Help CenterBrass Plated Steel Wire 0.8mm Dia 2500MPa Tensile for Steel Cord Conveyor Belt
Product Spotlights
Related Products
-
Steel Cord Fabric 1500N/mm Breaking Strength 2% Elongation for Rubber Conveyor BeltUS$ 2.05MOQ: 1000 Square Feet -
Brass Coated Steel Wire 1.2mm Diameter ISO 9001 Compliant for Conveyor BeltUS$ 2.05MOQ: 1000 Square Feet
-
Steel Cord Fabric 10mm Pitch 3500N/mm Strength for Mining Conveyor BeltUS$ 2.05MOQ: 1000 Square Feet
-
Steel Cord Fabric 0.3mm-2.0mm 2000MPa Tensile for Heavy-Duty Conveyor BeltUS$ 2.05MOQ: 1000 Square Feet
-
Brass Steel Wire 0.25mm Dia Brass Coating 0.2μm for Conveyor Belt ReinforcementUS$ 2.05MOQ: 1000 Square Feet
As a leading manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory proudly presents our high-quality Brass Plated Steel Wire – specifically engineered for steel cord conveyor belt applications. With a diameter of 0.8mm and an impressive tensile strength of 2500 MPa, this wire is designed to meet the rigorous demands of heavy-duty industrial environments. Our product ensures reliable performance, excellent adhesion to rubber, and long service life, making it a preferred choice for conveyor belt manufacturers worldwide.
At Boli, we combine advanced manufacturing techniques with strict quality control to deliver wire that consistently meets international standards. Our brass-plated steel wire offers superior corrosion resistance and enhanced bonding capabilities, which are critical for the safety and durability of steel cord conveyor belts. Whether you are producing belts for mining, port handling, or heavy-duty transport, our wire delivers the strength and consistency you need.
Key Features & Technical Specifications
- High Tensile Strength: 2500 MPa ensures the wire can withstand extreme pulling forces without deformation.
- Precise Diameter: 0.8 mm ±0.01 mm tolerance for uniform performance in every meter.
- Brass Plating: Uniform coating with 65% copper / 35% zinc composition for optimal rubber adhesion.
- Excellent Ductility: Allows for easy twisting and cabling during belt manufacturing.
- Corrosion Resistance: Brass layer protects against rust and environmental degradation.
- Consistent Quality: Every batch is tested for tensile strength, elongation, and plating thickness.
| Parameter | Value |
|---|---|
| Diameter | 0.8 mm (0.0315 inch) |
| Tensile Strength | 2500 MPa (min) |
| Elongation at Break | ≥2% (typical) |
| Plating Composition | Cu 65% / Zn 35% |
| Plating Thickness | 2-5 μm (customizable) |
| Packaging Options | Spools, coils, or cut lengths |
Benefits for Your Business
- Improved Belt Durability: High tensile strength reduces belt stretching and ensures longer service intervals.
- Enhanced Safety: Consistent wire quality minimizes the risk of breakage under heavy loads, protecting personnel and equipment.
- Cost Efficiency: Longer belt life lowers replacement and maintenance costs over time.
- Global Compatibility: Our wire meets commonly used industry standards, making it suitable for export to various markets.
- Flexible Supply: We offer custom packaging and delivery schedules to match your production needs.
From our factory in Hengshui, Hebei, we have been serving customers worldwide since 1998. Our annual export value of US$5 million to US$10 million speaks to the trust placed in our products by markets in North America, South America, Europe, Asia, Africa, and Oceania. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery to your doorstep.
Why choose Boli? We invest in continuous process improvement and rigorous testing. Every coil of brass-plated steel wire is inspected for tensile strength, diameter accuracy, and plating quality. Our experienced team is ready to support you with technical advice and custom solutions. Contact us today for a quote or to discuss your specific requirements.
Frequently Asked Questions
-
Q: What is the typical lead time for this wire?
A: For standard specifications, lead time is 10-15 working days after order confirmation. Custom orders may require additional time. -
Q: Can you provide samples for testing?
A: Yes, we offer free samples (shipping cost may apply). Please contact us with your requirements. -
Q: Is the wire suitable for outdoor conveyor belts?
A: Yes, the brass plating provides good corrosion resistance. However, for extremely harsh environments, we can adjust plating thickness upon request. -
Q: What is the maximum length per spool?
A: We can package up to 50 kg per spool, which corresponds to approximately 4,000 meters of 0.8mm wire. Custom lengths are available. -
Q: Do you test for adhesion to rubber?
A: Yes, we perform adhesion tests using standard rubber compounds. Test results can be provided upon request. -
Q: What payment terms do you accept?
A: We accept T/T, L/C, and other common terms. Negotiable for large orders. -
Q: Can you supply wire with different tensile strengths?
A: Yes, we can customize tensile strength from 2000 MPa to 3000 MPa. Please specify your requirements.
With 25 years of manufacturing expertise, a proven track record in global exports, and a commitment to quality, Anping County Boli Hardware Wiremesh Products Factory is your reliable partner for brass-plated steel wire. Contact us now to place an order or request a quotation. We look forward to building a long-term cooperation with you.
