As a professional manufacturer with over 25 years of experience in the wire mesh industry, Anping County Boli Hardware Wiremesh Products Factory (established in 1998) proudly presents our 316 Stainless Steel Weld Mesh Screen specifically designed for chemical filtering applications. With an annual export value exceeding US$5 million and serving markets across North America, Europe, Southeast Asia, and beyond, we understand the critical requirements of precision filtration. This mesh features a fine 0.3mm wire diameter and 0.8mm hole size, delivering exceptional corrosion resistance and mechanical strength for demanding chemical environments.
Our 316 stainless steel weld mesh screen is manufactured using high-quality raw materials sourced from reputable mills, ensuring consistent alloy composition and durability. The welding process creates a strong, rigid structure that maintains its dimensional stability under high pressure and temperature fluctuations. Whether you are filtering aggressive chemicals, separating fine particles, or reinforcing composite materials, this mesh provides reliable performance with minimal maintenance.
Key Features & Technical Specifications:
- Corrosion Resistance: 316 stainless steel contains molybdenum, offering superior resistance to chlorides, acids, and alkaline solutions compared to 304 grade. Ideal for chemical processing, pharmaceuticals, and wastewater treatment.
- Precision Dimensions: Wire diameter of 0.3mm ±0.02mm and hole size of 0.8mm ±0.05mm ensure consistent filtration accuracy. The open area is approximately 40%, balancing flow rate and particle retention.
- High Strength & Durability: Welded construction provides excellent tensile strength, resisting deformation under mechanical stress. The mesh can withstand operating temperatures up to 800°C (in reducing atmospheres) and pressures up to 50 bar (depending on support structure).
- Easy Cleaning & Reusability: Smooth surface finish allows straightforward backwashing or chemical cleaning, extending service life. Can be cut, bent, or welded into custom shapes.
- Customizable Options: Available in various widths (0.5m to 2.5m) and lengths (rolls up to 30m or cut-to-size sheets). Edge treatments (selvedge, hemmed, or reinforced) can be applied upon request.
| Parameter | Value |
|---|---|
| Material | 316 Stainless Steel (UNS S31600) |
| Wire Diameter (mm) | 0.3 |
| Hole Size (mm) | 0.8 |
| Open Area (%) | ~40% |
| Mesh Count (wires per inch) | Approx. 24 x 24 |
| Tensile Strength (N/mm²) | ≥ 520 |
| Maximum Operating Temperature | 800°C (reducing), 400°C (oxidizing) |
| Standard Roll Width | 1m, 1.2m, 1.5m (customizable) |
Advantages for Your Application:
- Chemical Filtering: The fine mesh effectively removes particles down to 0.8mm, suitable for pre-filtration, safety screens, or catalyst support in reactors. The 316 grade resists attack from sulfuric acid, phosphoric acid, and chloride-containing solutions.
- Versatile Use: Beyond chemical filtering, this mesh is used in petrochemical, food processing, water treatment, and mining industries for sieving, straining, and shielding.
- Cost-Effective: Long service life reduces replacement frequency. The welded structure eliminates loose wires, providing consistent performance over time.
- Global Logistics: Our factory in Hengshui, Hebei, China, ships from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring fast delivery to international customers.
Trust & Quality Assurance: With over two decades of manufacturing excellence, Anping County Boli Hardware Wiremesh Products Factory has built a reputation for quality and reliability. Our annual export value of US$5–10 million demonstrates the trust customers place in our products. We welcome third-party inspections and can provide material test certificates upon request. Every batch of 316 stainless steel mesh is tested for wire diameter, hole size, and chemical composition before shipment.
We are committed to supporting your project from sample development to bulk production. Contact our sales team today to discuss your specific requirements, request a quote, or ask for a free sample. Let us help you achieve optimal filtration performance with our premium 316 stainless steel weld mesh screen.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between 316 and 304 stainless steel weld mesh?
A: 316 stainless steel contains 2-3% molybdenum, which significantly improves corrosion resistance against chlorides and acids. For chemical filtering applications involving aggressive media, 316 is the recommended choice. 304 is suitable for milder environments. -
Q: Can this mesh be used for high-temperature filtration?
A: Yes, 316 stainless steel can withstand temperatures up to 800°C in reducing atmospheres. However, in oxidizing environments, maximum continuous service temperature is around 400°C. Please consult with our engineers for your specific temperature conditions. -
Q: What is the tolerance for wire diameter and hole size?
A: Standard tolerance is ±0.02mm for wire diameter and ±0.05mm for hole size. Tighter tolerances are available upon request for critical applications. -
Q: Do you offer custom sizes or cut-to-length pieces?
A: Absolutely. We can produce rolls up to 30m length, or cut sheets to your exact dimensions. Custom widths ranging from 0.5m to 2.5m are possible. Edge finishing options include hemmed edges, reinforced borders, or welded strips. -
Q: How is the mesh packaged for export?
A: Standard packaging includes wooden pallets, reinforced with steel straps, and wrapped in waterproof material. For small orders, we use strong cardboard boxes. Packaging can be customized to meet your handling requirements. -
Q: Can you provide a material test certificate (MTC) or mill certificate?
A: Yes, we can provide a certificate of compliance or mill test reports from our steel suppliers. Additional testing by third-party laboratories can be arranged at extra cost. -
Q: What is the typical lead time for bulk orders?
A: For standard sizes (1m x 30m rolls), lead time is 15-20 working days after order confirmation. Custom sizes may require 20-25 working days. We offer express production for urgent orders upon request. -
Q: Is the mesh suitable for food contact applications?
A: 316 stainless steel is generally recognized as safe for food contact (FDA compliant). However, please verify local regulations and advise us if you require specific surface finishing (e.g., passivation or electropolishing) to meet hygiene standards.
