Help Center20 Micron Nylon Mesh Filter, 100% PA66, 150°C Max Temp, for Liquid Filtration
Product Spotlights
Related Products
-
300 Micron Nylon Mesh, High Tensile Strength, 0.5mm Thickness, for SievingUS$ 1MOQ: 10 Square Meters -
Standard Compliant Nylon Mesh Screen, Technical Support, 30-Day ReplacementUS$ 1MOQ: 10 Square Meters
-
Water Purification Nylon Mesh Screen, 100 Micron, for Sediment RemovalUS$ 1MOQ: 10 Square Meters
-
FDA Food Grade Nylon Filter Mesh/ 100 220 500 Micron Food Grade Nylon Filter Mesh ClothUS$ 1 - 20MOQ: 10 Square Meters
-
Food Grade Nylon Filter Mesh/ 100 220 500 600 Micron Food Grade Nylon Mesh ClothUS$ 1 - 20MOQ: 10 Square Meters
Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer since 1998, specializing in precision wire mesh products. Our 20 Micron Nylon Mesh Filter, made from 100% PA66 virgin nylon, delivers consistent filtration performance for demanding liquid applications. With a maximum operating temperature of 150°C, this filter is engineered to withstand thermal stress while maintaining dimensional stability. Whether you are in chemical processing, food & beverage, or water treatment, our mesh offers reliable particle retention and long service life.
Each roll of our nylon mesh is produced using advanced weaving technology, ensuring uniform pore distribution and high tensile strength. The 20 micron opening effectively captures suspended solids, sediments, and fine contaminants, making it an ideal choice for pre-filtration, polishing, or strainer applications. The PA66 material provides excellent resistance to oils, solvents, and weak acids, extending the filter's lifespan in harsh environments.
We understand that filtration needs vary by industry, which is why we offer customization options including width, length, and packaging. Our mesh can be cut to size or supplied as rolls, sheets, or pre-cut discs. The fabric is lightweight, flexible, and easy to install in existing filter housings or custom frames. Below, we have detailed the key specifications and benefits of our 20 Micron Nylon Mesh Filter.
Key Features & Technical Specifications
- Material: 100% PA66 Nylon (virgin, no recycled content) – ensures consistent quality and chemical resistance.
- Mesh Opening: 20 Microns ±3% tolerance – precise particle retention for fine filtration.
- Maximum Operating Temperature: 150°C (302°F) – suitable for hot liquids and steam sterilization.
- Open Area: Approximately 30-35% – balances flow rate and filtration efficiency.
- Thickness: 0.2mm – 0.5mm (depending on weave pattern) – offers robustness without excessive pressure drop.
- Width: Available in 1m, 1.2m, 1.5m, or custom widths – fits various filter frames.
- Color: White (natural) – can be dyed if required, but standard is undyed for purity.
- Packaging: Rolls of 30m, 50m, or 100m, with protective wrapping to prevent contamination.
| Parameter | Value |
|---|---|
| Mesh Count | Approx. 500-600 per inch (depends on wire diameter) |
| Wire Diameter | 0.05mm – 0.08mm |
| Tensile Strength (MD) | ≥ 500 N/5cm |
| Temperature Resistance | Continuous: 150°C, Intermittent: 170°C |
| Chemical Resistance | Good against oils, greases, alkalis, and most organic solvents |
| Filtration Grade | 20 micron (nominal) |
Advantages & Customer Benefits
- High Purity & Safety: 100% virgin PA66 means no impurities or contaminants that could leach into your process fluid. Ideal for food contact applications (FDA compliance available upon request).
- Thermal Stability: Withstand temperatures up to 150°C continuously, making it suitable for hot filtration, sterilization, and high-temperature processes without deformation or degradation.
- Excellent Flow Rate: The open area design (30-35%) ensures minimal pressure drop while capturing fine particles, reducing energy consumption in pumping systems.
- Durability & Reusability: The mesh can be cleaned by backwashing or ultrasonic cleaning, extending its service life and reducing replacement costs.
- Versatile Applications: Used in chemical filtration, pharmaceutical, food & beverage (juice, wine, beer), paint & coatings, ink, water treatment, and industrial liquid processing.
- Customizable Options: We can supply mesh in various widths, lengths, and with edge finishes (selvedge, taped, or bonded) to meet your specific installation requirements.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
With over 25 years of manufacturing experience (since 1998), we have built a reputation for quality and reliability. Our annual export value exceeds US$5 million, serving customers across North America, South America, Europe, Asia, Africa, and Oceania. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery worldwide.
Every batch of our 20 Micron Nylon Mesh Filter undergoes strict quality control – from raw material inspection to weaving tension monitoring and final micron rating verification. Our factory is equipped with advanced looms and testing equipment to guarantee consistency. We are committed to providing products that meet or exceed your expectations.
We invite you to contact us for a quote or free sample. Our team is ready to discuss your specific filtration needs, recommend the right mesh configuration, and provide competitive pricing. Let us be your trusted partner in liquid filtration solutions.
Frequently Asked Questions (FAQ)
-
Q: What is the exact mesh opening tolerance?
A: Our 20 micron nylon mesh has a tolerance of ±3% (i.e., 19.4 to 20.6 microns) under standard testing conditions. -
Q: Can this mesh be used for air filtration?
A: This product is designed for liquid filtration. For air/gas filtration, we recommend our polyester or stainless steel mesh options. -
Q: Is the PA66 material food-grade?
A: Yes, PA66 is generally recognized as safe for food contact. We can provide FDA compliance documentation upon request. -
Q: What is the maximum pressure drop the mesh can handle?
A: Typical operating pressure drop is below 0.5 bar. For higher differential pressures, consider using a support screen or thicker mesh. -
Q: How do I clean the mesh?
A: Rinse with water or mild detergent, or use ultrasonic cleaning. Avoid strong acids or high-pressure steam above 150°C. -
Q: Can you supply in non-standard widths?
A: Yes, we can customize width from 0.5m up to 2m. Minimum order quantity may apply for custom sizes. -
Q: What is the typical lead time?
A: For standard rolls (1m width, 50m length), lead time is 7-10 working days. Custom orders may take 15-20 days. -
Q: Do you offer samples?
A: Yes, we provide free samples (A4 size) for quality evaluation. Shipping cost is borne by the buyer.
