As a trusted manufacturer from Anping County Boli Hardware Wiremesh Products Factory (established 1998, annual export US$5-10 million), we are proud to introduce our premium Nylon Coated Stretch Mesh. This product combines exceptional flexibility with robust durability, featuring a precise 30% stretch ratio and heat resistance up to 150°C. Designed for demanding industrial applications, it offers reliable performance while maintaining compliance with standard quality benchmarks. Whether you need filtration media, protective barriers, or decorative architectural mesh, our solution delivers consistent stretch, thermal stability, and long service life.
Our Nylon Coated Stretch Mesh is engineered with a fine wire core (polyester or stainless steel) coated with a uniform nylon layer, giving it a smooth surface, corrosion resistance, and excellent elasticity. The 30% stretch ratio allows easy installation and snug fitting around curved or irregular shapes, while the 150°C heat tolerance ensures stability in high-temperature environments such as oven filters, engine compartments, or hot air drying systems. Below are key technical specifications for your reference:
| Property | Value |
| Base Material | Polyester / Stainless steel wire |
| Coating | Nylon (PA6 or PA66) |
| Stretch Ratio | 30% (±2%) |
| Heat Resistance | Up to 150°C (continuous) |
| Mesh Opening | 1mm – 10mm (customizable) |
| Standard Roll Width | 1m, 1.2m, 1.5m |
| Roll Length | 30m / 50m (custom) |
| Color Options | Black, white, green, blue, gray |
Key Features & Benefits:
- Controlled 30% Stretch: Our mesh stretches uniformly, allowing it to conform to complex contours without sagging or tearing. This feature is ideal for curved filtration systems, speaker grilles, and protective covers where a precise fit is critical.
- High Temperature Resistance (150°C): The nylon coating and base wire withstand continuous exposure to 150°C, making the mesh suitable for hot air filtration, oven liners, engine bay screens, and drying equipment.
- Durable Nylon Coating: Protects the wire from corrosion, abrasion, and UV degradation. The coating also provides a smooth, non-stick surface that reduces material buildup and simplifies cleaning.
- Standard Compliance: Our manufacturing process adheres to recognized industry quality standards, ensuring consistent mesh opening, uniform coating thickness, and reliable mechanical properties.
- Customizable Options: We offer flexible customization in mesh opening, wire diameter, coating thickness, width, length, and color. Samples are available upon request.
- Versatile Applications: Used in automotive (airbag components, radiator grilles), industrial filtration (liquid/air), agriculture (greenhouse screens), construction (facade mesh), and consumer goods (luggage netting, sports equipment).
Our Nylon Coated Stretch Mesh is also available in a variety of packaging options: standard rolls, cut sheets, or die-cut shapes. We can produce custom widths up to 2.5m and lengths per your requirements. For applications requiring enhanced fire retardancy or UV resistance, alternative coatings (e.g., PVC, silicone) are optional.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
With over 25 years of manufacturing experience since 1998, we have served clients across North America, Europe, Southeast Asia, Africa, and Oceania. Our annual export value exceeds US$5 million, reflecting global trust in our quality. We ship from major Chinese ports (Tianjin, Qingdao, Shanghai, Foshan) and offer flexible lead times. Every roll of mesh undergoes strict quality control – from raw material inspection to final coating thickness tests. Our team provides professional technical support, helping you select the right specifications for your project. We are not just a supplier; we are your long-term partner for industrial mesh solutions.
Contact us today for a quote or free sample. Let our Nylon Coated Stretch Mesh with 30% stretch ratio and 150°C heat resistance bring efficiency and reliability to your operations.
Frequently Asked Questions
Q1: What is the maximum temperature this mesh can withstand?
A: It can withstand continuous exposure up to 150°C. For short-term peaks, it can tolerate up to 170°C, but we recommend staying within the rated limit for optimal longevity.
Q2: Can the mesh be cut to custom sizes?
A: Yes, we offer custom cutting, die-cutting, and roll slitting. Please provide your required dimensions, and we will produce accordingly.
Q3: Is the nylon coating food-grade?
A: Our standard nylon coating is not certified food-grade, but we can source FDA-compliant nylon upon request. Please contact us for specific requirements.
Q4: What is the typical lead time?
A: For standard sizes in stock, lead time is 7-10 days. Custom orders usually take 15-20 days depending on quantity and complexity. We can expedite for urgent projects.
Q5: How do I select the correct mesh opening for my application?
A: Mesh opening depends on the particle size you need to filter or the support structure. For liquid filtration, we recommend openings 1-3mm; for air filtration, 3-8mm; for decorative uses, 5-10mm. Our technical team can help you choose.
Q6: Does the mesh retain its shape after stretching?
A: Yes, the 30% stretch ratio is designed to be elastic, meaning it returns to its original shape when tension is released. However, prolonged overstretching may cause permanent deformation. We recommend stretching within the specified limit.
Q7: What colors are available?
A: Standard colors are black, white, green, and gray. Custom colors (Pantone) are available with a minimum order quantity. Please inquire.
Q8: Can I get a sample before placing a bulk order?
A: Absolutely. We provide free samples (A4 size) for standard meshes. For custom specifications, a sample fee may apply, which is refundable upon bulk order. Shipping cost is on your side.
