Anping Xinye Metal Wire Mesh Products Co., Ltd is proud to present our Galvanized PVC Stainless Steel Concertina Razor Blade Barbed Wire in models BTO-22, BTO-60, and CBT-65. Designed for high-security applications, this concertina wire combines robust materials with precision engineering to deliver reliable perimeter protection. Whether you need to secure a military base, a prison, a commercial facility, or a private property, our razor wire offers a formidable barrier that is both durable and cost-effective.
Our concertina razor wire is manufactured using advanced machinery and strict quality control, ensuring consistent blade sharpness and structural integrity. The wire is available in three material options: galvanized steel for corrosion resistance, PVC-coated for added weather protection and aesthetic appeal, and stainless steel for maximum durability in harsh environments. Each model — BTO-22, BTO-60, and CBT-65 — is designed to suit different security levels and installation requirements.
Key Features & Advantages
- High Security: Sharp razor blades effectively deter and delay intruders, making it ideal for high-risk perimeters.
- Durable Materials: Choose from galvanized, PVC-coated, or stainless steel finishes to match your environmental conditions.
- Easy Installation: Concertina coils are pre-compressed and can be quickly deployed using standard mounting hardware.
- Customizable: Available in various coil diameters, blade lengths, and spacing to meet specific project needs.
- Long Service Life: Hot-dip galvanized and stainless steel options provide excellent resistance to rust and corrosion.
- Compliance with International Standards: Our products are designed to meet common security fencing requirements (certifications available upon request).
Technical Specifications
| Parameter | BTO-22 | BTO-60 | CBT-65 |
|---|---|---|---|
| Blade Length | 22 mm | 60 mm | 65 mm |
| Blade Spacing | 26 mm | 28 mm | 45 mm |
| Coil Diameter | 450 mm, 600 mm, 900 mm | 600 mm, 900 mm | 900 mm, 1200 mm |
| Wire Core Diameter | 2.5 mm ± 0.1 mm | 2.5 mm ± 0.1 mm | 3.0 mm ± 0.1 mm |
| Blade Thickness | 0.5 mm | 0.6 mm | 0.7 mm |
| Available Materials | Galvanized, PVC, Stainless Steel | Galvanized, PVC, Stainless Steel | Galvanized, PVC, Stainless Steel |
Applications
- Military & Defense: Perimeter fencing for bases, ammunition depots, and sensitive areas.
- Correctional Facilities: Prisons, detention centers, and rehabilitation institutes.
- Industrial & Commercial: Factories, warehouses, power plants, and data centers.
- Infrastructure: Airports, seaports, railway stations, and government buildings.
- Private Security: High-end residential communities, farms, and estates.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we are committed to providing superior security solutions. With our factory located in Hengshui, Hebei — a major wire mesh production hub in China — we have the resources and expertise to deliver high-quality razor wire at competitive prices. Our experienced team ensures rigorous quality checks at every stage, from raw material selection to final packaging. Whether you need a standard BTO-22 coil or a custom CBT-65 setup, we can meet your requirements.
We welcome inquiries from distributors, contractors, and end-users. Contact us today for a quote or sample. Our customer service team is ready to assist you with technical support and logistics. Choose Anping Xinye for dependable security fencing that stands the test of time.
Frequently Asked Questions
-
What is the difference between BTO-22, BTO-60, and CBT-65?
These models differ in blade length and spacing. BTO-22 has 22 mm blades with 26 mm spacing, suitable for medium security. BTO-60 has 60 mm blades with 28 mm spacing for higher deterrence. CBT-65 features 65 mm blades with 45 mm spacing, offering maximum intimidation and is often used in military perimeter. -
Can I choose different colors for PVC coating?
Yes, PVC coating is available in various colors such as green, yellow, black, and blue. Contact our sales team for color options and minimum order quantities. -
What is the typical lifespan of this razor wire?
Lifespan depends on the material and environment. Galvanized steel can last 8–12 years in moderate conditions; PVC-coated adds additional protection; stainless steel can last 20+ years in harsh environments. -
Do you provide samples before bulk order?
Yes, we offer free samples for evaluation. You only need to pay for shipping. Samples are typically 1 meter of coil or a small piece for testing. -
What is the packaging method?
Each coil is compressed and wrapped with waterproof paper, then packed in wooden pallets or cartons for export. Custom packaging is available upon request. -
Can this wire be used for temporary fencing?
Absolutely. Concertina wire is easy to deploy and remove, making it suitable for temporary security at events, construction sites, or emergency situations. -
Do you support ODM/OEM orders?
Yes, we can customize wire diameter, blade shape, coil diameter, and packaging according to your specifications. MOQ applies for custom items. -
How do I install the concertina wire?
Installation typically requires Y-shaped or picket posts, tensioning wires, and clamps. We provide installation guidelines and accessories. Professional installation recommended for high-security applications.
