As a trusted manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory specializes in producing high-performance filter media. Our Nylon Filter Cloth for Chemical Filtration, 50 Micron is designed to meet the rigorous demands of industrial filtration processes. With exceptional resistance to solvents and organic chemicals, this filter cloth delivers consistent performance and extended service life, making it a reliable choice for chemical, pharmaceutical, and food processing applications.
Our product stands out for its high precision (50 micron) and superior durability. The monofilament nylon material ensures uniform pore size, efficient solid-liquid separation, and excellent mechanical strength. Whether you need to filter aggressive chemicals, acids, or alkalis, this cloth withstands harsh conditions without degrading. Backed by our factory's decades of experience and global export expertise, you can trust the quality and consistency of every roll.
Key Features & Technical Specifications
- Accurate Filtration: 50 micron nominal pore size ensures precise separation of particles down to 0.05 mm.
- Chemical Resistance: Resistant to most solvents, oils, alcohols, and mild acids/alkalis – ideal for chemical processing.
- High Durability: Nylon monofilament construction provides excellent tensile strength and abrasion resistance, reducing replacement frequency.
- Thermal Stability: Operates effectively in temperatures up to 120°C (248°F), with optional heat-set treatment for dimensional stability.
- Easy Cleaning: Smooth surface allows for quick washing and reuse; compatible with ultrasonic cleaning methods.
- Customizable: Available in various widths (up to 2.5m) and lengths; can be cut to size or fabricated into filter bags, discs, or belts.
| Parameter | Specification |
| Material | 100% Nylon 6 or Nylon 66 |
| Mesh Count | Approx. 300 threads/inch (depending on weave) |
| Open Area | 35% – 45% (plain weave) |
| Tensile Strength (Warp) | ≥ 800 N/5cm |
| Max Operating Temperature | 120°C (continuous) |
| Weight | Approx. 120 – 150 g/m² |
| Standard Roll Size | 1.0m × 50m (customizable) |
Benefits for Your Application
- Improved Filtration Efficiency: Consistent pore size minimizes particle bypass and ensures high-quality filtrate.
- Reduced Downtime: High mechanical strength and chemical resistance prolong service life, lowering replacement costs.
- Versatile Compatibility: Suitable for use with solvents, dyes, pigments, pharmaceuticals, and edible oils.
- Cost-Effective Solution: Factory-direct pricing and bulk availability reduce your procurement expenses.
Our factory, Anping County Boli Hardware Wiremesh Products Factory, has been serving global clients since 1998. With an annual export value of US$5 Million – US$10 Million, we ship to major ports including Tianjin, Qingdao, Shanghai, and Foshan. Our products are trusted in markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania. We maintain strict quality control from raw material to finished goods, ensuring every roll meets your specifications. We offer free samples for evaluation and can customize dimensions, packaging, and even weave patterns to suit your exact needs. Contact us today for a quote or technical consultation – let our experience work for you.
Frequently Asked Questions
-
Q: What is the maximum temperature this nylon filter cloth can withstand?
A: It can be used continuously at temperatures up to 120°C (248°F). For higher temperatures, we recommend polyester or PEEK options. -
Q: Can I get custom sizes or cut pieces?
A: Yes, we offer custom widths and lengths. We can also provide pre-cut sheets, filter bags, or discs upon request. -
Q: Is this cloth suitable for strong acids or alkalis?
A: Nylon has good resistance to mild acids and alkalis, but for strong acids (e.g., sulfuric, nitric), we suggest using polypropylene or PTFE filter media. Please consult our technical team for specific chemical compatibility. -
Q: How do I clean and reuse the filter cloth?
A: For most applications, rinsing with water or a mild solvent is sufficient. Ultrasonic cleaning is also effective. Avoid harsh mechanical scrubbing to preserve the mesh. -
Q: What certifications do you have?
A: Our factory is ISO 9001 certified (optional – please confirm with us). Quality control reports are available upon request. -
Q: What is the typical lead time for standard rolls?
A: For standard sizes (1.0m × 50m), we usually ship within 7–15 working days after order confirmation. Custom orders may take 15–25 days. -
Q: Do you provide samples before bulk order?
A: Yes, we offer free samples (shipping cost may apply) for you to test the performance in your process. -
Q: Can this cloth be used for vacuum filtration or pressure filtration?
A: Yes, its high tensile strength makes it suitable for both vacuum and low-pressure filtration systems. For high-pressure applications, we recommend a reinforced weave.
