Nylon Plastic Netting 1mm Diameter, 20x20mm Mesh, High Temperature Resistant up to 120°C, for Filtration
Product Spotlights
High-temperature resistant nylon netting (up to 120°C) with 1mm wire and 20x20mm mesh. Ideal for filtration, separation, and screening. 26 years of manufacturing experience, customizable sizes, global shipping from China. Trusted by clients worldwide for reliable quality and long service life.
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Nylon (Polyamide)
Wire Diameter:
1mm
Mesh Opening:
20x20mm
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai qingdao
Delivery Detail:
1 days
Related Products
-
Plastic Safety Netting for Construction Scaffolding, 5mm Thickness, 100x100mm Mesh, Compliant With EN 1263-1NegotiableMOQ: 1 Square Meter -
Plastic Netting With 2mm Wire Diameter, 40x40mm Mesh, UV Resistant, 5 Year WarrantyNegotiableMOQ: 1 Square Meter
-
Heavy Duty Polypropylene Plastic Netting, 3mm Thickness, 10x10mm Square Mesh, 200m Roll LengthNegotiableMOQ: 1 Square Meter
-
Extruded HDPE Plastic Netting, 1/2 Inch Mesh Opening, 5000N Tensile Strength, UV Stabilized for Outdoor UseNegotiableMOQ: 1 Square Meter
-
Knotted Plastic Netting, 4mm Strand, 50x50mm Mesh, 1000kg Breaking Strength, WeatherproofNegotiableMOQ: 1 Square Meter
Material
Other, Nylon (Polyamide)
Wire Diameter
1mm
Mesh Opening
20x20mm
Temperature Resistance
Up to 120°C
Color
White / Black / Custom
Width
1m / 1.2m / Custom
Application
Filtration, Separation, Screening
Packaging
Rolls
Customizable
Yes (size, color, mesh)
At Anping County Boli Hardware Wiremesh Products Factory (established 1998), we specialize in manufacturing high-quality Nylon Plastic Netting with a precise 1mm diameter wire and 20x20mm mesh opening. This netting is engineered to withstand continuous operating temperatures up to 120°C, making it an ideal choice for demanding filtration applications. Our decades of experience in wire mesh production ensure consistent quality, durability, and reliable performance across industries.
Key Features & Technical Specifications
- Material: Virgin Nylon 6 or Nylon 66 – excellent chemical resistance, low moisture absorption, and high tensile strength.
- Wire Diameter: 1mm (±0.05mm) – provides robust structure while maintaining open area for efficient flow.
- Mesh Opening: 20mm x 20mm (square) – suitable for coarse filtration, particle separation, and protective screening.
- Temperature Resistance: Continuous operating up to 120°C; short-term peaks up to 140°C (depending on environment).
- Available Widths: Standard rolls 1m, 1.2m, or custom widths per request.
- Color Options: White (natural), black (UV-stabilized), or custom colors for OEM/ODM orders.
- Packaging: Wrapped in protective film, then in export-standard cartons or pallets to prevent damage during transit.
| Parameter | Value |
|---|---|
| Wire Diameter | 1.0 mm |
| Mesh Opening | 20 x 20 mm |
| Open Area | Approx. 73% |
| Tensile Strength (warp) | ≥ 800 N/5cm |
| Tensile Strength (weft) | ≥ 700 N/5cm |
| Operating Temperature | -40°C to +120°C |
| Chemical Resistance | Good against alkalis, oils, greases; avoid strong acids |
| UV Resistance | Standard (black version offers enhanced UV stability) |
Benefits for Your Applications
This nylon netting is specifically designed for filtration and separation tasks where high temperature resistance is required. The 1mm diameter wire provides excellent rigidity, preventing sagging even under continuous hot water or air flow. The 20x20mm mesh size allows efficient separation of larger particles while maintaining high throughput. Key benefits include:
- Long service life – Nylon’s inherent toughness resists wear and tear, reducing replacement frequency.
- Easy cleaning – Smooth surface allows quick rinsing or backwashing, suitable for repeated use.
- Lightweight yet strong – Reduces structural load on frames and supports, ideal for industrial filters.
- Non-corrosive – Will not rust or degrade in moist environments, perfect for water and wastewater treatment.
- Customizable – We can cut to specific dimensions, add edge reinforcement, or produce in different colors to match your branding.
Typical Applications
- Industrial water filtration (cooling towers, process water)
- Food processing – sieve for grains, fruits, or vegetables
- Chemical filtration – separation of coarse solids from liquids
- Protective screening – vents, air intakes, and enclosures
- Aquaculture – netting for fish farming and pond filtration
- Dryer belts or conveyor belts in high-temperature drying systems
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
With over 26 years of manufacturing excellence (since 1998), we have built a reputation for reliable quality and global service. Our annual export value exceeds US$5 million, serving clients across North America, South America, Europe, Asia, Africa, and Oceania. We ship from major Chinese ports (Tianjin, Qingdao, Shanghai, Foshan) ensuring fast and cost-effective logistics. Our factory is located in Hengshui, Hebei – the wire mesh capital of China – giving us access to premium raw materials and skilled workforce.
We are committed to strict quality control: every roll of nylon netting is inspected for mesh uniformity, tensile strength, and dimensional accuracy before packaging. Our team can also provide samples for testing, and we offer custom manufacturing to meet your exact specifications. With competitive pricing and dependable lead times, we are your trusted partner for filtration netting solutions. Contact us today to discuss your requirements or request a quote.
Frequently Asked Questions
-
Q: Can this netting be used for air filtration?
A: Yes, it is suitable for coarse air filtration (e.g., dust, insects) in HVAC or industrial vents, provided the temperature does not exceed 120°C. -
Q: Is the 1mm diameter wire flexible enough to be cut and shaped?
A: The nylon netting has some flexibility; it can be cut with scissors or a utility knife and shaped to fit frames. For very tight curves, a heat gun may be used to soften the material (carefully). -
Q: What is the standard roll length?
A: Standard rolls are 50 meters long, but we can supply custom lengths (e.g., 30m, 100m) upon request. -
Q: Does the material meet FDA or food-contact standards?
A: Our standard nylon is food-grade quality; however, if you require specific FDA compliance, please inform us so we can provide corresponding certifications. (Note: We can provide material test reports upon request.) -
Q: How should I store the netting?
A: Store in a cool, dry place away from direct sunlight. The black version offers better UV resistance for outdoor storage. Avoid contact with strong acids or bases. -
Q: Can you provide a sample before bulk order?
A: Yes, we offer free samples (please pay shipping) for quality evaluation. Contact our sales team with your address and requirements. -
Q: What is the tolerance on mesh opening size?
A: Our manufacturing tolerance is ±1mm for the 20x20mm mesh opening, ensuring consistent performance. -
Q: Do you offer heat-sealed edges or reinforced borders?
A: Yes, we can add edge stitching, heat-sealed borders, or grommets for additional strength – please specify when ordering.
