Wuxi Yansheng Technology Co., Ltd. is a professional manufacturer with over 7 years of experience in the superalloy industry. Our annual export value exceeds US$50 million, serving markets across North America, Europe, Southeast Asia, and more. We supply high-performance Nickel Alloy X (N06002) plate and sheet specifically engineered for demanding gas turbine applications. This superalloy offers exceptional oxidation resistance, high-temperature strength, and fabricability, making it the preferred choice for combustion chambers, transition ducts, and afterburner components.
Our Nickel Alloy X is produced in strict compliance with international standards such as ASTM B435 and AMS 5536. Each batch undergoes rigorous testing to ensure consistent mechanical properties and chemical composition. With a factory size of 1,000–3,000 sqm and a skilled team of 101–200 employees, we guarantee reliable supply and short lead times.
Key Features & Benefits
Excellent high-temperature strength – Maintains mechanical integrity up to 1200°C (2192°F), ideal for continuous operation in gas turbines.
Superior oxidation and corrosion resistance – Chromium and molybdenum content provide protection against hot corrosion and scaling.
Good fabricability – Can be welded, formed, and machined with standard techniques, reducing manufacturing costs.
Low coefficient of thermal expansion – Minimizes thermal stress in cyclic temperature environments.
Wide range of thicknesses – From 0.5mm thin sheets to 100mm thick plates, customizable to your specifications.
Typical Chemical Composition (ASTM B435)
| Element | Content (%) |
| Nickel (Ni) | Balance |
| Chromium (Cr) | 20.5 – 23.0 |
| Iron (Fe) | 17.0 – 20.0 |
| Molybdenum (Mo) | 8.0 – 10.0 |
| Cobalt (Co) | 0.5 – 2.5 |
| Carbon (C) | 0.05 – 0.15 |
| Tungsten (W) | 0.20 – 1.0 |
Mechanical Properties (Typical at Room Temperature)
| Property | Value |
| Tensile Strength (MPa) | ≥ 690 |
| Yield Strength (MPa) | ≥ 310 |
| Elongation (%) | ≥ 30 |
| Hardness (HRB) | ≤ 95 |
Our Nickel Alloy X plates and sheets are supplied with mill test certificates and can be customized with additional processing such as plasma cutting, laser cutting, or edge preparation. We offer flexible packaging (wooden cases, pallets, or steel frames) to ensure safe transit via Tianjin, Shanghai, Qingdao, or Ningbo ports.
Trust & Reliability
Wuxi Yansheng Technology Co., Ltd. has been a trusted supplier since 2017, with an annual export value of US$50–100 million. We hold multiple management system certifications including ISO9001, ISO14000, OHSAS18001, and SA8000, ensuring product quality, environmental responsibility, and ethical manufacturing. Our 101–200 employees operate a 1,000–3,000 sqm facility equipped with advanced testing equipment (spectrometers, tensile testers, etc.). We have served over 50 countries across North America, Europe, Southeast Asia, and the Middle East, with many repeat customers in the gas turbine industry.
We are committed to providing competitive pricing, on-time delivery, and technical support. Whether you need standard sizes or custom dimensions, our team is ready to assist. Contact us today for a quotation or to discuss your specific requirements.
Frequently Asked Questions
Q: What is the difference between Nickel Alloy X and Hastelloy X?
A: Nickel Alloy X (UNS N06002) is the same as Hastelloy X. It is a nickel-chromium-iron-molybdenum superalloy known for high-temperature strength and oxidation resistance.Q: Can you supply plates with thickness over 100mm?
A: Yes, we can produce thicker plates up to 200mm upon request. Please contact us for custom dimensions.Q: What certifications do you provide with the material?
A: We provide mill test certificates (MTC) per ASTM B435, and we can also provide third-party inspection reports if required.Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 500 kg. For custom sizes, MOQ may vary; please inquire.Q: Is this material suitable for welding?
A: Yes, Nickel Alloy X has excellent weldability using common techniques like TIG, MIG, or resistance welding. Preheating is not required, but post-weld heat treatment may be performed for specific applications.Q: How do you ensure the quality of each batch?
A: Every batch is tested for chemical composition, tensile strength, yield strength, and elongation. We also perform ultrasonic inspection for internal defects when requested.Q: What is the typical lead time for an order?
A: For standard sizes, lead time is 15–20 working days after confirmation. For custom orders, it may be 25–30 working days.Q: Do you offer samples for evaluation?
A: Yes, we can provide small samples (e.g., 200x200mm) at a nominal cost. Shipping charges apply.
