Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Hongrui Brand 150KW Cummins Diesel Generator Set With DSE Control Systerm DSE6120 LEROYSOMER Alternator Standard Voltage 400V 50HZ/1500rpm
Hongrui Brand 150KW Cummins Diesel Generator Set With DSE Control Systerm DSE6120 LEROYSOMER Alternator Standard Voltage 400V 50HZ/1500rpm
Product Spotlights
1. Engine Model : SC4H115D2
2. Auto start/stop, load transfer and alarming of generator
3 phase generator and mains voltage monitoring.
4. Multiple start/stop cycles can be preset
5. Load current monitoring and protection
6. Engine speed protection Battery voltage monitoring
7. Generator/load power detection (kW, kVA, kVAr PF)
2. Auto start/stop, load transfer and alarming of generator
3 phase generator and mains voltage monitoring.
4. Multiple start/stop cycles can be preset
5. Load current monitoring and protection
6. Engine speed protection Battery voltage monitoring
7. Generator/load power detection (kW, kVA, kVAr PF)
US$ 2000 - 8000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Self-Starting Diesel Generator
Warranty:
365 days
Stroke:
Four Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
30 days
Related Products
-
Chinese in Stock 300KW SDEC Diesel Silent Type Generator Set With DSE Control Systerm DSE6120 3 Phrase 540A Rated Current GensetUS$ 2000 - 8000MOQ: 1 Piece -
Portable Diesel Generator Set Fuel Efficient Diesel Generators 200KW Certified Water Cooling Diesel GeneratorUS$ 2000 - 8000MOQ: 1 Piece
-
Portable Diesel Generator Set 1000kw Diesel Generators Portable Standby Soundproof Generator Diesel Engine ATSUS$ 2000 - 15000MOQ: 1 Piece
-
30kw Portable Outdoor Power Household Diesel Generator Set Remote Full Set Charging Facilities GeneratMotorUS$ 1000 - 3000MOQ: 1 Piece
-
250KVA Diesel Generator Set Remote Full Set Charging Facilities GeneratMotor for Hospital , Construction Machinery and Data CencerUS$ 1000 - 3000MOQ: 1 Piece
Type
Self-Starting Diesel Generator
Warranty
365 days
Stroke
Four Stroke
Usage
Common Units, Standby Unit, Emergency Crew
Speed
Speed
Cooling Method
Water Cooling
After-sales Service
Available
Installation Method
Portable
Excitation Mode
AC Rotating Exciter
Conditions of Use
Land Use
Landuse Type of Unit
Low Noise Automation Type
Output Type
AC Three Phase
Alternator brand
LEROYSOMER
Alternator model
TAL-A44-C
Alternator Power
75KW
Voltage regulator type
AVR
Diesel Engine brand
SDEC POWER
Diesel Engine Model
SC4H115D2
Diesel Engine Power
78/86KW
Frequency/Speed
50HZ/1500rpm
Control module
DSE6120
Standard Voltage
400V
Transport Package
As client requiement
Specification
300 KW
Trademark
Hongrui
Origin
Jining
Hongrui Brand 75KW SDEC Diesel Generator Set With DSE Control Systerm DSE6120 LEROYSOMER Alternator
Diesel generator Parameters and specification
GENSET Power |
75kw |
Frequency/Speed |
50HZ/1500rpm |
Engine Model |
SC4H115D2 |
Standard Voltage |
400V |
Alternator model |
TAL-A44-C
|
Phases |
3 |
Control module |
DSE6120 |
Rated Current |
135A |
Starting Voltage |
DC24V |
Power Factor(cosφ) |
0.8 |
Weight |
1300KG |
Dimension L*W*H |
2800*1140*1600mm |
Engine specification
Diesel Engine brand |
SDEC POWER |
Diesel Engine Model |
SC4H115D2 |
Diesel Engine Power |
78/86KW |
Cylinders |
4 |
Bore(mm) |
105 |
Stroke(mm) |
124 |
Air inlet |
Turbocharged & Intercooled |
Start Method |
Electric starting |
Cooling Method |
Water cooling |
Fuel consumption |
≤198g/kW•h |
Alternator specification
Alternator brand |
LEROYSOMER |
Alternator model |
TAL-A44-C
|
Alternator Power |
75KW |
Voltage regulator type |
AVR |
Insulation class |
H |
Standard configuration
Radiator |
（50℃） |
Battery |
included |
Bottom diesel tank |
included |
Connection Cable |
included |
Silencer |
included |
Controller |
included |
Inlet and outlet pipes |
included |
Circuit breaker |
included |
