As a leading manufacturer based in Hengshui, Hebei, Anping Xinye Metal Wire Mesh Products Co., Ltd brings over two decades of expertise in producing high-quality road safety products. Our Heavy Duty Hot Dip Galvanized W Beam Guardrail is specifically engineered for municipal road construction, combining robust structural integrity with exceptional corrosion resistance. This guardrail system is designed to absorb impact energy effectively, protecting vehicles and pedestrians while maintaining long-term performance in harsh outdoor environments.
The W beam profile is optimized to redirect vehicles upon collision, reducing the risk of severe damage. Each guardrail undergoes a strict hot dip galvanizing process, ensuring a uniform zinc coating that meets industry standards for thickness and adhesion. Whether you are upgrading urban roads or constructing new infrastructure, our guardrail delivers reliable safety and durability.
Key Features & Technical Specifications
- High-Strength Steel: Manufactured from premium Q235 steel, offering excellent tensile strength and impact resistance.
- Hot Dip Galvanized Coating: Average zinc coating thickness ≥ 85μm (optional heavier coating available), providing superior anti-corrosion protection for 15–20 years in normal conditions.
- W Beam Design: The wave height of 75mm and span width of 310mm effectively distribute collision forces, enhancing vehicle containment.
- Easy Installation: Pre-drilled holes and modular components allow quick assembly with standard bolts and posts, reducing labor time on site.
- Customizable Specifications: Available in plate thicknesses of 2.5mm, 3.0mm, or 4.0mm, with lengths from 1200mm to 4320mm to suit different road classifications.
- Compliance with Standards: Designed in accordance with international road safety guidelines (e.g., AASHTO M180), with test reports available upon request.
- Low Maintenance: The galvanized finish requires minimal upkeep, saving long-term costs for municipalities.
| Parameter | Standard Value | Optional Range |
|---|---|---|
| Material | Q235 Steel | Q345 available upon request |
| Surface Treatment | Hot Dip Galvanized (HDG) | Zinc-aluminum alloy optional |
| Beam Length | 4320 mm | 2000–6000 mm |
| Wave Height | 75 mm | 65–85 mm |
| Plate Thickness | 3.0 mm | 2.5 / 3.0 / 4.0 mm |
| Zinc Coating Weight | ≥ 600 g/m² | Up to 1000 g/m² |
Our heavy-duty guardrail is widely used in municipal road construction, highway medians, bridge parapets, and parking lot perimeters. The hot dip galvanized finish ensures the product withstands extreme weather conditions, including rain, snow, and salt spray, without rusting or weakening. For projects requiring additional crashworthiness, we offer reinforced end terminals and post options.
Anping Xinye Metal Wire Mesh Products Co., Ltd has supplied guardrails to numerous municipal projects across China and overseas. With a dedicated team of engineers and a comprehensive quality control system, we guarantee consistent product dimensions and performance. Each shipment is accompanied by a mill test certificate and packing list.
We understand that municipal road contractors need reliable delivery schedules. Our factory maintains a large inventory of raw materials, enabling fast turnaround for orders of any size. Whether you need 500 meters or 50,000 meters, we can meet your requirements with competitive pricing.
Why Choose Anping Xinye Guardrails?
- Over 20 years of manufacturing experience in metal wire mesh and road safety products.
- Strict quality inspection at every stage: incoming material, production, and final packing.
- Flexible customization: length, thickness, post spacing, and color (upon request).
- Professional export packaging: steel pallets or wooden crates to prevent damage during transit.
- Responsive customer service: technical drawings and installation guidance provided.
We invite you to contact us for a quotation or sample. Our team is ready to assist you with product selection and shipping logistics. Partner with a trusted manufacturer to ensure your municipal road project meets the highest safety standards.
Frequently Asked Questions (FAQ)
Q1: What is the typical lifespan of your hot dip galvanized guardrail?
A: Under normal atmospheric conditions, the hot dip galvanized coating provides corrosion protection for 15–20 years before any maintenance is needed. The actual lifespan may vary depending on the environment (e.g., coastal areas with high salt content may require thicker coating).
Q2: Can you provide guardrails in different lengths?
A: Yes, we offer customizable lengths from 1200mm to 6000mm. The standard length is 4320mm, but we can cut to your specific requirements. Please inform us of your needed dimensions when placing an order.
Q3: Do you have test reports for crashworthiness?
A: Our guardrail design follows AASHTO M180 guidelines, and we can provide test reports from third-party laboratories upon request. For specific project requirements, we can also arrange additional testing.
Q4: What is the minimum order quantity (MOQ)?
A: Our MOQ for standard guardrail sections is 1000 meters. For smaller quantities, please contact our sales team; we may accommodate sample orders for evaluation.
Q5: How is the guardrail packaged for shipping?
A: Each guardrail beam is bundled with steel strapping and wrapped in waterproof paper. For sea freight, we use strong wooden pallets or steel crates to prevent deformation. Post and hardware are packed separately in cartons or bags.
Q6: Can you provide installation hardware and posts?
A: Yes, we offer complete guardrail systems including steel posts, blockouts, bolts, nuts, and washers. All hardware is also hot dip galvanized for consistency. We can supply a full bill of materials for your project.
Q7: What is the delivery time for a typical order?
A: For standard specifications, production takes 15–20 working days after receiving the deposit. Custom orders may require 25–30 days. We will confirm the exact lead time in the proforma invoice.
Q8: Do you offer discounts for large volume orders?
A: Yes, we provide tiered pricing based on order quantity. Please contact us with your estimated volume, and we will give you a competitive quotation. Long-term cooperation is always welcome.
