Anping Xinye Metal Wire Mesh Products Co., Ltd is a professional manufacturer of road safety equipment with over 15 years of production experience. Our Q235 Steel Two Wave / Three Wave Road Guardrail (4320×310×85mm) represents the perfect balance of strength, durability, and cost-effectiveness. Made from high-quality Q235 carbon steel, this guardrail is designed to withstand severe vehicle impacts while maintaining structural integrity. Whether you need a two-wave or three-wave profile, our product ensures reliable protection for highways, expressways, and mountain roads. With customizable surface treatments like hot-dip galvanizing, you get long-lasting corrosion resistance even in harsh environments.
Product Features & Technical Specifications
- Material: Premium Q235 carbon steel – excellent weldability and impact resistance.
- Wave Design: Two-wave (W-beam) and three-wave (Thrie-beam) options available. The three-wave provides higher stiffness and is recommended for high-risk areas.
- Standard Dimensions: 4320mm length, 310mm width, 85mm height – compatible with standard guardrail systems.
- Surface Treatment: Hot-dip galvanized (≥85µm zinc coating) for superior anti-corrosion; electro-galvanized or PVC coated also available upon request.
- Thickness Range: 2.5mm to 4.0mm (customizable to meet your project requirements).
- Installation: Designed to fit standard posts and bolts; easy to install and replace.
- Certification: Manufactured according to China industry standard JT/T 281-2007; third-party testing reports available.
- Application: Highways, expressways, bridges, tunnels, mountain roads, parking lots, and industrial areas.
| Parameter | Specification |
|---|---|
| Material | Q235 Steel (equivalent to ASTM A36) |
| Wave Type | Two Wave (W-Beam) / Three Wave (Thrie-Beam) |
| Length × Width × Height | 4320mm × 310mm × 85mm |
| Thickness | 2.5mm / 3.0mm / 3.5mm / 4.0mm (custom) |
| Surface Treatment | Hot Dip Galvanized (HDG), Electro-Galvanized, PVC Coated, or Painted |
| Zinc Coating Mass | ≥85µm (HDG), ≥600g/m² |
| Standard | JT/T 281-2007 (China Highway Guardrail Standard) |
| Packaging | Steel bundles or pallets with waterproof wrapping |
Key Advantages for Your Project
- High Impact Resistance: The Q235 steel base combined with wave design effectively absorbs and redirects collision energy, reducing vehicle deceleration and protecting occupants.
- Long Service Life: Hot-dip galvanizing ensures the guardrail can last 20+ years in normal outdoor conditions without rust.
- Cost-Effective: Compared to stainless steel or aluminum alternatives, our Q235 guardrail offers comparable performance at a lower price point.
- Easy Maintenance: Damaged sections can be quickly replaced without affecting the entire system – just unbolt and install new panels.
- Versatility: Suitable for straight roads, curves, and slopes; can be used with different post types (e.g., C-post, I-beam post).
- Custom Options: We can adjust thickness, length, coating color, and even produce special shapes per your drawings.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we have a dedicated production line for guardrails with an annual capacity of over 50,000 tons. Our factory in Hengshui, Hebei, is equipped with advanced stamping, galvanizing, and testing facilities. Every batch undergoes strict quality control – including tensile strength tests, zinc coating thickness measurement, and dimensional inspection. We have supplied guardrails to projects in Asia, Africa, South America, and the Middle East, earning trust from government agencies and contractors. When you choose our Q235 Steel Two Wave Three Wave Road Guardrail, you are choosing a reliable partner committed to safety and value.
Contact us today for a quotation or technical consultation. Our team will provide professional advice and fast delivery to meet your project deadline.
Frequently Asked Questions (FAQ)
1. What is the difference between two-wave and three-wave guardrail?
Two-wave (W-beam) is suitable for standard road sections with moderate impact risk. Three-wave (Thrie-beam) has a higher stiffness and is recommended for high-risk areas such as sharp curves, steep slopes, or bridge ends. Both can be supplied in the same outer dimensions.
2. Can the guardrail be customized to different lengths?
Yes, we can produce custom lengths ranging from 2000mm to 6000mm. However, the standard 4320mm is the most common for compatibility with existing posts and accessories.
3. What surface treatment is best for coastal areas?
We recommend hot-dip galvanized (HDG) with a minimum zinc coating of 85µm, which provides excellent resistance to salt spray and humidity. For extremely corrosive environments, additional PVC coating can be applied.
4. How is the guardrail packed for export?
Each guardrail panel is bundled with steel straps, and multiple bundles are stacked on pallets. The entire package is wrapped with waterproof plastic film to protect against moisture during shipping.
5. Do you provide installation accessories like posts and bolts?
Yes, we offer a complete guardrail system including end terminals, reflector posts, bolts, nuts, and washers. All components are designed to match the 4320×310×85mm panels.
6. What is the lead time for a typical order?
For standard specifications (2.5mm thick, HDG), the lead time is 15–20 working days after receiving the deposit. Custom orders may take 25–30 days depending on quantity and complexity.
7. Can you provide third-party testing reports?
Yes, we can arrange for testing by an independent laboratory (e.g., SGS, Intertek) at an additional cost. Standard in-house test reports are provided free of charge.
8. Is the guardrail suitable for use in cold climates?
Q235 steel maintains its mechanical properties down to -20°C. For extreme cold regions (below -30°C), we recommend using low-temperature impact steel (Q345D or Q345E), which we can also supply upon request.
