As a leading manufacturer from Anping Xinye Metal Wire Mesh Products Co., Ltd in Hengshui, Hebei, China, we are proud to present our premium Fiberglass Mesh 160g/m², 5x5mm Opening. This product is engineered to provide exceptional reinforcement for construction and renovation projects. With a 1-year warranty and 7-day replacement guarantee, we stand behind the quality and durability of every roll. Our factory-direct pricing ensures you receive the best value without compromising on performance.
Our fiberglass mesh is manufactured using high-quality alkali-resistant fiberglass yarns, woven into a stable grid structure. The 160g/m² density and 5x5mm opening size offer an optimal balance between strength and flexibility, making it ideal for both interior and exterior applications. Whether you are reinforcing walls, enhancing insulation systems, or protecting surfaces from cracking, this mesh delivers consistent results.
Key Features & Technical Specifications
- High Density (160g/m²): Provides superior crack resistance and load distribution.
- Standard Mesh Opening (5x5mm): Ensures excellent adhesion with mortar, plaster, and coatings.
- Alkali-Resistant: Treated with special coating to withstand alkaline environments in cement.
- Lightweight & Flexible: Easy to cut, handle, and install on curved surfaces.
- Thermal Stability: Maintains integrity under temperature variations.
- Eco-Friendly: Made from non-toxic, recyclable fiberglass materials.
| Weight | 160g/m² (±5%) |
| Mesh Opening | 5mm x 5mm |
| Roll Width | 1m (standard), customizable up to 2m |
| Roll Length | 50m or 100m (customizable) |
| Tensile Strength (Warp) | ≥ 1200 N/50mm |
| Tensile Strength (Weft) | ≥ 1000 N/50mm |
| Color | White (standard), other colors available on request |
| Coating | Acrylic or PVC coating for alkali resistance |
Applications & Benefits
Our fiberglass mesh is widely used in the construction industry for:
- External wall insulation systems (EIFS/ETICS)
- Internal wall reinforcement to prevent plaster cracks
- Waterproofing membranes and roofing systems
- Tile backer board and marble reinforcement
- Industrial flooring and concrete reinforcement
- Asphalt pavement crack prevention
By choosing our mesh, customers benefit from reduced maintenance costs, extended building lifespan, and improved surface finish quality. The 5x5mm opening allows optimal bonding with cement-based materials, while the 160g/m² weight provides the needed strength without excessive bulk.
Why Choose Anping Xinye?
Located in the heart of China's wire mesh industry, Anping Xinye Metal Wire Mesh Products Co., Ltd has been dedicated to manufacturing high-quality mesh products for over a decade. We control every step of production, from raw material sourcing to final packaging, ensuring consistent quality. Our factory-direct price eliminates middlemen, offering you competitive pricing without sacrificing quality. We back every order with a 1-year warranty and a 7-day replacement policy for any defects or non-conformities. Our team is committed to providing excellent customer service, quick response, and reliable shipping worldwide.
We take pride in our professional production facilities, experienced workers, and strict quality control. Each batch is tested for tensile strength, mesh opening uniformity, and alkali resistance. We offer flexible customization options, including different widths, lengths, colors, and packaging. Whether you need a small sample or a full container, we are ready to serve you.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between 160g/m² and lighter meshes?
A: 160g/m² mesh offers higher tensile strength and better crack resistance, making it suitable for demanding applications like external wall insulation and heavy-duty reinforcement. Lighter meshes (e.g., 110g/m²) are often used for lighter interior plastering. -
Q: Is this mesh suitable for use with cement?
A: Yes, our fiberglass mesh is treated with an alkali-resistant coating, making it compatible with cement and lime-based plasters. It will not degrade in alkaline environments. -
Q: Can I get custom sizes?
A: Absolutely. We offer customizable widths from 0.5m to 2m, and lengths from 25m to 200m per roll. Please contact us with your specific requirements. -
Q: What is the packaging for export?
A: Each roll is wrapped in plastic film, then packed in a woven bag or carton, depending on the size. We can also provide pallet packaging for container loading. -
Q: How long does shipping take?
A: For standard orders, we ship within 7-15 days after payment. For large quantities, lead time may be 15-25 days. We offer FOB, CIF, and EXW terms. -
Q: Do you provide samples?
A: Yes, we provide free samples (size A4) for quality evaluation. You only need to pay for the shipping cost. Sample production takes 1-2 days. -
Q: What is the warranty policy?
A: We offer a 1-year warranty against manufacturing defects. If any issue arises within 7 days of receipt, we will replace the product promptly. For long-term quality, we are confident in our product's durability. -
Q: Can I request a specific color?
A: While white is standard, we can produce other colors (e.g., green, blue, black) for orders with a minimum quantity. Please inquire for details.
Contact us today to discuss your project requirements and get a factory-direct quote. We are ready to support your business with reliable products and dependable service.
