Welcome to Shanghai Zhibang Valve Manufacture Co., Ltd. As a professional manufacturer established in 2016 with an annual export value of US$1 million to US$1.5 million, we take pride in offering high-quality marine valves. Our CB/T4480 Marine Bronze Electric Ball Valve is designed for reliable performance in demanding marine environments. Built from durable bronze and equipped with an electric actuator, this valve ensures precise flow control while withstanding corrosion from seawater. Each unit comes with a 12-month warranty and a mill test report, guaranteeing material integrity and workmanship.
This valve is widely used in shipbuilding, offshore platforms, and coastal facilities. It meets the Chinese CB/T4480 standard, ensuring compatibility with international marine systems. The combination of bronze construction and electric actuation provides long service life, low maintenance, and easy automation. Below we detail its key features, technical specifications, and benefits for your operations.
Key Features & Benefits
- Corrosion-Resistant Bronze Body: The valve body is made of high-quality bronze, which offers excellent resistance to seawater and saline atmospheres, significantly extending the valve's lifespan in marine applications.
- Electric Actuator with IP67 Protection: The fully sealed electric actuator provides reliable remote operation, with manual override available for emergency use. IP67 rating ensures protection against dust and temporary immersion.
- Precision Manufacturing: Following CB/T4480 standard, the valve features tight shut-off and low torque operation, reducing energy consumption and improving system efficiency.
- Mill Test Report Included: Every valve is supplied with a mill test report that verifies chemical composition and mechanical properties of the bronze material, ensuring traceability and quality assurance.
- 12-Month Warranty: We stand behind our product with a full year warranty against manufacturing defects, giving you peace of mind for your investment.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | Bronze (ASTM B62 / C83600 equivalent) |
| Standard | CB/T4480 (Chinese Marine Standard) |
| Pressure Rating | PN16 / PN25 (customizable up to PN40) |
| Connection Type | Flanged (GB/T 9113) or Threaded (BSP/NPT) |
| Size Range | DN15 – DN150 (1/2" – 6") |
| Actuator Voltage | AC 220V / DC 24V (other voltages available upon request) |
| Protection Class | IP67 (optional IP68) |
| Operating Temperature | -20°C to +120°C |
| Applicable Media | Seawater, fresh water, oil, gas, and other non-aggressive fluids |
Our CB/T4480 Marine Bronze Electric Ball Valve is engineered to deliver consistent performance in harsh marine conditions. The electric actuator allows for easy integration with automation systems, enabling remote control and monitoring. The valve's compact design saves space on ship piping systems, while the bronze body ensures low magnetic interference – a critical factor for naval vessels.
Each valve undergoes rigorous testing before shipment, including shell pressure test, seat leakage test, and actuator functional test. The mill test report provides complete material traceability, meeting the requirements of classification societies such as CCS, DNV, or ABS upon request. We also offer customization options like special coatings, extended stem lengths, or limit switches based on your project needs.
Why Choose Shanghai Zhibang Valve?
Since 2016, we have been dedicated to manufacturing high-quality valves for marine and industrial applications. Our factory is ISO9001 certified, ensuring consistent quality management throughout production. With an annual export value of over US$1 million, we serve customers from North America to Southeast Asia, Africa to Europe. Our port of shipment includes Shanghai, Guangzhou, Hong Kong, and Beijing, facilitating fast and cost-effective logistics worldwide.
We understand that reliability is paramount in marine operations. That's why every CB/T4480 Marine Bronze Electric Ball Valve is backed by a 12-month warranty and a comprehensive after-sales service team. Whether you need a single valve for a repair or a large batch for a new shipbuilding project, we can deliver with competitive pricing and short lead times. Contact us today to discuss your requirements or request a quotation.
Frequently Asked Questions
-
Q: What is the difference between your CB/T4480 valve and standard bronze ball valves?
A: Our valve is manufactured specifically to the Chinese marine standard CB/T4480, which includes stricter material requirements, tighter tolerances, and specific testing procedures for marine environments. It also comes with a mill test report for material certification. -
Q: Can the actuator be replaced with a manual handle or pneumatic actuator?
A: Yes, we offer the same valve body with manual gearbox or pneumatic actuator options. The electric version is compatible with standard mounting flanges (ISO 5211), making it easy to retrofit. -
Q: What voltage options are available for the electric actuator?
A: Standard voltages are AC 220V and DC 24V. Other voltages (AC 110V, DC 12V, 380V, etc.) are available upon request. Please specify your requirement when ordering. -
Q: Is the valve suitable for use with potable water?
A: Yes, bronze is an approved material for potable water systems. However, if you require a specific liner or coating for drinking water, we can customize according to your standards. -
Q: How long is the lead time for a standard order?
A: For stock sizes (DN15-DN50), lead time is typically 7-10 working days. For larger sizes or custom configurations, please allow 15-25 working days depending on quantity. -
Q: Do you provide certificates from classification societies like CCS or DNV?
A: We can arrange third-party inspection and certification upon request. Additional costs and time will apply. The mill test report is included as standard. -
Q: What is the warranty coverage?
A: Our 12-month warranty covers manufacturing defects in materials and workmanship. It does not cover damage caused by improper installation, misuse, or wear and tear. We will replace or repair defective valves free of charge. -
Q: Can I get a sample before placing a bulk order?
A: Yes, we accept sample orders. Sample cost is negotiable, and we can deduct it from the first bulk order. Shipping is at customer's expense.
With over 8 years of experience in valve manufacturing, Shanghai Zhibang Valve is your trusted partner for marine bronze valves. Our commitment to quality, on-time delivery, and customer satisfaction has earned us a strong reputation in global markets. Choose our CB/T4480 Marine Bronze Electric Ball Valve for a reliable, long-lasting solution that meets the highest standards. Contact us now to place your order or request more information.
