Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer with over 25 years of experience since 1998, exporting to global markets with annual export value of US$5-10 million. Our Plain Weave Elliptical Screen Panel (1.2mm wire, 1.5m x 3m sheet, industrial grade) is engineered to deliver superior performance in demanding screening applications. The unique elliptical openings provide excellent anti-clogging properties while maintaining high strength and durability, making it an ideal choice for mining, aggregate, and industrial processing industries.
This product is meticulously woven using high-quality steel wire with precise 1.2mm diameter, ensuring consistent opening geometry and long service life. The plain weave pattern creates a stable structure that withstands heavy loads and continuous vibration. Below are the key technical specifications:
| Parameter | Value |
|---|---|
| Wire Diameter | 1.2 mm (±0.05 mm) |
| Panel Size | 1.5 m x 3 m (custom sizes available) |
| Weave Type | Plain weave |
| Opening Shape | Elliptical (customizable long/short axis) |
| Material Options | Low carbon steel, stainless steel (304, 316), or as requested |
| Surface Treatment | Plain, galvanized, or PVC coated (optional) |
| Tensile Strength | Industry standard for industrial grade |
Product Features & Benefits
- Anti-Clogging Design – Elliptical openings prevent material wedging, reducing downtime and improving screening efficiency.
- High Strength & Durability – Plain weave structure with 1.2mm wire offers excellent load-bearing capacity for heavy-duty industrial use.
- Precision Manufacturing – Strict quality control ensures uniform opening size and consistent panel dimensions.
- Versatile Applications – Suitable for sand, gravel, coal, ore, recycled materials, and other bulk solids in mining, quarrying, and processing plants.
- Customizable Options – Available in various materials, coatings, and custom sizes to meet specific project requirements.
- Cost-Effective – Long service life reduces replacement frequency, offering excellent value for money.
Why Choose Our Plain Weave Elliptical Screen Panel?
Our screen panels are manufactured using advanced weaving machinery and stringent quality checks. Each panel is inspected for wire tension, opening geometry, and flatness. The 1.5m x 3m sheet size is a standard industrial dimension, easy to install in most vibrating screens. With over two decades of export experience, we have supplied products to clients across North America, Europe, South America, Africa, and Asia, earning a reputation for reliability and consistency.
We understand that every screening application is unique. Our engineering team can assist in selecting the optimal opening size, material grade, and surface treatment to match your specific material characteristics and operational conditions. Whether you need additional corrosion resistance for wet applications or higher wear resistance for abrasive materials, we have flexible solutions.
Frequently Asked Questions
-
Q: What materials are available for this screen panel?
A: We offer low carbon steel, stainless steel (304, 316), and other alloys upon request. The standard material for industrial grade is high-quality carbon steel. -
Q: Can I get custom elliptical opening dimensions?
A: Yes, we can customize the long and short axis of the elliptical openings to match your particle size requirements. Please provide the desired opening dimensions. -
Q: What surface treatment options do you provide?
A: Standard is plain (black) finish. Galvanizing, PVC coating, and other anti-corrosion treatments are available as optional. -
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ is typically 10 sheets, but smaller trial orders can be discussed. Contact us for details. -
Q: How long is the delivery time?
A: For standard specifications, delivery is within 15-20 days after order confirmation. Custom orders may take 20-30 days. -
Q: Do you offer samples?
A: Yes, we can provide samples of the screen mesh for quality evaluation. Sample cost and shipping are negotiable. -
Q: What packaging is used for export?
A: Panels are packed in wooden crates or steel pallets to ensure safe transportation. Waterproof paper and strapping are used for protection. -
Q: Can this panel be used in high-temperature environments?
A: Standard carbon steel is suitable for moderate temperatures. For high-temperature applications, we recommend stainless steel or special alloys. Please consult our team.
Backed by a factory with 25+ years of manufacturing excellence, annual export revenue of US$5-10 million, and shipping from major Chinese ports (Tianjin, Qingdao, Shanghai, etc.), Anping County Boli Hardware Wiremesh Products Factory is your reliable partner for industrial screening solutions. Our professional team is ready to provide technical support, competitive pricing, and timely delivery. Contact us today to discuss your requirements or request a quote!
