As a leading manufacturer based in Hengshui, Hebei, China, Anping Xinye Metal Wire Mesh Products Co., Ltd is proud to offer our Heavy Duty W Beam Guardrail designed specifically for municipal road construction and safety barrier applications. Our guardrails are engineered to provide reliable vehicle containment and redirection, significantly reducing the risk of severe accidents. With years of expertise in metal fabrication, we ensure every piece meets rigorous quality standards, delivering long-lasting performance and peace of mind for road authorities and contractors.
The W beam profile is recognized globally for its superior energy absorption and structural integrity. Our heavy-duty version features thicker steel plates and reinforced connections, making it ideal for high-traffic municipal roads, highway medians, and temporary construction zones. Each guardrail system is hot-dip galvanized to resist corrosion, even in harsh weather conditions, and can be customized with various post spacings and mounting options to fit your specific project requirements.
Key Features & Technical Specifications
- Robust W Beam Design: The corrugated shape increases stiffness and impact resistance, effectively directing vehicles back onto the road.
- High-Strength Steel: Manufactured from Q235 grade steel, with a yield strength of ≥235 MPa, ensuring durability under heavy loads.
- Corrosion Protection: Hot-dip galvanized coating (average 85 μm) per ASTM A123 or equivalent, providing up to 20 years of service life in normal environments.
- Easy Installation: Modular components with bolted connections allow quick assembly on-site, reducing labor costs and downtime.
- Versatile Applications: Suitable for permanent municipal roads, temporary construction barriers, parking lots, and industrial facilities.
- Customizable Options: Available in different beam lengths, post heights, and spacer types to meet specific project standards.
| Parameter | Standard Value | Remarks |
|---|---|---|
| Beam Material | Q235 steel, hot-rolled | Meets international standards |
| Beam Thickness | 3.0 mm (heavy duty) | 2.5 – 4.0 mm optional |
| Beam Length | 4320 mm | Other lengths available upon request |
| Overall Height | 310 mm | Standard profile |
| Post Material | Q235 steel, C-shape or I-beam | Hot-dip galvanized |
| Post Spacing | 2 m (standard) | 1 m, 4 m for different containment levels |
| Surface Treatment | Hot-dip galvanized (85 μm) | Painting optional |
| Connection Type | Bolted with splice plates | Easy to install and replace |
Benefits for Municipal Road Construction
- Enhanced Safety: The W beam design absorbs impact energy and guides vehicles, reducing the severity of crashes and protecting pedestrians and infrastructure.
- Cost-Effective Solution: Durable galvanized steel minimizes maintenance and replacement costs over the long term.
- Quick Deployment: Pre-engineered components allow rapid installation, minimizing traffic disruption during construction.
- Compliance with Local Standards: Our guardrails can be manufactured to meet various national specifications, including AASHTO M180, EN 1317, or other regional standards upon request.
- Environmentally Friendly: Steel is 100% recyclable, and the hot-dip galvanizing process is environmentally controlled.
At Anping Xinye, we have supplied guardrail systems for numerous municipal projects across China and overseas. Our factory is equipped with advanced production lines and strict quality control procedures, ensuring consistent product quality. We also offer tailored solutions, including customized lengths, coatings, and packaging for export. With a dedicated team of engineers and sales professionals, we provide prompt technical support and after-sales service.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lifespan of your heavy-duty W beam guardrail?
A: With proper hot-dip galvanization, the guardrail can last 20 years or more in normal outdoor conditions. Regular inspection is recommended to ensure optimal performance. -
Q: Can you customize the guardrail for specific road curvature?
A: Yes, we can supply curved beams and flexible post arrangements to follow the road alignment. Please provide your road geometry for a tailored solution. -
Q: Is installation difficult? Do you provide installation manuals?
A: Our guardrail system is designed for easy bolted assembly. We provide detailed installation drawings and can offer on-site guidance if needed. -
Q: What certifications do your products have?
A: Our products are manufactured in accordance with international standards. Specific certifications can be obtained upon request depending on the destination country. -
Q: What is the minimum order quantity (MOQ)?
A: MOQ is typically 100 meters for standard products, but we accept smaller orders for sample testing or pilot projects. -
Q: How do you ensure the guardrail meets safety requirements?
A: We conduct material testing, coating thickness measurement, and dimensional checks. Our factory follows ISO 9001 quality management system. -
Q: Can you supply the guardrail with yellow paint for visibility?
A: Yes, we offer powder coating or painting in various colors, including yellow for high-visibility applications. Please specify your requirement. -
Q: Do you provide samples before mass production?
A: Yes, we can provide small samples for quality evaluation. The customer only needs to cover shipping costs.
Choose Anping Xinye as your reliable partner for road safety solutions. With our extensive experience in metal mesh and guardrail manufacturing, we are committed to delivering products that exceed your expectations. Contact us today for a quotation or technical consultation. We look forward to building a safer road infrastructure together.
