Help CenterAutomotive OEM Hall Sensor Bracket Molding, PPS High-Temp Resin, Tight Tolerance ±0.02mm, Automated Robotic Pick & Place
Product Spotlights
Related Products
-
OEM Plastic Injection Molding for Hall Sensor Holder, Glass-Filled PBT, 30% GF, Cycle Time Under 30s, IATF 16949 Compliant ProcessNegotiableMOQ: 5000 Pieces -
Custom Molded Hall Sensor Brackets for ECU Bases, PBT+GF30 Material, 150 Ton Injection Machine, No Flash, No Sink MarksNegotiableMOQ: 5000 Pieces
-
Custom Automotive Hall Sensor Bracket Molding, High-Temp PPS, 220°C Continuous Use, Zero Warpage, CMM Verified DimensionsNegotiableMOQ: 5000 Pieces
-
OEM Molding for Hall Sensor Brackets Used in BLDC Motor & Electronic Parking Brake, IATF 16949:2016, Consistent Part DensityNegotiableMOQ: 5000 Pieces
-
Precision Hall Sensor Brackets for New Energy Vehicle BLDC Motor Assembly, Optimized for Magnetic Field Sensing in EV DrivetrainsNegotiableMOQ: 5000 Pieces
Changzhou Hongxinyutai Precision Mold Co., Ltd. is a professional manufacturer established in 2017, specializing in precision injection molding for automotive components. Our Automotive OEM Hall Sensor Bracket Molding is crafted from PPS high-temperature resin, offering exceptional thermal stability and mechanical strength. With tight tolerance control of ±0.02mm and automated robotic pick & place integration, this bracket ensures reliable performance in demanding automotive environments. Designed for direct OEM replacement, it meets the highest standards of quality and consistency.
This product is the result of years of expertise in precision mold design and manufacturing. Our factory, spanning 1,000–3,000 square meters, is equipped with advanced injection molding machines and robotic automation systems. Each bracket undergoes rigorous quality checks to guarantee ±0.02mm dimensional accuracy, critical for hall sensor alignment in modern vehicles. The PPS material provides excellent chemical resistance, low moisture absorption, and continuous operation at temperatures up to 230°C, making it ideal for under-hood applications.
Key Features & Benefits
- High-Temperature Resistance: PPS resin withstands continuous heat up to 230°C, ensuring long-term stability in engine compartments.
- Ultra-Precision Tolerance: ±0.02mm accuracy guarantees perfect fit and consistent sensor positioning, reducing assembly errors.
- Automated Robotic Handling: Robotic pick & place reduces manual handling, minimizes contamination, and ensures repeatable quality.
- Lightweight yet Durable: PPS offers high strength-to-weight ratio, reducing overall vehicle weight without compromising performance.
- Chemical & Moisture Resistance: Excellent resistance to oils, fuels, coolants, and humidity, extending product lifespan.
- OEM Compliant: Manufactured under TS16969 quality system, meeting strict automotive industry standards.
- Customizable Design: Available in multiple colors and dimensions, tailored to your specific sensor bracket requirements.
Technical Specifications
| Parameter | Value |
| Material | PPS (Polyphenylene Sulfide) |
| Tolerance | ±0.02mm |
| Operating Temperature | -40°C to +230°C |
| Molding Process | Injection Molding with Robotic Pick & Place |
| Color Options | Black, Gray, or Custom (upon request) |
| Packaging | Anti-static bags, foam trays, or custom |
| Certification | TS16969 (IATF 16949) |
Our automated production line ensures consistent quality across thousands of parts. The robotic pick & place system eliminates human error during part removal, maintaining the tight tolerance of ±0.02mm even in high-volume runs. This bracket is designed for easy integration into existing hall sensor assemblies, reducing installation time and improving overall system reliability.
Quality Assurance: Every batch is tested for dimensional accuracy, material integrity, and thermal performance. Our TS16969 certified quality management system ensures traceability and continuous improvement. We serve global markets including North America, Europe, Southeast Asia, and more, with flexible shipping from Jiangsu, Shanghai, or Shenzhen ports.
Why Choose Hongxinyutai?
- 51–100 experienced employees dedicated to precision molding.
- Factory size of 1,000–3,000 m² with advanced equipment.
- Established in 2017 with a track record of reliable deliveries.
- Flexible customization: we work with your design files to produce the exact bracket you need.
- Competitive pricing without compromising on quality.
Trusted by global automotive OEMs, our hall sensor brackets have been used in various vehicle models, demonstrating consistent performance under extreme conditions. We invite you to contact us for a quotation or sample testing. Our engineering team is ready to support your project from prototype to mass production.
Frequently Asked Questions
-
Q: What is the typical lead time for this bracket?
A: Lead time is typically 15–25 working days after order confirmation, depending on quantity and customization. Rush orders can be arranged upon request. -
Q: Can you produce brackets with different hole patterns?
A: Yes, we can customize the design based on your 3D drawing or sample. Our mold team will modify the tooling to meet your exact specifications. -
Q: Is the PPS material RoHS compliant?
A: Yes, our PPS resin is RoHS compliant and free from hazardous substances as per automotive industry requirements. -
Q: How do you ensure the ±0.02mm tolerance?
A: We use precision CNC mold machining and in-process inspection with CMM (Coordinate Measuring Machine). Every part is sampled and measured during production. -
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 500 pieces for standard designs. For custom molds, MOQ may be negotiable. Please contact us for details. -
Q: Do you provide samples for testing?
A: Yes, samples are available. We can produce a small batch using prototype tooling or existing molds. Sample cost is chargeable but refundable upon mass order. -
Q: Can the bracket withstand prolonged exposure to engine oil?
A: PPS has excellent resistance to oils, fuels, and most automotive fluids. It is widely used in under-hood components for its chemical stability. -
Q: How is the product packaged to prevent damage?
A: We use anti-static bags, foam trays, and sturdy cartons. For large quantities, we can also use reusable plastic containers. Custom packaging is available.
With over 5 years of experience in automotive precision molding, Changzhou Hongxinyutai Precision Mold Co., Ltd. is your reliable partner for hall sensor brackets. Our commitment to quality, tight tolerances, and automated production ensures you receive components that meet your exact needs. Contact us today to discuss your requirements or request a quote.
