Help CenterStainless Steel Filter Drum 0.2mm Slot, 0.6MPa Pressure, 50-500μm Mesh, Customizable Length, 1.2m Diameter
Product Spotlights
Related Products
-
Stainless Steel Filter Drum for Wastewater Treatment, 0.5mm Mesh, 100L/min, Corrosion Resistant, 304 GradeNegotiableMOQ: 1 Piece -
Duplex Stainless Steel Filter Drum, 200 Micron, 0.8MPa, Chemical Resistant, High Strength, 1.5m LengthNegotiableMOQ: 1 Piece
-
Customized Stainless Steel Filter Drum, 304/316L, 0.2mm Slot, 30-Day Delivery, Quality Guaranteed, 0.5m-2m LengthNegotiableMOQ: 1 Piece
-
Stainless Steel Filter Drum With 1 Year Warranty, Mill Test Report, 0.5mm-2mm Mesh, Factory Direct, CustomizableNegotiableMOQ: 1 Piece
-
Stainless Steel Filter Drum 304 30 Micron 220V 50Hz Industrial FiltrationNegotiableMOQ: 1 Piece
Anping County Boli Hardware Wiremesh Products Factory, a professional manufacturer since 1998, presents our Stainless Steel Filter Drum with a precision 0.2mm slot, designed for demanding filtration applications. With over 20 years of experience and an annual export value exceeding US$5 million, we deliver robust, high-performance filter drums that withstand 0.6MPa pressure and offer mesh sizes from 50 to 500μm. Our customizable length and fixed 1.2m diameter ensure a perfect fit for your industrial systems, balancing efficiency and durability.
This filter drum is constructed from premium stainless steel, providing excellent corrosion resistance and long service life. The wedge wire design ensures uniform slot openings, preventing clogging and maximizing flow rate. Ideal for water treatment, petrochemical, and food processing industries, our drum meets the rigorous demands of continuous operation. Below we detail its key specifications and benefits.
Key Features & Technical Specifications
- Precision Slot Size: 0.2mm (200 microns) – ensures accurate solid-liquid separation, reduces particle leakage.
- High Pressure Capacity: Rated at 0.6 MPa (6 bar) – suitable for high-pressure filtration systems without deformation.
- Wide Mesh Range: 50 to 500 μm – customizable to your specific filtration requirements (e.g., 50μm, 100μm, 200μm, 500μm).
- Large Diameter: 1.2 m outer diameter – high throughput volume, ideal for industrial-scale operations.
- Length Customization: Available in lengths from 0.5 m to 6 m (or as requested) – easy integration into existing vessels.
- Material: Grade 304 or 316L stainless steel – excellent corrosion resistance, suitable for acidic or alkaline environments.
- Wedge Wire Profile: Continuous V-shaped wire wound on support rods – minimizes clogging, provides self-cleaning capability.
- Reinforced Structure: Welded with high-strength support rods – withstands mechanical stress during backwashing and operation.
| Parameter | Value | Notes |
|---|---|---|
| Slot Size | 0.2 mm | ±0.02 mm tolerance |
| Working Pressure | 0.6 MPa | Tested up to 1.0 MPa |
| Filtration Precision | 50 – 500 μm | Customizable per mesh |
| Outer Diameter | 1.2 m (1200 mm) | Fixed |
| Length | Customizable | Standard: 1m, 2m, 3m, 6m |
| Material | SS304 / SS316L | Optional |
Advantages & Customer Benefits
- Enhanced Filtration Efficiency: The precise 0.2mm slot ensures consistent solid capture, reducing downstream equipment wear.
- High Flow Rate: Wedge wire design provides up to 40% more open area compared to perforated plates, minimizing pressure drop.
- Easy Maintenance: Self-cleaning V-wire profile reduces clogging; backwashing is more effective.
- Long Service Life: Stainless steel construction resists rust, corrosion, and abrasion, even in harsh environments.
- Customizable Dimensions: Length tailored to your vessel – no need for modification or adapters.
- Cost-Effective Solution: Durable construction reduces replacement frequency, lowering total cost of ownership.
Our filter drums are manufactured using advanced CNC winding and automatic welding technology, ensuring consistent quality. Each drum undergoes pressure testing and slot size verification before shipment. We offer optional end connections (flanges, threads, or plain ends) to match your piping system.
Trust & Reliability
As a trusted manufacturer based in Hengshui, Hebei, China, Anping County Boli Hardware Wiremesh Products Factory has been serving global clients for over 25 years. With an annual export value of US$5–10 million, we ship to North America, South America, Europe, Asia, Africa, and Oceania. Our products are exported via major ports including Tianjin, Qingdao, Shanghai, and Foshan. We are committed to providing reliable filtration solutions with fast delivery and responsive after-sales support. Contact us today to discuss your specific requirements – we offer free samples and engineering drawings upon request.
Frequently Asked Questions
- What is the maximum length for a 1.2m diameter drum? We can produce lengths up to 6 meters in one piece. Longer lengths can be made by welding multiple sections, but we recommend a single piece for pressure integrity.
- Can the slot size be tighter than 0.2mm? Yes, we offer slot sizes from 0.1mm to 5mm. For 0.2mm or smaller, we recommend using 316L stainless steel to maintain strength.
- Is the drum suitable for seawater applications? Yes, when made of 316L stainless steel, it offers excellent resistance to chloride corrosion. We can also apply additional coatings if needed.
- How is the drum connected to the pipeline? We can weld flanges (ANSI, DIN, JIS) or provide threaded ends (male/female). Custom connections are available upon request.
- What is the typical lead time? For standard sizes (1m length, 304 material), lead time is 15–20 working days. Custom orders may take 25–30 days depending on complexity.
- Do you provide a warranty? Yes, we offer a 12-month warranty against manufacturing defects. Our drums are tested for pressure and slot uniformity before shipment.
- Can the mesh range be mixed in one drum? No, each drum has a uniform slot size. However, we can supply multiple drums with different mesh sizes for staged filtration.
- What is the minimum order quantity? For standard products, MOQ is 5 pieces. For custom lengths, MOQ can be 1 piece after sample approval.
