Anping Xinye Metal Wire Mesh Products Co., Ltd presents our premium Stainless Steel Punching Mesh with a precise 0.8mm hole diameter, 0.5mm thickness, and 200 mesh count, engineered specifically for high-performance liquid filtration. As a leading manufacturer based in Hengshui, Hebei, China, we combine decades of metal fabrication expertise with advanced punching technology to deliver consistent, durable, and reliable filtration media. This product is designed to meet the rigorous demands of industrial liquid processing, offering exceptional flow rate, mechanical strength, and corrosion resistance. Whether you are clarifying beverages, filtering chemicals, or separating solids from process water, our punching mesh provides a cost-effective solution that outperforms woven wire cloth in certain applications.
Product Overview
This stainless steel punching mesh is manufactured from high-grade 304 or 316L stainless steel coils, punched with round holes at a 0.8mm diameter and a pitch that results in a 200 mesh count per inch. The 0.5mm material thickness ensures rigidity while maintaining flexibility for custom fabrication. The staggered hole pattern optimizes open area for efficient liquid passage, and the smooth, burr-free edges reduce clogging. Each sheet is flattened and precision-cut to your specifications, making it ideal for use in filter presses, strainers, centrifugal filters, and custom filtration systems.
Key Features & Technical Specifications
- Material: Stainless steel 304 / 316L – excellent corrosion resistance against acids, alkalis, and saline environments.
- Hole Diameter: 0.8 mm (±0.05 mm) – consistent size for accurate particle retention.
- Sheet Thickness: 0.5 mm – balances strength and weight, easy to cut and weld.
- Mesh Count: 200 holes per inch – provides high open area up to 40% for efficient flow.
- Hole Pattern: Staggered / 60° triangular pitch – maximizes structural integrity and filtration uniformity.
- Surface Finish: Mill finish, bright annealed, or electro-polished upon request.
- Edge Condition: Plain cut, deburred, or with reinforced border for added durability.
- Custom Sizes: Available in sheets or coils; width from 100 mm to 1500 mm, length as required.
Detailed Specifications Table
| Parameter | Value |
| Material Grade | SS304 / SS316L |
| Hole Diameter | 0.8 mm (0.0315 inch) |
| Sheet Thickness | 0.5 mm (0.0197 inch) |
| Mesh Count | 200 holes per inch |
| Open Area | ~40% (depending on pitch) |
| Hole Pitch | 1.27 mm (staggered) |
| Max Width | 1500 mm (customizable) |
| Standard Length | 2000 mm or as required |
| Tensile Strength | ≥ 520 MPa (SS304) |
Benefits for Liquid Filtration
- High Flow Efficiency: The 40% open area allows rapid liquid passage while retaining particles above 0.8 mm, reducing pressure drop.
- Durability: Stainless steel resists rust, chemical attack, and high temperatures, ensuring long service life even in aggressive filtration environments.
- Easy Cleaning: Smooth hole edges and non-stick surface make backwashing or ultrasonic cleaning simple, minimizing downtime.
- Versatile Applications: Suitable for water treatment, food & beverage (juice, beer, wine), pharmaceutical, chemical, and oil filtration.
- Customizable Dimensions: We can cut to exact size, add beveled edges, or weld frames for easy integration into existing equipment.
- Consistent Quality: Each sheet is inspected for hole uniformity and flatness, ensuring reliable performance batch after batch.
Why Choose Anping Xinye?
With over 15 years of experience in wire mesh and perforated metal manufacturing, Anping Xinye has supplied filtration solutions to clients across 30+ countries. Our factory is equipped with advanced CNC punching presses and automated quality control systems. We have exported thousands of tons of stainless steel mesh to industries ranging from chemical processing to water purification. Our dedicated team provides technical support, sample availability, and flexible packaging to meet your logistics needs. We are committed to delivering products that meet your exact filtration requirements, and we welcome small trial orders as well as large-volume contracts.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between this punching mesh and woven wire mesh?
A: Punching mesh is made from a solid sheet with holes punched in; it provides higher strength and rigidity compared to woven mesh, and is less prone to unraveling. It is ideal for applications requiring a flat, rigid filter surface. -
Q: Can I use this mesh for filtering particles smaller than 0.8 mm?
A: No, the hole diameter is 0.8 mm, so particles larger than that will be retained. For finer filtration, we recommend our woven mesh or multi-layer filter cloth. -
Q: Is the product available in 316L stainless steel for corrosive liquids?
A: Yes, we offer both 304 and 316L grades. 316L is recommended for acidic or chloride-rich environments. -
Q: Do you provide samples before bulk order?
A: Absolutely. We can provide small samples (e.g., 200x200 mm) for testing. Please contact us with your requirements. -
Q: What is the minimum order quantity?
A: MOQ is typically 10 sheets for standard sizes, but we can accommodate smaller quantities for trial orders. -
Q: How do I clean the mesh after use?
A: Backflushing with water or using a mild detergent is effective. For stubborn deposits, ultrasonic cleaning or pressurized water jet can be used. -
Q: Can the mesh be cut to non-rectangular shapes?
A: Yes, we can laser-cut or shear to any shape, including circles, ovals, or custom profiles, as per your drawing. -
Q: Does the product have any certifications?
A: Our manufacturing process follows ISO 9001 quality management standards. Specific certifications are available upon request for certain projects.
We at Anping Xinye Metal Wire Mesh Products Co., Ltd are confident that our Stainless Steel Punching Mesh will meet your liquid filtration needs with precision and durability. Contact us today for a quote or technical consultation. Let us help you optimize your filtration process.
