1 Product Overview
Coastal power plant dedicated seawater electrolysis chlorine system is large-scale industrial seawater treatment equipment for power station seawater circulating cooling systems. Coastal power plants rely on natural seawater for cooling, and seawater contains a large number of algae, shellfish, plankton and microorganisms, which are easy to attach and reproduce in pipelines, causing pipeline blockage, increased pipeline resistance and reduced unit heat exchange efficiency. This equipment takes natural seawater as the only raw material, realizes on-site electrolysis chlorine generation without adding any chemical agents. It maintains stable trace active chlorine in the circulating water system, achieves efficient sterilization and anti-biofouling, ensures long-term stable operation of power plant cooling units, and meets industrial environmental protection and energy-saving operation standards.
2 Technical Principle
The equipment adopts large-flow industrial seawater direct electrolysis technology. The natural seawater extracted from the sea for power plant cooling is sent to the multi-stage precision filtration system to remove suspended solids, marine debris and large plankton. The purified seawater flows into the industrial-grade high-efficiency electrolytic cell group. Under constant current DC electrolysis, chloride ions in seawater are oxidized to produce active hypochlorous acid disinfectant. The electrolyzed seawater with uniform active chlorine concentration is injected into the power plant circulating water main pipe. Active chlorine can quickly kill microorganisms and inhibit the incubation of shellfish and algae spores. The system links with water flow and seasonal temperature changes to intelligently adjust electrolysis load, ensuring accurate and efficient anti-fouling disinfection effect for large-flow circulating water.
3 Main Features
Large-Flow Industrial Processing Capacity：Supports matching with large-scale power plant seawater circulating systems, meeting high-flow continuous disinfection and anti-fouling demands.
Industrial Stable Operation：Adaptable to fluctuating seawater quality and temperature changes in different seasons, maintaining long-term stable working state.
Zero Chemical Consumables：Direct electrolysis of seawater, no need for chlorine dioxide, sodium hypochlorite and other chemical agents, green and low-carbon.
Intelligent Industrial Control：Linked with power plant DCS system, realizing automatic operation, data monitoring and centralized management.
Energy-Saving & High-Efficiency：Optimized electrolysis process, low unit energy consumption, reducing power plant auxiliary energy consumption.
4 Core Advantages
Industrial Matching Advantage：Customized for power plant large-flow circulating water scenarios, solving the problem of insufficient treatment capacity of small civil disinfection equipment.
Significant Cost Saving：Completely abandoning traditional chemical dosing mode, saving a large amount of chemical procurement, transportation and storage costs every year.
Improve Unit Operation Efficiency：Effectively prevent pipeline biological fouling, stabilize cooling water flow and heat exchange efficiency, reduce unit energy consumption.
Environmental Compliance Advantage：Electrolysis products naturally attenuate, no residual chemical pollution, meeting marine environmental protection discharge standards.
High Compatibility：Can be perfectly compatible with new and old coastal power plant seawater cooling systems, convenient for equipment upgrading and renovation.
5 Core Components
Industrial Large-Flow Seawater Electrolytic Cell Group：Core industrial reaction unit, meeting high-volume seawater electrolysis demand with high efficiency and stability.
Intelligent Energy-Saving DC Rectifier System：Industrial-grade stable power supply, dynamically adjusting power according to water volume to reduce energy consumption.
Multi-Stage Seawater Purification Filtration Device：Industrial precision filtration to ensure seawater quality and protect electrolytic cell operation.
Power Plant DCS Linked Control Cabinet：Realizes data interconnection with power plant system, centralized automatic control and fault monitoring.
Large-Flow Uniform Dosing Pipeline System：Ensures active chlorine uniform diffusion in large-diameter circulating pipelines for overall anti-fouling effect.
6 Application Fields
Coastal thermal power plant seawater circulating water treatment, nuclear power plant auxiliary seawater system anti-biofouling, large coastal industrial park seawater cooling system disinfection, seaside desalination plant pretreatment anti-fouling, coastal chemical enterprise seawater circulating pipeline protection.
Boasting 25 years of professional industry experience in production and supply, BLUEWAV factory delivers premium,cost-effective chemical products with reliable quality. Equipped with fully automatic production systems and scientific modular production line design, we achieve stable output, high efficiency and low energy consumption while strictly complying with industrial standards. Different from ordinary manufacturers, BLUEWAV provides flexible customized services tailored to diverse customer needs on product specifications, packaging and solutions. With direct factory pricing and optimized production processes, we help clients cut procurement costs and obtain high-quality, stable chemical supplies with comprehensive professional support.
