Hemaokang Steel (Shandong) Co., Ltd., a trusted supplier based in Liaocheng, Shandong, China, proudly presents our 1100 Aluminum Coil H14 Temper with thickness range of 0.3–3mm and width range of 1000–2000mm. As a company with an annual export value of US$50 million to US$100 million and ISO9001 certification, we are dedicated to delivering high-quality aluminum coils that meet international standards. Our product is designed for a wide variety of industrial applications, offering excellent formability, corrosion resistance, and consistent mechanical properties. Whether you need coils for kitchenware, heat exchangers, or decorative panels, our 1100 H14 aluminum coil is a cost-effective and reliable choice.
Key Features & Technical Specifications
- Alloy 1100: Commercially pure aluminum (99.0% min) with excellent workability and weldability.
- Temper H14: Strain-hardened to a quarter-hard condition, providing a good balance of strength and ductility for forming and bending.
- Thickness range: 0.3mm to 3mm, with tight tolerances (±0.02mm for thickness under 1mm, ±0.05mm for 1–3mm).
- Width range: 1000mm to 2000mm, customizable to specific requirements.
- Inner diameter: Standard 508mm or 610mm, other sizes available upon request.
- Surface finish: Mill finish, embossed, or coated options (e.g., PVDF, polyester) to meet diverse aesthetic and functional needs.
- Standards compliance: Manufactured in accordance with ISO9001, ASTM B209, and EN 485, ensuring consistent quality.
- Packaging: Seaworthy export packing with wooden pallets, steel straps, and moisture-proof paper to protect during transit.
Typical Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 110 – 145 |
| Yield Strength (MPa) | ≥ 95 |
| Elongation (%) | ≥ 5 |
| Hardness (HB) | Approx. 32 |
Advantages & Customer Benefits
- Excellent corrosion resistance: Ideal for outdoor and humid environments, reducing maintenance costs.
- High formability: Suitable for deep drawing, bending, stamping, and spinning without cracking.
- Good thermal and electrical conductivity: Used in heat exchangers and electrical components.
- Cost-effective: Lower price compared to higher alloyed aluminum, offering great value for general-purpose applications.
- Consistent quality: Our ISO9001 quality management system ensures tight control over chemical composition and mechanical properties.
- Customizable sizes and surface: We can produce coils with specific widths, thicknesses, and finishes to match your production requirements.
- Reliable supply: With a production capacity of thousands of tons per month, we can fulfill large-volume orders with short lead times.
Frequently Asked Questions (FAQ)
-
Q: What is the standard tolerance for thickness and width?
A: Thickness tolerance is ±0.02mm for 0.3–1mm, ±0.05mm for 1–3mm. Width tolerance is ±2mm for 1000–2000mm. We can also provide tighter tolerances upon request. -
Q: Can you supply coils with embossed or painted surface?
A: Yes, we offer mill finish, embossed (diamond, stucco, etc.), and coated finishes (PVDF, polyester, etc.) as per your specifications. -
Q: What is the minimum order quantity (MOQ)?
A: The standard MOQ is 5 tons per size. For smaller orders or sample coils, please contact us for feasibility. -
Q: How do you pack the coils for export?
A: We use seaworthy packing: wooden pallets, steel straps, and waterproof paper or plastic wrap. Coils can also be packed in wooden crates for extra protection. -
Q: What is the typical lead time?
A: For standard sizes in stock, delivery is within 7–10 days after deposit. For customized production, lead time is 15–25 days depending on quantity. -
Q: Do you provide third-party inspection services?
A: Yes, we welcome SGS, BV, or other accredited inspectors to verify the quality before shipment. We can also provide mill test certificates. -
Q: What are the main applications of 1100 H14 aluminum coil?
A: Common uses include kitchen utensils, heat exchanger fins, roofing sheets, decorative panels, chemical equipment, and reflectors. -
Q: Is your product compliant with international standards?
A: Yes, our 1100 aluminum coil meets ASTM B209, EN 485, and ISO 9001 standards. We can also produce to other standards like JIS or GB upon request.
Why Choose Hemaokang Steel?
Hemaokang Steel (Shandong) Co., Ltd. was established in 2025 and has quickly grown into a major exporter of aluminum products. With an annual export value of US$50 million to US$100 million and a dedicated team of 51–100 employees, we have built a strong reputation for quality and reliability. Our ISO9001-certified production facilities ensure that every coil meets the highest standards. We serve customers across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and Asia, demonstrating our global reach. Our zero-defect policy, competitive pricing, and responsive customer service make us the preferred partner for aluminum coil buyers. We invite you to contact us for a quote or to discuss your specific requirements. Let us supply you with 1100 H14 aluminum coils that will enhance your production efficiency and product quality.
