Cast Steel Marine Steam Pressure Reducing Valve DN15-DN100 PN1.6-6.4MPa Flanged DNV BV Approved
Product Spotlights
Our Cast Steel Marine Steam Pressure Reducing Valve (DN15-DN100, PN1.6-6.4MPa) features DNV & BV approval, precise pressure regulation, flanged connections, and high-temperature steam resistance. Ideal for demanding marine and industrial applications, it ensures safety, efficiency, and long service life. Backed by ISO 9001 certified manufacturing and global export experience.
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Cast Steel
Certification:
Other, DNV
Type:
Other, Steam Pressure Reducing Valve
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Zhibang Marine Steam Pressure Reducing Valve With 1-Year Warranty Cast Steel Flanged DN15-DN100 PN1.6-6.4MPaNegotiableMOQ: 1 Unit -
Flanged Marine Steam PRV Cast Steel DN15-DN100 PN1.6-6.4MPa DNV BV Approved for Ship SystemsNegotiableMOQ: 1 Unit
-
Cast Steel Marine Steam Pressure Reducing Valve DN15-DN100 PN1.6-6.4MPa Flanged High Temp Standard CompliantNegotiableMOQ: 1 Unit
-
Zhibang DN15-DN100 Marine Steam Pressure Reducing Valve Cast Steel Flanged PN1.6-6.4MPa Mill Test ReportNegotiableMOQ: 1 Unit
-
PN1.6-6.4MPa Marine Steam Pressure Reducing Valve Cast Steel Flanged DN15-DN100 High Temperature ResistantNegotiableMOQ: 1 Unit
Material
Other, Cast Steel
Certification
Other, DNV
Type
Other, Steam Pressure Reducing Valve
Connection
Flanged
Size Range
DN15 – DN100
Pressure Rating
PN1.6 – PN6.4 MPa
Application
Marine Steam Systems
Design Standard
ISO 9001 (Manufacturing Quality)
Shanghai Zhibang Valve Manufacture Co., Ltd. is a professional valve manufacturer established in 2016, with an annual export value of US$1 million to US$1.5 million. Our Cast Steel Marine Steam Pressure Reducing Valve, ranging from DN15 to DN100 and rated PN1.6 to 6.4MPa, is designed to deliver precise pressure control in demanding marine steam environments. Certified with DNV and BV approvals, this flanged valve ensures reliable operation and long service life, making it an ideal choice for shipbuilding, offshore platforms, and industrial steam systems. We are committed to providing high-quality products that meet the rigorous standards of the global maritime industry.
Key Features & Technical Specifications
- Robust Cast Steel Construction – The valve body is made of high-grade cast steel, offering excellent strength and corrosion resistance in marine environments.
- Flanged Connections – Standard flanged ends (DIN/ANSI/JIS available) ensure easy installation and leak-proof sealing.
- Wide Size & Pressure Range – Available in DN15 to DN100, with pressure ratings from PN1.6 to PN6.4 MPa, covering a broad spectrum of steam applications.
- Precise Pressure Regulation – Internal pilot-operated or direct-acting design maintains downstream pressure within ±5% accuracy, even under fluctuating inlet conditions.
- DNV & BV Type Approval – The valve has been tested and certified by Det Norske Veritas (DNV) and Bureau Veritas (BV), ensuring compliance with international marine classification standards.
- High Temperature & Steam Resistance – Suitable for saturated and superheated steam up to 350°C (customizable for higher temperatures).
- Maintenance-Friendly Design – Easy access to internal parts for cleaning and replacement, reducing downtime.
| Parameter | Value |
|---|---|
| Nominal Diameter | DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100 |
| Pressure Rating | PN1.6, PN2.5, PN4.0, PN6.4 MPa |
| Working Temperature | Up to 350°C (standard), higher on request |
| Connection Type | Flanged (RF, FF, RTJ) |
| Applicable Medium | Steam (saturated, superheated) |
| Certification | DNV, BV, ISO 9001 |
Benefits for Your Application
- Reduces steam pressure to a safe, usable level, protecting downstream equipment and personnel.
- Stable output pressure minimizes energy waste and improves process efficiency.
- Compliance with marine classification society requirements (DNV/BV) simplifies vessel certification and inspection.
- Corrosion-resistant materials and robust construction extend valve life even in harsh saltwater environments.
- Customizable pressure ranges and end connections to fit existing piping systems.
Why Choose Shanghai Zhibang Valve?
Since 2016, we have been dedicated to manufacturing high-quality industrial valves. With an annual export value of US$1 million to US$1.5 million, our products are shipped to major markets worldwide including North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our factory is ISO 9001 certified, ensuring consistent quality control from raw material to finished product. We offer competitive pricing, short lead times, and flexible shipping from Shanghai, Guangzhou, Hong Kong, and Beijing ports. Every valve undergoes rigorous testing before delivery, including hydrostatic shell tests, seat leakage tests, and functional performance checks. Our experienced technical team provides responsive after-sales support to ensure your satisfaction.
Contact us today for a quote or technical consultation. Let our Cast Steel Marine Steam Pressure Reducing Valve be the reliable solution for your steam system needs.
Frequently Asked Questions
-
What is the difference between this valve and a standard pressure reducing valve?
This valve is specifically designed for marine steam applications, with cast steel construction and DNV/BV type approval, making it suitable for use on ships and offshore platforms where classification society rules apply. -
Can the valve be used for non-marine applications?
Yes, it can also be used in industrial steam systems where high pressure and temperature resistance are required. However, for non-marine use, the DNV/BV certification is an extra guarantee of quality. -
What is the typical lead time for production?
Standard sizes (DN15-DN100) are typically produced within 15-30 working days, depending on quantity and customization. Contact us for specific lead times. -
Do you offer spare parts or repair kits?
Yes, we provide diaphragm kits, spring sets, and seat seals for maintenance. Please specify your valve model when ordering. -
How is the valve shipped?
We ship from Shanghai, Guangzhou, Hong Kong, or Beijing ports. Spare parts can be sent via air freight for urgent needs. -
Can the pressure setting be adjusted in the field?
Yes, the set pressure can be adjusted by turning the adjusting screw (for direct-acting types) or by adjusting the pilot valve (for pilot-operated types). Instructions are included in the manual. -
Is the valve suitable for superheated steam above 350°C?
Standard design is for up to 350°C. For higher temperatures, we can provide custom materials and seals upon request. -
What is the warranty period?
We offer a 12-month warranty from the date of shipment against manufacturing defects. Extended warranty options are available.
