Hemaokang Steel (Shandong) Co., Ltd. is proud to offer the 6061 T6 Aluminum Rod in a 1-inch diameter and 12-foot length, produced through an advanced cold drawn process that ensures tight tolerance and a machine-ready surface. With an annual export value exceeding US$50 million and a dedicated team of 51–100 experienced professionals, we deliver consistent quality to global markets including North America, South America, Europe, and Asia. Our ISO9001-certified facility in Liaocheng, Shandong, guarantees that every rod meets rigorous standards for dimensional accuracy, surface finish, and mechanical properties, making it the ideal choice for precision machining, prototyping, and structural applications.
The 6061-T6 alloy combines excellent strength, corrosion resistance, and weldability, while the cold drawn process refines the grain structure and improves surface quality. The rod is supplied with a smooth, clean finish that eliminates the need for additional machining preparation, saving you time and cost. Whether you are manufacturing automotive components, aerospace parts, or custom machinery, this rod offers consistent performance across all dimensions.
Product Features & Technical Specifications
- Material: 6061-T6 Aluminum alloy – known for high strength-to-weight ratio, excellent machinability, and good corrosion resistance.
- Dimensions: Exact 1-inch diameter (25.4 mm) with tight tolerance (±0.001 inch) for precision fit in bearings, bushings, and shafts.
- Length: 12 feet (3657.6 mm) – standard long length to minimize waste and allow multiple cuts.
- Processing: Cold drawn – improves surface finish, dimensional accuracy, and mechanical properties over hot rolled or extruded rods.
- Machine Ready: No scale or rough surface; ready for immediate turning, milling, drilling, or threading.
- Straightness: Maintains excellent straightness per industry standards (e.g., 0.005 inch per foot).
- Heat Treatment: T6 temper – solution heat treated and artificially aged for maximum strength.
| Specification | Value |
|---|---|
| Diameter | 1 inch (25.4 mm) |
| Diameter Tolerance | ±0.001 inch (0.025 mm) |
| Length | 12 feet (3657.6 mm) |
| Length Tolerance | ±0.125 inch (3.2 mm) |
| Tensile Strength (min) | 310 MPa (45,000 psi) |
| Yield Strength (0.2% offset) | 276 MPa (40,000 psi) |
| Elongation (in 2”) | 10% |
| Hardness (Brinell) | 95 HB |
| Surface Finish | Smooth, bright, scale-free (Ra ≤ 1.6 μm) |
| Straightness | 0.005 inch per foot (0.42 mm/m) |
Key Advantages for Your Business
- Time Savings: The machine-ready surface eliminates the need for pre-machining, allowing you to go straight to final operations.
- Cost Reduction: Tight tolerances reduce scrap and rework, especially in high-volume production runs.
- Versatility: Suitable for CNC machining, welding, anodizing, and various fabrication processes.
- Reliable Supply: With annual export value between US$50–100 million, we maintain large inventory and fast shipping worldwide.
- Consistent Quality: ISO9001-certified quality management system ensures every batch meets strict specifications.
Our 6061 T6 aluminum rod is the preferred choice for engineers and manufacturers who demand precision and reliability. The cold drawn process not only delivers superior dimensional accuracy but also enhances the material’s strength and fatigue resistance, making it ideal for components that undergo cyclic loading. Whether you need a single rod for a prototype or a full container for mass production, Hemaokang Steel can fulfill your requirements with competitive pricing and on-time delivery.
Frequently Asked Questions (FAQ)
Q1: What is the difference between cold drawn and extruded aluminum rods?
A: Cold drawn rods are pulled through a die at room temperature, which improves dimensional accuracy, surface finish, and mechanical properties compared to extruded rods. The cold drawn process yields tighter tolerances and a smoother surface, making it “machine ready.”
Q2: Can you cut the rod to custom lengths?
A: Yes, we offer cutting services for custom lengths upon request. Standard length is 12 feet, but we can provide shorter pieces with a small additional charge. Please inquire for details.
Q3: Is this rod suitable for welding?
A: Yes, 6061-T6 aluminum has good weldability using common techniques (MIG, TIG). However, welding may soften the heat-affected zone. Post-weld heat treatment can restore temper if required.
Q4: What is the maximum working temperature?
A: 6061-T6 aluminum retains its strength up to approximately 150°C (300°F). Above this temperature, the material may lose temper. For high-temperature applications, consider other alloys.
Q5: Do you provide material test certificates?
A: Yes, we can provide a mill test certificate (MTC) per EN 10204 or equivalent, including chemical composition and mechanical properties. This is available upon request.
Q6: How do you package the rods for export?
A: Rods are bundled with protective plastic caps, wrapped in waterproof paper, and packed in wooden crates or steel bands for secure international shipping. Each bundle is labeled with grade, size, and heat number.
Q7: What is the minimum order quantity (MOQ)?
A: For standard sizes, the MOQ is 100 kg (about 30 pieces of 12-foot rods). For custom sizes or special requirements, please contact our sales team to discuss.
Q8: Can this rod be anodized?
A: Yes, 6061-T6 aluminum is an excellent candidate for anodizing. The smooth surface from cold drawing ensures a uniform anodic coating, enhancing corrosion resistance and appearance.
Trust Hemaokang Steel (Shandong) Co., Ltd. – a company with US$50–100 million annual export value, 51–100 employees, and a global reach across five continents. Our ISO9001 certification reflects our commitment to quality. Thousands of satisfied customers in North America, Europe, and Asia rely on our precision aluminum rods. Contact us today for a quote or technical consultation, and experience the reliability of a trusted B2B partner.
