Product Description
LFM supplies all Tubing of the API standards.
In addition, we has also developed many kinds of tubing, casings of non-API standards, such as: Products for ultrahigh strength & deep well, Products for heavy oil thermal recovery well, Products for Sour service, Products for H2S corrosion resistant & anti-collapse, forming its own series to meet different requirements and offer more selections for the customers.
Specifications
OD: Tubing 1.66"-4-1/2"
Steel Grade: J/K 55, N80-1/Q, L80-1, 1Cr, 9Cr, 13Cr, P110, Q125, TT Series, SS Series etc.
Connection Type:
API series: Tubing: NUE EUE
Premium thread: V series, Tenaris Series, TPCQ Series, BG series, JFE series.
Pup Joint: As required.
Product Name |
Oil-well Casing / Drill Pipe |
Applicable Standard |
API 5CT / 5DP / 5E |
Material / Steel Grade |
J55, K55, P110, N80, N80Q, L80, P95, Q125, V150 |
Production Process |
Seamless, Welded |
Length Range |
R1 (4.88m - 7.62m), R2 (7.62m - 10.36m), R3 (10.36m - 14m), Custom Length as per Customer Requirements |
Coupling / Thread Type |
NUE, EUE, BTC, LTC, STC, VA M |
Specification
Product Name |
Oil Casing And Tubing |
Standard |
API5CT |
Tubing Outer Diameter |
2 3/8''-4 1/2''(60.3mm-114.30mm) |
Casing Outer Diameter |
4 1/2''-20''(114.30mm-508mm'') |
Wall Thickness |
0.205''-0.635'' |
Length |
R1(4.88mm-7.62mm) |
Steel Grade |
J55/K55/N80/L80/P110/C95/T95/Q125/L80-13CR/P110- 13CR/80S/80SS/95S/ |
Connection Type |
NU/EU/IJ/STC/BTC/LTC/PREMIUM CONNECTION |
Surfacr Treatment |
Corrosion proofing water based paint |
Package |
Protection Caps in Both Ends, Waterproof Paper Wrapped, Two Tags |
Heat Treatment |
Normalized, Quencher+Temper |
Applicable Environment |
Conventional oil and gas wells, deep wells, ultra-deep wells, and highly sulphurous/highly saline corrosive environments (H2S/CO2) |
HS code |
73052000 |
Product Advantage
Key Advantage
1. High Strength & Structural Integrity
Manufactured from premium carbon or alloy steel, exhibiting exceptional tensile, compressive and crush resistance.
Suitable for deep wells, ultra-deep wells and complex geological conditions, ensuring long-term stable operation of oil wells.
2.Outstanding Corrosion Resistance | Excellent Corrosion Resistance
Available grades include L80 (13Cr), C90, and other sulphur-resistant steels, suitable for sour service environments containing H2S and CO2.
Supports coating, anti-corrosion, and galvanised finishes to extend service life and reduce maintenance costs.
3. Full Compliance with API & ISO Standards
Strict adherence to API 5CT and ISO standards.
All products bear API certification , suitable for global oilfield projects, facilitating seamless customs clearance and acceptance for customers.
