Center5754 Aluminum Coil 1.5mm-5mm Thickness Annealed Temper for Automotive Body Panels
Product Spotlights
Related Products
-
3003 3004 Aluminum Coil 0.3mm-3mm Thickness Bright Finish for Container ManufacturingNegotiableMOQ: 1 Ton -
Anodized Aluminum Coil 1050 1060 0.4mm-2mm Thickness for LED Lighting ReflectorsNegotiableMOQ: 1 Ton
-
7075 T6 Aluminum Coil 0.8mm-2.5mm Thickness High Strength Alloy With Mill Test ReportNegotiableMOQ: 1 Ton
-
Customized Width Aluminum Coil 5052 5754 1mm-4mm Thickness Free Samples and Technical Support AvailableNegotiableMOQ: 1 Ton
-
Polished Aluminum Coil 5052 5083 1mm-3mm Thickness for Marine Interior DecorationNegotiableMOQ: 1 Ton
Hemaokang Steel (Shandong) Co., Ltd. is proud to offer the 5754 Aluminum Coil in thicknesses from 1.5mm to 5mm with an annealed (O) temper, specifically engineered for high-performance automotive body panels. As a trusted supplier established in 2025 with an annual export value exceeding US$50 million, we combine advanced manufacturing capabilities with rigorous quality control to deliver coils that meet the demanding requirements of the automotive industry. Our 5754 alloy provides an excellent balance of strength, corrosion resistance, and formability, making it the ideal choice for stamping, deep drawing, and structural components in vehicles.
This product features a fully annealed (O temper) condition, which ensures maximum ductility and minimized springback during forming operations. With a thickness range of 1.5mm to 5mm, it accommodates a wide variety of automotive panel applications, from inner structures to outer skin panels. The coil is processed on state-of-the-art rolling mills and annealing furnaces, guaranteeing consistent mechanical properties across the entire coil length. Backed by our ISO 9001 certification, every coil undergoes strict dimensional, chemical, and mechanical testing before shipment.
| Parameter | Specification |
|---|---|
| Alloy | 5754 (AlMg3) |
| Temper | O (Annealed) |
| Thickness Range | 1.5 mm – 5 mm (±0.05 mm tolerance) |
| Width Range | 1000 mm – 2000 mm (customizable) |
| Tensile Strength | 190 – 240 MPa (typical) |
| Yield Strength | 80 – 120 MPa (typical) |
| Elongation | ≥ 18% (A50) |
| Surface Finish | Mill finish / embossed / custom |
Key Features and Benefits
- Superior Formability: The annealed temper (O) provides excellent ductility, allowing complex shapes and deep draws without cracking, ideal for automotive body panels.
- Excellent Corrosion Resistance: 5754 alloy contains magnesium, offering high resistance to atmospheric corrosion and road salt, extending vehicle life.
- Lightweight Strength: Compared to steel, this aluminum coil reduces weight by up to 50%, contributing to fuel efficiency and lower emissions.
- Consistent Mechanical Properties: Our controlled annealing process ensures uniform hardness and elongation across the entire coil, reducing scrap during stamping.
- Weldability & Machinability: 5754 alloy is readily weldable using MIG/TIG processes and can be easily cut, drilled, or formed.
- Customizable Dimensions: We offer slit widths, inner diameters, and specific coil weights to match your production line requirements.
Our 5754 aluminum coil is extensively used in the automotive industry for components such as door panels, hoods, trunk lids, fenders, and structural reinforcements. The combination of high strength-to-weight ratio and excellent fatigue resistance makes it a preferred material for modern electric vehicles (EVs) and lightweight body designs. Additionally, the coil can be supplied with an optional protective film to prevent surface scratches during handling and stamping.
Hemaokang Steel (Shandong) Co., Ltd. operates with a team of 51-100 experienced professionals and a modern production facility in Liaocheng, Shandong, China. Our ISO 9001 certification ensures that every production step—from raw material sourcing to final inspection—meets international quality standards. With an annual export value of US$50 million to US$100 million, we have successfully supplied customers across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our commitment to on-time delivery, competitive pricing, and responsive customer service has earned us long-term partnerships with leading automotive manufacturers and tier-1 suppliers.
We invite you to experience the reliability and performance of our 5754 aluminum coil. Whether you need a standard size or a customized solution, our technical team is ready to assist. Contact us today for a quotation or sample request, and discover how Hemaokang Steel can support your automotive panel production with premium materials and exceptional service.
Frequently Asked Questions
-
Q: What is the typical lead time for 5754 aluminum coil?
A: Standard lead time is 15-30 days after deposit, depending on quantity and customization. We can expedite for urgent orders. -
Q: Can you provide coils with a protective film?
A: Yes, we offer optional protective film coating (PE or PVC) to prevent surface damage during stamping and handling. -
Q: Is this coil suitable for stamping large body panels like doors?
A: Absolutely. The annealed temper ensures excellent deep drawing capability, making it ideal for large, complex panels. -
Q: What certifications do you have?
A: Our factory is ISO 9001 certified. Additional certifications such as IATF 16949 are available upon request. -
Q: How do you ensure the coil's flatness and surface quality?
A: We use precision leveling and tension levelling processes, plus 100% visual inspection and thickness gauging. -
Q: What width tolerances can you achieve?
A: Standard width tolerance is ±2 mm. Tighter tolerances (±1 mm) are available upon request. -
Q: Do you offer samples for testing?
A: Yes, we provide free samples (shipping cost covered by customer) for qualification. Contact our sales team. -
Q: Can this coil be used for marine applications?
A: 5754 alloy has good corrosion resistance and is sometimes used in marine environments, but it is primarily designed for automotive use. Please consult our technical team for specific applications.
